Part number
6ES7521-1BH00-0AB0
Model no
DI 16x24VDC HF
$279.45 In stock · 50+ Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
SIMATIC S7-1500

Siemens 6ES7521-1BH00-0AB0 SIMATIC S7-1500 DI 16x24VDC HF Digital Input Module

SIMATIC S7-1500 DI 16x24VDC HF digital input module: 16 channels, 2 counter channels up to 6kHz, IEC 61131 type 3, 24V DC.

Rated current
0.02 A
Rated operational voltage
24 V AC
EAN
4025515080138
Description

About the DI 16x24VDC HF

The Siemens 6ES7521-1BH00-0AB0 is a SIMATIC S7-1500 DI 16x24VDC HF digital input module with 16 channels in one group, 2 of which can run as counters up to 6 kHz. Input delay is parameterizable from 0.05 to 20 ms per IEC 61131 type 3. It draws up to 20 mA from a 24 V DC supply and reports wire-break and short-circuit diagnostics.

Selection Notes

At 16 channels the DI 16x24VDC HF is the lower-density counterpart to the DI 32x24VDC HF in the same 35 mm housing footprint — pick this one when the input count for a segment is under 16 and rack space is not the constraint, since the per-channel cost is otherwise similar. Two of the 16 channels double as 32-bit up-counters to 6 kHz, useful for basic flow or pulse counting without a dedicated high-speed counter module. Wire-break detection to below 350 µA flags an open field circuit at the module level, useful for safety-adjacent digital inputs like guard switches even though this module itself is not fail-safe rated.

Applications

Fits S7-1500 stations needing moderate digital input counts with basic pulse-counting capability — machine interlocks, sensor banks, and general discrete field wiring.

Specification

Full specification

89 values · Last verified 01 Nov 2026

General information 15

Product type designation DI 16x24VDC HF
HW functional status from FS04
Firmware version V2.2.0
FW update possible Yes
Product function: I&M data Yes; I&M0 to I&M3
Product function: Isochronous mode Yes
Product function: Prioritized startup Yes
Engineering with: STEP 7 TIA Portal configurable/integrated from version V13 SP1 / -
Engineering with: STEP 7 configurable/integrated from version V5.5 SP3 / -
Engineering with: PROFIBUS from GSD version/GSD revision V1.0 / V5.1
Engineering with: PROFINET from GSD version/GSD revision V2.3 / -
Operating mode: DI Yes
Operating mode: Counter Yes
Operating mode: Oversampling No
Operating mode: MSI Yes

Supply voltage 4

Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Reverse polarity protection Yes

Input current 1

Current consumption, max. 20 mA; with 24 V DC supply
Show all 89 specifications ↓ Show less ↑69 more values in Identification, Power, Power loss, Digital inputs, Encoder, Isochronous mode, Interrupts/diagnostics/status information, Potential separation, Isolation, Security, Ambient conditions, Dimensions, Weights, General Product Approval, Logistics.

Identification 10

Part number 6ES7521-1BH00-0AB0
Type designation DI 16x24VDC HF
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4025515080138
ETIM class EC001419
eCl@ss 27242204

Power 1

Power consumption from the backplane bus 1.1 W

Power loss 1

Power loss, typ. 2.6 W

Digital inputs 17

Number of digital inputs 16
Digital inputs, parameterizable Yes
Sourcing/sinking input P-reading
Input characteristic curve in accordance with IEC 61131, type 3 Yes
Digital input functions, parameterizable: Gate start/stop Yes
Digital input functions, parameterizable: Freely usable digital input Yes
Counter: Number, max. 2
Counter: Counting frequency, max. 3 kHz
Counter: Counting width 32 bit
Counter: Counting direction up/down Up
Input voltage: Rated value (DC) 24 V
Input voltage: for signal "0" -30 to +5 V
Input voltage: for signal "1" +11 to +30V
Input current: for signal "1", typ. 2.5 mA
Input delay (for rated value of input voltage) for standard inputs: parameterizable Yes; 0.05 / 0.1 / 0.4 / 1.6 / 3.2 / 12.8 / 20 ms
Cable length: shielded, max. 1 000 m
Cable length: unshielded, max. 600 m

Encoder 2

Connectable encoders: 2-wire sensor Yes
Connectable encoders: permissible quiescent current (2-wire sensor), max. 1.5 mA

Isochronous mode 2

Filtering and processing time (TCI), min. 80 µs; At 50 μs filter time
Bus cycle time (TDP), min. 250 µs

Interrupts/diagnostics/status information 12

Diagnostics function Yes
Alarms: Diagnostic alarm Yes
Alarms: Hardware interrupt Yes
Diagnoses: Monitoring the supply voltage Yes
Diagnoses: Wire break Yes; to I < 350 µA
Diagnoses: Short-circuit No
Diagnostics indication LED: RUN LED Yes; green LED
Diagnostics indication LED: ERROR LED Yes; red LED
Diagnostics indication LED: Monitoring of the supply voltage (PWR-LED) Yes; green LED
Diagnostics indication LED: Channel status display Yes; green LED
Diagnostics indication LED: for channel diagnostics Yes; red LED
Diagnostics indication LED: for module diagnostics Yes; red LED

Potential separation 4

Potential separation channels: between the channels No
Potential separation channels: between the channels, in groups of 16
Potential separation channels: between the channels and backplane bus Yes
Potential separation channels: between the channels and the power supply of the electronics No

Isolation 2

Isolation tested with Standards, approvals, certificates 707 V DC (type test)
Suitable for safety functions No

Security 2

signed firmware update No
data integrity No

Ambient conditions 3

Ambient temperature during operation: horizontal installation, min. -30 °C; From FS05
Ambient temperature during operation: vertical installation, min. -30 °C; From FS05
Altitude during operation relating to sea level: Installation altitude above sea level, max. 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual

Dimensions 3

Width 35 mm
Height 147 mm
Depth 129 mm

Weights 1

Weight, approx. 240 g

General Product Approval 3

Miscellaneous Manufacturer Declara-tion For use in hazard-
General Product Approval ous locations
China RoHS Manufacturer Declara- tion

Logistics 6

Net weight 0.275 kg
Country of origin DE
Shipping weight 0.775 kg
Ships from Türkiye
Dispatch 18 Nov
Stock In stock
