SIMATIC S7-1200Siemens 6ES7223-1QH32-0XB0 S7-1200 SM 1223 8DI 120/230VAC 8DO Relay 2A I/O Module
SIMATIC S7-1200 digital I/O module SM 1223, 8 DI 120/230V AC, 8 DO relay 2A, IP20.
Description
About the SM 1223, DI 8x120/230 V AC, DQ 8x relay
About the SM 1223, DI 8x120/230 V AC, DQ 8x relay
The Siemens 6ES7223-1QH32-0XB0 is a SIMATIC S7-1200 digital I/O module (SM 1223) with 8 AC inputs rated 120/230 V AC and 8 relay outputs switching up to 2 A each. It runs from a 24 V DC backplane supply, groups inputs and outputs in sets of 4 for potential separation, and carries IP20, CE, UL/cULus, CSA, FM, and RCM/KC approvals.
Certifications & Standards
- CE
- CSA
- UL
- cULus
- FM
- RCM
- KC
- Marine
Selection Notes
The 8 AC inputs read 120/230 V AC field devices directly, so this card avoids interposing relays where limit switches or pushbuttons already run on line voltage. On the output side, the 8 relay channels switch either AC (5-250 V AC) or DC (5-30 V DC) loads on the same card, unlike a transistor output module limited to one voltage type, which suits panels mixing AC contactors with DC indicators. Output short-circuit protection is not built in and must be provided externally, which matters when sizing upstream fusing for the relay outputs.
Applications
Machine control panels with mixed 120/230 V AC field inputs and relay-switched AC/DC outputs, such as line-voltage limit switches feeding contactors, solenoids, or pilot lamps from an S7-1200 station.
Specification
Full specification
General information 1
| Product type designation | SM 1223, DI 8x120/230 V AC, DQ 8x relay |
|---|
Supply voltage 3
| Rated value (DC) | 24 V |
|---|---|
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
Input current 1
| from backplane bus 5 V DC, max. | 120 mA |
|---|
Show all 96 specifications ↓ Show less ↑91 more values in Identification, Output voltage, Power loss, Digital inputs, Digital outputs, Interrupts/diagnostics/status information, Potential separation, Permissible potential difference, Degree and class of protection, Standards, approvals, certificates, Ambient conditions, Connection method, Mechanics/material, Dimensions, Weights, General Product Approval, Logistics.
Identification 10
| Part number | 6ES7223-1QH32-0XB0 |
|---|---|
| Type designation | SM 1223, DI 8x120/230 V AC, DQ 8x relay |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 6940408102026 |
| ETIM class | EC001419 |
| eCl@ss | 27242204 |
Output voltage 1
| Power supply to the transmitters: present | Yes |
|---|
Power loss 1
| Power loss, typ. | 7.5 W |
|---|
Digital inputs 13
| Number of digital inputs | 8 |
|---|---|
| in groups of | 4 |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes |
| Number of simultaneously controllable inputs all mounting positions: up to 40 °C, max. horizontal installation | 8 |
| Input voltage: Rated value (AC) | 120/230 V AC |
| Input voltage: for signal "0" | 20 V AC at 1 mA |
| Input voltage: for signal "1" | 79 V AC at 2.5 mA |
| Input current: for signal "0", max. (permissible quiescent current) | 1 mA |
| Input current: for signal "1", min. | 2.5 mA |
| Input current: for signal "1", typ. | 9 mA |
| Input delay (for rated value of input voltage) for standard inputs: parameterizable for interrupt inputs | Yes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms and 12.8 ms, selectable in groups of four |
| Cable length: shielded, max. | 500 m |
| Cable length: unshielded, max. | 300 m |
Digital outputs 20
| Number of digital outputs | 8 |
|---|---|
| in groups of | 4 |
| Short-circuit protection | No; to be provided externally |
| Switching capacity of the outputs: with resistive load, max. | 2 A |
| Switching capacity of the outputs: on lamp load, max. | 30 W with DC, 200 W with AC |
| Output voltage: Rated value (DC) | 5 V DC to 30 V DC |
| Output voltage: Rated value (AC) | 5 V AC to 250 V AC |
| Output current: for signal "1" rated value | 2 A |
| Output current: for signal "1" permissible range, max. | 2 A |
| Output delay with resistive load: "0" to "1", max. | 10 ms |
| Output delay with resistive load: "1" to "0", max. | 10 ms |
| Total current of the outputs (per group) horizontal installation: up to 50 °C, max. | 8 A; Current per mass |
| Relay outputs: Number of relay outputs | 8 |
| Relay outputs: Rated supply voltage of relay coil L+ (DC) | 24 V |
| Relay outputs: Number of operating cycles, max. Switching capacity of contacts | mechanically 10 million, at rated load voltage 100 000 |
| Relay outputs: with inductive load, max. | 2 A |
| Relay outputs: on lamp load, max. | 30 W with DC, 200 W with AC |
| Relay outputs: with resistive load, max. | 2 A |
| Cable length: shielded, max. | 500 m |
| Cable length: unshielded, max. | 150 m |
Interrupts/diagnostics/status information 3
| Alarms: Diagnostic alarm | Yes |
|---|---|
| Diagnostics indication LED: for status of the inputs | Yes |
| Diagnostics indication LED: for status of the outputs | Yes |
Potential separation 4
| Potential separation digital inputs: between the channels, in groups of | 2 |
|---|---|
| Potential separation digital outputs: between the channels | Relays |
| Potential separation digital outputs: between the channels, in groups of | 2 |
| Potential separation digital outputs: between the channels and backplane bus | 1 500 V AC for 1 minute |
Permissible potential difference 1
| between different circuits | 750 V AC for 1 minute |
|---|
Degree and class of protection 1
| IP degree of protection | IP20 |
|---|
Standards, approvals, certificates 13
| CE mark | Yes |
|---|---|
| CSA approval | Yes |
| UL approval | Yes |
| cULus | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| Marine approval | Yes |
| Ecological footprint: environmental product declaration Global warming potential | Yes |
| Ecological footprint: global warming potential, (total) [CO2 eq] | 123 kg |
| Ecological footprint: global warming potential, (during production) [CO2 eq] | 12.1 kg |
| Ecological footprint: global warming potential, (during operation) [CO2 eq] | 111 kg |
| Ecological footprint: global warming potential, (after end of life cycle) [CO2 eq] | -0.434 kg |
Ambient conditions 11
| Free fall: Fall height, max. | 0.3 m; five times, in product package |
|---|---|
| Ambient temperature during operation: min. | -20 °C |
| Ambient temperature during operation: max. | 60 °C; Number of simultaneously activated outputs: 4 (no adjacent points) at 60 °C horizontal or 50 °C vertical, 8 at 55 °C horizontal or 45 °C vertical |
| Ambient temperature during operation: horizontal installation, min. | -20 °C |
| Ambient temperature during operation: vertical installation, min. | -20 °C |
| Ambient temperature during operation: permissible temperature change | 5°C to 55°C, 3°C / minute |
| Ambient temperature during storage/transportation: min. | -40 °C |
| Ambient temperature during storage/transportation: max. | 70 °C |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, min. | 660 hPa |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, max. | 1 080 hPa |
| Relative humidity: Operation at 25 ℃ without condensation, max. | 95 % |
Connection method 1
| required front connector | Yes |
|---|
Mechanics/material 1
| Enclosure material (front): Plastic | Yes |
|---|
Dimensions 3
| Width | 45 mm |
|---|---|
| Height | 100 mm |
| Depth | 75 mm |
Weights 1
| Weight, approx. | 230 g |
|---|
General Product Approval 1
| Miscellaneous Manufacturer Declara- | tion |
|---|
Logistics 6
| Net weight | 0.223 kg |
|---|---|
| Country of origin | CN |
| Shipping weight | 0.723 kg |
| Ships from | Türkiye |
| Dispatch | 12 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 01 Nov 2026
