SIMATIC S7-1200Siemens 6ES7222-1XF32-0XB0 SIMATIC S7-1200 SM 1222 8DO Relay Changeover PLC I/O Module
SIMATIC S7-1200 SM 1222 digital output module - 8 relay changeover DO, 2A each, 5-30VDC/5-250VAC.
Description
About the SM 1222, DQ 8x relay/2 A
About the SM 1222, DQ 8x relay/2 A
The Siemens 6ES7222-1XF32-0XB0 is a SIMATIC S7-1200 SM 1222 digital output module with 8 relay changeover-contact outputs rated 2 A each, switching 5-30 V DC or 5-250 V AC loads directly. It draws its logic supply from the S7-1200 backplane bus at 20.4-28.8 V DC, adding 140 mA of 5 V DC backplane load and 5 W of power loss.
Certifications & Standards
- CE
- CSA
- UL
- cULus
- FM
- RCM
- KC
- Marine
Selection Notes
The changeover (SPDT) relay contacts switch AC or DC loads directly from the CPU without an external interposing relay, but short-circuit protection is not built in, so size external fusing or a circuit breaker to the 2 A rated current per channel. Relay life is rated at 10 million mechanical cycles but drops to 100000 at rated load current, so for high-cycle switching duty a solid-state output module is the better fit; choose this relay variant when the load is AC, mixed AC/DC, or exceeds the voltage range of transistor outputs.
Applications
Fits applications that need a PLC output stage to switch mains-referenced loads directly: contactor coils, indicator lamps, small solenoid valves, and mixed 24 V DC / 230 V AC control panels where isolating relay contacts avoid mixing supply domains on one output card.
Specification
Full specification
General information 1
| Product type designation | SM 1222, DQ 8x relay/2 A |
|---|
Supply voltage 2
| permissible range, lower limit (DC) | 20.4 V |
|---|---|
| permissible range, upper limit (DC) | 28.8 V |
Input current 2
| from backplane bus 5 V DC, max. | 140 mA |
|---|---|
| Digital outputs: from load voltage L+, max. | 16.7 mA/relay coil |
Show all 82 specifications ↓ Show less ↑77 more values in Identification, Power loss, Digital outputs, Interrupts/diagnostics/status information, Potential separation, Permissible potential difference, Degree and class of protection, Standards, approvals, certificates, Ambient conditions, Connection method, Mechanics/material, Dimensions, Weights, EClass 12 27-24-22-04, Logistics.
Identification 10
| Part number | 6ES7222-1XF32-0XB0 |
|---|---|
| Type designation | SM 1222, DQ 8x relay/2 A |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 6940408101975 |
| ETIM class | EC001419 |
| eCl@ss | 27242204 |
Power loss 1
| Power loss, typ. | 5 W |
|---|
Digital outputs 19
| Number of digital outputs | 8 |
|---|---|
| in groups of | 1 |
| Short-circuit protection | No; to be provided externally |
| Switching capacity of the outputs: with resistive load, max. | 2 A |
| Switching capacity of the outputs: on lamp load, max. | 30 W with DC, 200 W with AC |
| Output voltage: Rated value (DC) | 5 V DC to 30 V DC |
| Output voltage: Rated value (AC) | 5 V AC to 250 V AC |
| Output current: for signal "1" rated value | 2 A |
| Output delay with resistive load: "0" to "1", max. | 10 ms |
| Output delay with resistive load: "1" to "0", max. | 10 ms |
| Total current of the outputs (per group) horizontal installation: up to 50 °C, max. | 2 A; Current per mass |
| Relay outputs: Number of relay outputs | 8 |
| Relay outputs: Rated supply voltage of relay coil L+ (DC) | 24 V |
| Relay outputs: Number of operating cycles, max. Switching capacity of contacts | mechanically 10 million, at rated load voltage 100 000 |
| Relay outputs: with inductive load, max. | 2 A |
| Relay outputs: on lamp load, max. | 30 W with DC, 200 W with AC |
| Relay outputs: with resistive load, max. | 2 A |
| Cable length: shielded, max. | 500 m |
| Cable length: unshielded, max. | 150 m |
Interrupts/diagnostics/status information 2
| Alarms: Diagnostic alarm | Yes |
|---|---|
| Diagnostics indication LED: for status of the outputs | Yes |
Potential separation 3
| Potential separation digital outputs: between the channels | Relays |
|---|---|
| Potential separation digital outputs: between the channels, in groups of | 1 |
| Potential separation digital outputs: between the channels and backplane bus | 1 500 V AC for 1 minute |
Permissible potential difference 1
| between different circuits | 750 V AC for 1 minute |
|---|
Degree and class of protection 1
| IP degree of protection | IP20 |
|---|
Standards, approvals, certificates 13
| CE mark | Yes |
|---|---|
| CSA approval | Yes |
| UL approval | Yes |
| cULus | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| Marine approval | Yes |
| Ecological footprint: environmental product declaration Global warming potential | Yes |
| Ecological footprint: global warming potential, (total) [CO2 eq] | 68.6 kg |
| Ecological footprint: global warming potential, (during production) [CO2 eq] | 8.16 kg |
| Ecological footprint: global warming potential, (during operation) [CO2 eq] | 60.7 kg |
| Ecological footprint: global warming potential, (after end of life cycle) [CO2 eq] | -0.334 kg |
Ambient conditions 11
| Free fall: Fall height, max. | 0.3 m; five times, in product package |
|---|---|
| Ambient temperature during operation: min. | -20 °C |
| Ambient temperature during operation: max. | 60 °C; Number of simultaneously activated outputs: 4 (no adjacent points) at 60 °C horizontal or 50 °C vertical, 8 at 55 °C horizontal or 45 °C vertical |
| Ambient temperature during operation: horizontal installation, min. | -20 °C |
| Ambient temperature during operation: vertical installation, min. | -20 °C |
| Ambient temperature during operation: permissible temperature change | 5°C to 55°C, 3°C / minute |
| Ambient temperature during storage/transportation: min. | -40 °C |
| Ambient temperature during storage/transportation: max. | 70 °C |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, min. | 660 hPa |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, max. | 1 080 hPa |
| Relative humidity: Operation at 25 ℃ without condensation, max. | 95 % |
Connection method 1
| required front connector | Yes |
|---|
Mechanics/material 1
| Enclosure material (front): Plastic | Yes |
|---|
Dimensions 3
| Width | 70 mm |
|---|---|
| Height | 100 mm |
| Depth | 75 mm |
Weights 1
| Weight, approx. | 310 g |
|---|
EClass 12 27-24-22-04 4
| eClass | 9.1 27-24-22-04 |
|---|---|
| ETIM | 10 EC001419 |
| IDEA | 4 3566 |
| UNSPSC | 15 32-15-17-05 |
Logistics 6
| Net weight | 0.351 kg |
|---|---|
| Country of origin | CN |
| Shipping weight | 0.851 kg |
| Ships from | Türkiye |
| Dispatch | 13 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6ES7222-1XF32-0XB0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE mark
- CSA approval
- UL approval
- cULus
- FM approval
- RCM (formerly C-TICK)
- KC approval
- Marine approval
Quick answers
Questions about the SM 1222, DQ 8x relay/2 A
What is the rated current of SM 1222, DQ 8x relay/2 A?
The rated current of SM 1222, DQ 8x relay/2 A is 2 A.
Which supply voltage is SM 1222, DQ 8x relay/2 A rated for?
The rated operational voltage of SM 1222, DQ 8x relay/2 A is 5–250 – 5–30 V DC.
What is the HS code of SM 1222, DQ 8x relay/2 A for customs?
The tariff (HS) code on file for SM 1222, DQ 8x relay/2 A is 85389091.
What is the EAN of SM 1222, DQ 8x relay/2 A?
The EAN (GTIN) of SM 1222, DQ 8x relay/2 A is 6940408101975.
Where does SM 1222, DQ 8x relay/2 A ship from, and how fast?
SM 1222, DQ 8x relay/2 A ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
