SIMATIC S7-1200Siemens 6ES7222-1BD30-0XB0 SIMATIC S7-1200 SB 1222 4DQ 24V DC 200kHz Signal Board PLC I/O Module
Siemens SB 1222 signal board, 4 DQ 24V DC, 200kHz pulse output, for SIMATIC S7-1200.
Description
About the SB 1222, DQ 4x24 V DC 200 kHz
About the SB 1222, DQ 4x24 V DC 200 kHz
The Siemens 6ES7222-1BD30-0XB0 SB 1222 is a signal board for the SIMATIC S7-1200 that adds 4 MOSFET digital outputs rated 24 V DC, switching up to 200 kHz for pulse-train motion control. Output current is 0.1 A per channel, and the board mounts directly on the CPU faceplate without consuming a backplane slot.
Certifications & Standards
- CE
- CSA
- UL
- cULus
- FM
- RCM
- KC
- Marine
Selection Notes
200 kHz switching frequency makes this board suitable for pulse-train (PTO) step/direction outputs to small stepper or servo drives, where the standard 100 Hz transistor outputs on a full signal module fall well short. Because it plugs into the CPU's signal-board slot rather than the backplane bus, adding it does not use up one of the CPU's limited signal-module positions - reserve that slot for higher-current I/O instead. The 0.1 A output rating means it drives drive-input opto-couplers directly but not solenoids or relay coils without an interposing driver.
Applications
High-speed pulse output for stepper/servo drive step-and-direction control, and general low-current 24 V DC digital output expansion on space-constrained SIMATIC S7-1200 CPUs.
Specification
Full specification
General information 1
| Product type designation | SB 1222, DQ 4x24 V DC 200 kHz |
|---|
Input current 1
| from backplane bus 5 V DC, typ. | 35 mA |
|---|
Power loss 1
| Power loss, typ. | 0.5 W |
|---|
Show all 54 specifications ↓ Show less ↑51 more values in Identification, Digital outputs, Interrupts/diagnostics/status information, Standards, approvals, certificates, Ambient conditions, Mechanics/material, Dimensions, Weights, Logistics.
Identification 10
| Part number | 6ES7222-1BD30-0XB0 |
|---|---|
| Type designation | SB 1222, DQ 4x24 V DC 200 kHz |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 6940408100794 |
| ETIM class | EC001419 |
| eCl@ss | 27242204 |
Digital outputs 11
| Number of digital outputs | 4; MOSFET, solid-state (current-sinking/current-sourcing) |
|---|---|
| in groups of | 4 |
| Short-circuit protection | No |
| Switching capacity of the outputs: with resistive load, max. | 0.1 A |
| Load resistance range: upper limit | 11 Ω |
| Output voltage: Rated value (DC) | 24 V |
| Output voltage: for signal "0", max. | 1 V; with 10 kOhm load |
| Output voltage: for signal "1", min. | L+ (-1.5 V) |
| Output current: for signal "1" rated value | 0.1 A |
| Output current: for signal "1" permissible range, max. | 0.1 A |
| Cable length: shielded, max. | 50 m |
Interrupts/diagnostics/status information 1
| Diagnostics indication LED: for status of the outputs | Yes |
|---|
Standards, approvals, certificates 8
| CE mark | Yes |
|---|---|
| CSA approval | Yes |
| UL approval | Yes |
| cULus | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| Marine approval | Yes |
Ambient conditions 10
| Free fall: Fall height, max. | 0.3 m; five times, in product package |
|---|---|
| Ambient temperature during operation: min. | -20 °C |
| Ambient temperature during operation: max. | 60 °C |
| Ambient temperature during operation: horizontal installation, min. | -20 °C |
| Ambient temperature during operation: vertical installation, min. | -20 °C |
| Ambient temperature during storage/transportation: min. | -40 °C |
| Ambient temperature during storage/transportation: max. | 70 °C |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, min. | 660 hPa |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, max. | 1 080 hPa |
| Relative humidity: Operation at 25 ℃ without condensation, max. | 95 % |
Mechanics/material 1
| Enclosure material (front): Plastic | Yes |
|---|
Dimensions 3
| Width | 38 mm |
|---|---|
| Height | 62 mm |
| Depth | 21 mm |
Weights 1
| Weight, approx. | 35 g |
|---|
Logistics 6
| Net weight | 0.03 kg |
|---|---|
| Country of origin | CN |
| Shipping weight | 0.53 kg |
| Ships from | Türkiye |
| Dispatch | 16 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6ES7222-1BD30-0XB0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- CE mark
- CSA approval
- UL approval
- cULus
- FM approval
- RCM (formerly C-TICK)
- KC approval
- Marine approval
Quick answers
Questions about the SB 1222, DQ 4x24 V DC 200 kHz
What is the rated current of SB 1222, DQ 4x24 V DC 200 kHz?
The rated current of SB 1222, DQ 4x24 V DC 200 kHz is 0.1 A.
Which supply voltage is SB 1222, DQ 4x24 V DC 200 kHz rated for?
The rated operational voltage of SB 1222, DQ 4x24 V DC 200 kHz is 24 V AC.
What is the HS code of SB 1222, DQ 4x24 V DC 200 kHz for customs?
The tariff (HS) code on file for SB 1222, DQ 4x24 V DC 200 kHz is 85389091.
What is the EAN of SB 1222, DQ 4x24 V DC 200 kHz?
The EAN (GTIN) of SB 1222, DQ 4x24 V DC 200 kHz is 6940408100794.
Where does SB 1222, DQ 4x24 V DC 200 kHz ship from, and how fast?
SB 1222, DQ 4x24 V DC 200 kHz ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
