Siemens 6ES7214-1HH50-0XB0 SIMATIC S7-1200 CPU 1214C DC/DC/RLY 14DI/10DO PLC

The Siemens 6ES7214-1HH50-0XB0 is a SIMATIC S7-1200 CPU 1214C DC/DC/RLY compact PLC with 24 V DC supply, 14 integrated digital inputs, and 10 relay outputs rated 2 A each. It provides 250 KB of program memory, 750 KB of data memory, and two integrated PROFINET RJ45 ports with autocrossing.

Technical Specifications

Certifications & Standards

• CE
• UL
• cULus
• RCM
• KC
• Marine

Selection Notes

The relay-output variant (DC/DC/RLY) switches up to 2 A resistive or 200 W AC lamp loads directly, which suits mixed AC/DC field devices without external interposing relays - the transistor-output DC/DC/DC version would be the choice instead for high-speed PTO/PWM outputs. With 8 of the 14 digital inputs usable for high-speed counting, up to 100 kHz single-phase, this CPU covers basic motion feedback and pulse counting without an added technology module. The 750 KB data memory versus 250 KB program memory split matters for programs with large recipe or logging data blocks.

Applications

Fits compact machine control, mixed AC/DC actuator switching without external relays, and applications needing onboard high-speed counting for encoder or pulse-based feedback.
