- Part number
- 6ES7214-1AF50-0XB0
- Model no
- CPU 1214FC DC/DC/DC
In stock · 16
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
SIMATIC S7-1200Siemens 6ES7214-1AF50-0XB0 SIMATIC S7-1200 CPU 1214FC DC/DC/DC 14DI/10DQ Programmable Logic Controller
SIMATIC S7-1200 CPU 1214FC fail-safe compact PLC - 14DI/10DQ, 300KB/750KB memory, PROFINET, 24V DC.
Description
About the CPU 1214FC DC/DC/DC
About the CPU 1214FC DC/DC/DC
The Siemens 6ES7214-1AF50-0XB0 is a SIMATIC S7-1200 CPU 1214FC DC/DC/DC fail-safe compact CPU with 14 integrated 24 V DC digital inputs and 10 digital outputs. It runs on 20.4-28.8 V DC, holds 300 KB of program memory and 750 KB of data memory with 20 KB retentive, and communicates over a 2-port PROFINET interface with integrated switch.
Certifications & Standards
- CE
- UL
- cULus
- RCM
- KC
- Marine
Selection Notes
The FC suffix marks a fail-safe compact CPU: alongside standard logic it accepts F-blocks for PROFIsafe-rated safety functions in TIA Portal without a separate safety controller. With 14 integrated digital inputs, 8 usable for high-speed counting up to 100 kHz, and 10 outputs, 4 rated to 100 kHz, it covers small-to-medium I/O counts without add-on signal modules. Pick it over a non-fail-safe CPU when the machine needs integrated safety, and reserve a larger-memory CPU in the range for programs exceeding the 300 KB/750 KB program/data split.
Applications
Suited to machine safety applications needing integrated F-CPU logic on a single controller: guard interlocking, E-stop chains, and light-curtain monitoring over PROFINET, alongside standard motion counting via the onboard 100 kHz high-speed counters for encoder-based positioning and quadrature-phase measurement tasks.
Specification
Full specification
General information 7
| Product type designation | CPU 1214FC DC/DC/DC |
|---|---|
| Firmware version | V4.1 |
| FW update possible | Yes |
| Product function: I&M data | Yes; I&M0 to I&M3 |
| Product function: Isochronous mode | Yes; For PROFINET only |
| Product function: SysLog | Yes |
| Engineering with: Programming package | STEP 7 V21 or higher |
Supply voltage 4
| Rated value (DC): 24 V DC | Yes |
|---|---|
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
Input current 4
| Current consumption (rated value) | 145 mA; CPU only |
|---|---|
| Current consumption, max. | 1 000 mA; CPU with all expansion modules |
| Inrush current, max. | 12 A; at 28.8 V DC |
| I2t | 0.5 A2·s |
Show all 333 specifications ↓ Show less ↑318 more values in Identification, Output current, Encoder supply, Power loss, Storage, CPU processing times, CPU-blocks, Data areas and their retentivity, Address area, Hardware configuration, Time of day, Digital inputs, Digital outputs, Analog inputs, Analog outputs, Encoder, Interfaces, 1. Interface, Protocols, Communication functions, S7 message functions, Test commissioning functions, Interrupts/diagnostics/status information, Supported technology objects, Integrated Functions, Potential separation, EMC, Degree and class of protection, Standards, approvals, certificates, Security, Ambient conditions, Configuration, Dimensions, Weights, General Product Approval, Logistics.
Identification 10
| Part number | 6ES7214-1AF50-0XB0 |
|---|---|
| Type designation | CPU 1214FC DC/DC/DC |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047623414797 |
| ETIM class | EC000236 |
| eCl@ss | 27242207 |
Output current 1
| for backplane bus (5 V DC), max. | 1 600 mA; Max. 5 V DC for SM and CM |
|---|
Encoder supply 3
| 24 V encoder supply: 24 V | Yes; L+ minus 4 V DC min. |
|---|---|
| 24 V encoder supply: Short-circuit protection | Yes |
| 24 V encoder supply: Output current, max. | 400 mA |
Power loss 1
| Power loss, typ. | 3.5 W |
|---|
Storage 8
| Work memory: integrated | 1 050 kbyte |
|---|---|
| Work memory: integrated (for program) | 300 kbyte |
| Work memory: integrated (for data) | 750 kbyte |
| Load memory: Integrated | 8 Mbyte |
| Load memory: Plug-in (SIMATIC Memory Card), max. | 32 Gbyte; with SIMATIC memory card |
| Backup: present | Yes |
| Backup: maintenance-free | Yes |
| Backup: without battery | Yes |
CPU processing times 3
| for bit operations, typ. | 37 ns; / instruction |
|---|---|
| for word operations, typ. | 30 ns; / instruction |
| for floating point arithmetic, typ. | 74 ns; / instruction |
CPU-blocks 12
| Number of elements (total) | 4 000; Blocks (OB, FB, FC, DB) and UDTs |
|---|---|
| OB: Number of free cycle OBs | 100 |
| OB: Number of time alarm OBs | 20 |
| OB: Number of delay alarm OBs | 20 |
| OB: Number of cyclic interrupt OBs | 20; with minimum OB 3x cycle of 1 ms |
| OB: Number of process alarm OBs | 50 |
| OB: Number of DPV1 alarm OBs | 3 |
| OB: Number of isochronous mode OBs | 1 |
| OB: Number of startup OBs | 100 |
| OB: Number of asynchronous error OBs | 4 |
| OB: Number of synchronous error OBs | 2 |
| OB: Number of diagnostic alarm OBs | 1 |
Data areas and their retentivity 3
| Retentive data area (incl. timers, counters, flags), max. | 20 kbyte |
|---|---|
| Flag: Size, max. | 8 kbyte; Size of bit memory address area |
| Local data: per priority class, max. | 64 kbyte; max. 16 KB per block |
Address area 4
| I/O address area: Inputs | 1 kbyte; All inputs are in the process image |
|---|---|
| I/O address area: Outputs | 1 kbyte; All outputs are in the process image |
| Process image: Inputs, adjustable | 1 kbyte |
| Process image: Outputs, adjustable | 1 kbyte |
Hardware configuration 4
| Number of modules per system, max. | 10 |
|---|---|
| number of expansion boards (SB, CB, BB) | 2 |
| number of signal modules (SM) | 10; depends on the number of CMs |
| number of communications modules (CM) | 3 |
Time of day 4
| Clock: Hardware clock (real-time) | Yes |
|---|---|
| Clock: Backup time | 480 h; Typical |
| Clock: Deviation per day, max. | 2 s; at 25 °C |
| Clock synchronization: on Ethernet via NTP | Yes |
Digital inputs 10
| Number of digital inputs | 14; Integrated |
|---|---|
| of which inputs usable for technological functions | 8; HSC (High Speed Counting) |
| Sourcing/sinking input | Yes |
| Number of simultaneously controllable inputs all mounting positions: up to 40 °C, max. | 14 |
| Input voltage: Rated value (DC) | 24 V |
| Input voltage: for signal "0" | 5 V DC or 0.5 mA |
| Input voltage: for signal "1" | 15 V DC at 2.5 mA |
| Input delay (for rated value of input voltage) for standard inputs: parameterizable | 0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 μs; 0.05 / 0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 ms |
| Cable length: shielded, max. | 500 m; 50 m for technological functions |
| Cable length: unshielded, max. | 300 m; for technological functions: No |
Digital outputs 15
| Number of digital outputs | 10; 20 kHz or 100 kHz |
|---|---|
| of which high-speed outputs | 4; 100 kHz (Qa.0 - Qa.3) |
| Limitation of inductive shutdown voltage to Switching capacity of the outputs | L+ (-40 V) |
| with resistive load, max. | 0.5 A |
| on lamp load, max. | 5 W |
| Output voltage: for signal "0", max. | 0.1 V; with 10 kOhm load |
| Output voltage: for signal "1", min. | 20 V |
| Output current: for signal "1" rated value | 0.5 A |
| Output current: for signal "0" residual current, max. | 10 µA |
| Output delay with resistive load: "0" to "1", max. | 1 µs; of the pulse outputs (Qa.0 to Qa.3), max. 1.0 µs; of the standard outputs (Qa.4 to Qb.1), max. 50 µs |
| Output delay with resistive load: "1" to "0", max. | 3 µs; of the pulse outputs (Qa.0 to Qa.3), max. 3.0 µs; of the standard outputs (Qa.4 to Qb.1), max. 200 µs |
| Switching frequency: of the pulse outputs, with resistive load, max. | 100 kHz; 100 kHz max. (Qa.0 - Qa.3), 20 kHz max. (Qa.4 to Qb.1) |
| Relay outputs: Number of relay outputs | 0 |
| Cable length: shielded, max. | 500 m |
| Cable length: unshielded, max. | 150 m |
Analog inputs 1
| Number of analog inputs | 0 |
|---|
Analog outputs 1
| Number of analog outputs | 0 |
|---|
Encoder 1
| Connectable encoders: 2-wire sensor | Yes |
|---|
Interfaces 1
| Number of PROFINET interfaces | 1 |
|---|
1. Interface 43
| Interface type | PROFINET |
|---|---|
| Isolated | Yes |
| automatic detection of transmission rate | Yes |
| Autonegotiation | Yes |
| Autocrossing | Yes |
| Interface types: RJ 45 (Ethernet) | Yes; X1 |
| Interface types: Transmission rate, max. | 100 Mbit/s |
| Interface types: Number of ports | 2 |
| Interface types: integrated switch | Yes |
| Protocols: IP protocol | Yes; IPv4 |
| Protocols: PROFINET IO Controller | Yes |
| Protocols: PROFINET IO device | Yes |
| Protocols: SIMATIC communication | Yes |
| Protocols: Open IE communication | Yes; Optionally also encrypted |
| Protocols: Web server | Yes |
| Protocols: Media redundancy | Yes |
| PROFINET IO Controller: Transmission rate, max. Services | 100 Mbit/s |
| PROFINET IO Controller: PG/OP communication | Yes; encryption with TLS V1.3 pre-selected |
| PROFINET IO Controller: Isochronous mode | Yes |
| PROFINET IO Controller: IRT | Yes |
| PROFINET IO Controller: Dynamic Frame Packing (DFP) | Yes |
| PROFINET IO Controller: PROFIenergy | Yes; per user program |
| PROFINET IO Controller: Prioritized startup | Yes |
| PROFINET IO Controller: Number of IO devices with prioritized startup, max. | 16 |
| PROFINET IO Controller: Number of connectable IO Devices, max. | 31 |
| PROFINET IO Controller: Of which IO devices with IRT, max. | 31 |
| PROFINET IO Controller: Number of connectable IO Devices for RT, max. | 31 |
| PROFINET IO Controller: of which in line, max. | 31 |
| PROFINET IO Controller: Number of IO Devices that can be simultaneously activated/deactivated, max. | 8 |
| PROFINET IO Controller: Updating time Update time for IRT | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. |
| PROFINET IO Controller: for send cycle of 1 ms | 1 ms to 16 ms |
| PROFINET IO Controller: for send cycle of 2 ms | 2 ms to 32 ms |
| PROFINET IO Controller: for send cycle of 4 ms Update time for RT | 4 ms to 64 ms |
| PROFINET IO Controller: for send cycle of 4 ms | 4 ms to 512 ms |
| PROFINET IO Device Services: PG/OP communication | Yes; encryption with TLS V1.3 pre-selected |
| PROFINET IO Device Services: Isochronous mode | No |
| PROFINET IO Device Services: IRT | Yes |
| PROFINET IO Device Services: Dynamic Frame Packing (DFP) | No |
| PROFINET IO Device Services: PROFIenergy | Yes; per user program |
| PROFINET IO Device Services: Prioritized startup | Yes |
| PROFINET IO Device Services: Shared device | Yes |
| PROFINET IO Device Services: Number of IO Controllers with shared device, max. | 2 |
| PROFINET IO Device Services: Asset management record | Yes |
Protocols 56
| Supports protocol for PROFINET IO | Yes |
|---|---|
| PROFIsafe | Yes |
| PROFIBUS | No |
| OPC UA | Yes; OPC UA Server |
| AS-Interface | No |
| Protocols (Ethernet): TCP/IP | Yes |
| Protocols (Ethernet): DHCP | Yes |
| Protocols (Ethernet): SNMP | Yes |
| Protocols (Ethernet): DCP | Yes |
| Protocols (Ethernet): LLDP | Yes |
| Number of connections: Number of connections, max. | 128; via integrated interfaces of the CPU and connected CPs / CMs |
| Number of connections: Number of connections reserved for ES/HMI/web | 10 |
| Number of connections: Number of connections via integrated interfaces | 88 |
| Number of connections: Number of S7 routing paths | 16 |
| Redundancy mode: PROFINET system redundancy (S2) | No |
| Redundancy mode: PROFINET system redundancy (R1) Media redundancy | No |
| Redundancy mode: MRP | Yes; as MRP redundancy manager and/or MRP client |
| Redundancy mode: MRP interconnection, supported | Yes |
| Redundancy mode: MRPD | Yes; Requirement: IRT |
| Redundancy mode: Number of stations in the ring, max. | 50 |
| SIMATIC communication: PG/OP communication | Yes; encryption with TLS V1.3 pre-selected |
| SIMATIC communication: S7 routing | Yes |
| SIMATIC communication: S7 communication, as server | Yes |
| SIMATIC communication: S7 communication, as client | Yes; only PUT/GET |
| SIMATIC communication: User data per job, max. | See online help (S7 communication, user data size) |
| Open IE communication: TCP/IP | Yes |
| Open IE communication: Data length, max. | 64 kbyte |
| Open IE communication: several passive connections per port, supported | Yes |
| Open IE communication: ISO-on-TCP (RFC1006) | Yes |
| Open IE communication: UDP | Yes |
| Open IE communication: DHCP | Yes |
| Open IE communication: DNS | Yes |
| Open IE communication: SNMP | Yes |
| Open IE communication: DCP | Yes |
| Open IE communication: LLDP | Yes |
| Open IE communication: Encryption | Yes; Optional |
| Web server: supported | Yes |
| Web server: HTTPS | Yes |
| Web server: web API | Yes |
| Web server: Number of sessions, max. | 30 |
| Web server: HTTP request body, max. | 131 072 byte |
| Web server: User-defined websites | Yes |
| OPC UA: Runtime license required | Yes; "Basic" license required |
| OPC UA: OPC UA Server | Yes; data access (read, write, subscribe), method call, runtime license required |
| OPC UA: Application authentication | Yes |
| OPC UA: Security policies | available security policies: None, Basic128Rsa15, Basic256Rsa15, Basic256Sha256, Aes128Sha256RsaOaep, Aes256Sha256RsaPss |
| OPC UA: User authentication | "anonymous" or by user name & password |
| OPC UA: Number of sessions, max. | 10 |
| OPC UA: Number of subscriptions per session, max. | 5 |
| OPC UA: Sampling interval, min. | 100 ms |
| OPC UA: Publishing interval, min. | 200 ms |
| OPC UA: Number of server methods, max. | 20 |
| OPC UA: Number of monitored items, recommended max. | 1 000 |
| OPC UA: Number of server interfaces, max. | 2 |
| OPC UA: Number of nodes for user-defined server interfaces, max. | 2 000 |
| Further protocols: MODBUS | Yes; MODBUS RTU/TCP |
Communication functions 5
| S7 communication: supported | Yes |
|---|---|
| S7 communication: as server | Yes |
| S7 communication: as client | Yes |
| S7 communication: User data per job, max. | See online help (S7 communication, user data size) |
| Number of connections: overall | PG Connections: 4 reserved; HMI Connections: 4 reserved / 82 max; S7 Connections: 78 max; Open User Connections: 78 max; Web Connections: 2 reserved / 80 max; Total Connections: 10 reserved / 88 max |
S7 message functions 8
| Number of login stations for message functions, max. | 32 |
|---|---|
| number of subscriptions, max. | 250 |
| number of tags/attributes for subscriptions, max. | 2 000 |
| Program alarms | Yes |
| Number of configurable program messages, max. | 5 000 |
| Number of loadable program messages in RUN, max. | 2 500 |
| Number of simultaneously active program alarms: Number of program alarms | 600 |
| Number of simultaneously active program alarms: Number of alarms for system diagnostics | 100 |
Test commissioning functions 15
| Status block | Yes; Up to 8 simultaneously (in total across all ES clients) |
|---|---|
| Single step | No |
| Profiling | Yes |
| Status/control: Status/control variable | Yes |
| Status/control: Variables | Inputs/outputs, memory bits, DBs, distributed I/Os, timers, counters |
| Number of variables, max.: of which status variables, max. | 200; per job |
| Number of variables, max.: of which control variables, max. | 200; per job |
| Forcing: Forcing | Yes |
| Forcing: Forcing, variables | Peripheral inputs/outputs |
| Forcing: Number of variables, max. | 200 |
| Diagnostic buffer: present | Yes |
| Diagnostic buffer: Number of entries, max. | 500 |
| Diagnostic buffer: of which powerfail-proof | 100 |
| Traces: Number of configurable Traces | 4 |
| Traces: Memory size per trace, max. | 512 kbyte |
Interrupts/diagnostics/status information 3
| Diagnostics indication LED: RUN/STOP LED | Yes |
|---|---|
| Diagnostics indication LED: ERROR LED | Yes |
| Diagnostics indication LED: MAINT LED | Yes |
Supported technology objects 17
| Motion Control | Yes |
|---|---|
| Number of available Motion Control resources for technology objects | 800 |
| Required Motion Control resources: per speed-controlled axis | 40 |
| Required Motion Control resources: per positioning axis | 80 |
| Required Motion Control resources: per synchronous axis | 160 |
| Required Motion Control resources: per external encoder | 80 |
| Required Motion Control resources: per output cam | 20 |
| Required Motion Control resources: per cam track | 160 |
| Required Motion Control resources: per probe | 40 |
| Required Motion Control resources: Number of available Extended Motion Control resources for technology objects | 40 |
| Required Extended Motion Control resources: per cam (1 000 points and 50 segments) | 2 |
| Required Extended Motion Control resources: for each set of kinematics | 30 |
| kinematics functions: kinematics with up to 4 interpolating axes | Yes |
| kinematics functions: kinematics with 5 or more interpolating axes | No |
| kinematics functions: user-defined kinematics | No |
| kinematics functions: SIMATIC Safe Kinematics | No |
| Positioning axis: Number of positioning axes at motion control cycle of 4 ms (typical value) | 10 |
Integrated Functions 10
| Counter | Yes |
|---|---|
| Number of counters | 8 |
| Counting frequency, max. | 100 kHz; Ia.0 to Ia.5: 100 kHz (80 kHz in quadrature mode), Ia.6 to Ib.5: 30 kHz (20 kHz in quadrature mode) |
| Frequency measurement | Yes |
| controlled positioning | Yes |
| Number of position-controlled positioning axes, max. | 8 |
| Number of positioning axes via pulse-direction interface | Up to 4 with SB 1222 |
| PID controller | Yes |
| Number of pulse outputs | 8; individually assigned to CPU and Signal Board |
| Limit frequency (pulse) | 100 kHz |
Potential separation 6
| Potential separation digital inputs: Potential separation digital inputs | Yes; field side to logic: 707 V DC (type test) |
|---|---|
| Potential separation digital inputs: between the channels | No |
| Potential separation digital inputs: Number of potential groups | 1 |
| Potential separation digital outputs: Potential separation digital outputs | Yes |
| Potential separation digital outputs: between the channels | No |
| Potential separation digital outputs: Number of potential groups | 1 |
EMC 5
| Interference immunity against discharge of static electricity: Interference immunity against discharge of static electricity acc. to IEC 61000-4-2 | Yes |
|---|---|
| Interference immunity to cable-borne interference: Interference immunity on supply lines acc. to IEC 61000-4-4 | Yes |
| Interference immunity against voltage surge: Interference immunity on supply lines acc. to IEC 61000-4-5 | Yes |
| Interference immunity against conducted variable disturbance induced by high-frequency fields: Interference immunity against high-frequency radiation acc. to IEC 61000-4-6 | Yes |
| Emission of radio interference acc. to EN 55 011: Limit class A, for use in industrial areas | Yes; Group 1 |
Degree and class of protection 1
| IP degree of protection | IP20 |
|---|
Standards, approvals, certificates 18
| Siemens Eco Profile (SEP) | Siemens EcoTech |
|---|---|
| CE mark | Yes |
| UL approval | Yes |
| cULus | Yes |
| FM approval | No |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| Marine approval | Yes |
| Ecological footprint: environmental product declaration Global warming potential | Yes; type 2 acc. to ISO 14021 |
| Ecological footprint: global warming potential, (total) [CO2 eq] | 68 kg |
| Ecological footprint: global warming potential, (during production) [CO2 eq] | 14.4 kg |
| Ecological footprint: global warming potential, (during operation) [CO2 eq] | 54.2 kg |
| Ecological footprint: global warming potential, (after end of life cycle) [CO2 eq] | -0.72 kg |
| Highest safety class achievable in safety mode: Performance level according to ISO 13849-1 | PLe |
| Highest safety class achievable in safety mode: SIL acc. to IEC 61508 Probability of failure (for service life of 20 years and repair time of 100 hours) | SIL 3 |
| Highest safety class achievable in safety mode: Low demand mode: PFDavg in accordance with SIL3 | < 2.00E-05 |
| Highest safety class achievable in safety mode: High demand/continuous mode: PFH in accordance | < 1.00E-09 up to an operational altitude of 3 000 m or < 2.00E-09 at an |
| with SIL3 | operating altitude greater than 3 000 m up to 5 000 m |
Security 3
| PROFINET Security Class | 1 |
|---|---|
| signed firmware update | Yes |
| Secure Boot | Yes |
Ambient conditions 17
| Free fall: Fall height, max. | 0.3 m; five times, in product package |
|---|---|
| Ambient temperature during operation: min. | -20 °C; No condensation |
| Ambient temperature during operation: max. | 40 °C; at max. voltages and max. specifications |
| Ambient temperature during operation: horizontal installation, min. | -20 °C; No condensation |
| Ambient temperature during operation: vertical installation, min. | -20 °C; No condensation |
| Ambient temperature during storage/transportation: min. | -40 °C |
| Ambient temperature during storage/transportation: max. | 70 °C |
| Air pressure acc. to IEC 60068-2-13: Operation, min. | 540 hPa |
| Air pressure acc. to IEC 60068-2-13: Operation, max. | 1 140 hPa |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, min. | 540 hPa |
| Air pressure acc. to IEC 60068-2-13: Storage/transport, max. | 1 140 hPa |
| Altitude during operation relating to sea level: Installation altitude, min. | -1 000 m |
| Relative humidity: Operation, max. | 95 %; no condensation |
| Vibrations: Vibration resistance during operation acc. to IEC 60068-2-6 | 3.5 mm from 5 - 8.4 Hz, 1g from 8.4 - 150 Hz |
| Vibrations: Operation, tested according to IEC 60068-2-6 | Yes |
| Shock testing: tested according to IEC 60068-2-27 | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms |
| Pollutant concentrations: SO2 at RH < 60% without condensation | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60 % condensation-free |
Configuration 16
| Programming Programming language: LAD | Yes; incl. failsafe |
|---|---|
| Programming Programming language: FBD | Yes; incl. failsafe |
| Programming Programming language: SCL | Yes |
| Know-how protection: User program protection/password protection | Yes |
| Know-how protection: Copy protection | No |
| Know-how protection: Block protection | Yes |
| Access protection: protection of confidential configuration data | Yes |
| Access protection: Protection level: Write protection | Yes |
| Access protection: Protection level: Read/write protection | Yes |
| Access protection: Protection level: Write protection for Failsafe | Yes |
| Access protection: Protection level: Complete protection | Yes |
| Access protection: User administration | Yes; device-wide and centralized |
| Access protection: Number of users | 100 |
| Access protection: Number of groups | 100 |
| Access protection: Number of roles | 50 |
| Cycle time monitoring: can be set | Yes |
Dimensions 3
| Width | 80 mm |
|---|---|
| Height | 125 mm |
| Depth | 100 mm |
Weights 1
| Weight, approx. | 352 g |
|---|
General Product Approval 2
| Miscellaneous Manufacturer Declara- | tion |
|---|---|
| TUEV China RoHS Manufacturer Declara- | tion |
Logistics 7
| Net weight | 0.352 kg |
|---|---|
| Package dimensions | 136 × 90 × 110 mm |
| Country of origin | CN |
| Shipping weight | 0.852 kg |
| Ships from | Türkiye |
| Dispatch | 13 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6ES7214-1AF50-0XB0
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE mark
- UL approval
- cULus
- RCM (formerly C-TICK)
- KC approval
- Marine approval
Quick answers
Questions about the CPU 1214FC DC/DC/DC
What is the rated current of CPU 1214FC DC/DC/DC?
The rated current of CPU 1214FC DC/DC/DC is 0.145 A.
Which supply voltage is CPU 1214FC DC/DC/DC rated for?
The rated operational voltage of CPU 1214FC DC/DC/DC is 24 V DC.
What is the HS code of CPU 1214FC DC/DC/DC for customs?
The tariff (HS) code on file for CPU 1214FC DC/DC/DC is 85371091.
What is the EAN of CPU 1214FC DC/DC/DC?
The EAN (GTIN) of CPU 1214FC DC/DC/DC is 4047623414797.
Where does CPU 1214FC DC/DC/DC ship from, and how fast?
CPU 1214FC DC/DC/DC ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Guides
Guides for PLC & controllers
Main Types of Programmable Logic Controllers: A Complete PLC Guide
Compare the 5 main PLC types, IEC 61131-3 languages, scan-time sizing, and brand options to choose the right controller for your plant. Shop at...
Programmable Logic Controller Guide: Selection, Application, and Maintenance for Engineers
PLC selection guide for engineers covering IEC 61131 compliance, Siemens, Rockwell, Schneider, ABB comparison, scan time sizing, and wiring. Shop at Stoklink.
Reviews
Customer reviews
Series
Siemens SIMATIC S7-1200
- Brand
- Siemens
- Series
- SIMATIC S7-1200
