Siemens 6ES7194-2LH10-1AA0 SIMATIC ET 200AL Power Cable M8 4-Pole 1m IP65/67 Remote I/O Accessory

% $-21.71
Siemens 6ES7194-2LH10-1AA0 SIMATIC ET 200AL power cable M8 straight - 1m 4-pole
Siemens 6ES7194-2LH10-1AA0 SIMATIC ET 200AL power cable M8 straight - 1m 4-pole

Siemens 6ES7194-2LH10-1AA0 SIMATIC ET 200AL Power Cable M8 4-Pole 1m IP65/67 Remote I/O Accessory

Brand: Siemens
Reference No: 6ES7194-2LH10-1AA0
Catalog No: 6ES7194-2LH10-1AA0
Series: SIMATIC ET 200
Tariff Code (HS): 85444290
Stock: 0
Delivery time: 10-15 business day(s)
Shipping Origin: Türkiye EXW
$21.71

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Siemens 6ES7194-2LH10-1AA0 is a preassembled M8 power cable that feeds 24 V DC to a SIMATIC ET 200AL remote I/O node over a 1 m run. Both ends carry a straight 4-pin M8 connector and socket, and the IP65/67 sealed cable body withstands wash-down and outdoor cabinet environments. The 52 mm continuous bending radius suits routing alongside adjacent station cabling.

Technical Specifications

SKU 6ES7194-2LH10-1AA0
Brand Siemens
Series SIMATIC ET 200AL
EAN 4047623402978
Product Type Designation Power cable
Product Description Flexible 4-core cable, preassembled at each end with a 4-pin M8 male / female connector
Suitability for Use For connection to ET 200AL for 24 V DC power supply
IP Degree of Protection IP65/67
Cable Designation 4 Li9Y 0.50 mm² Y
Cable Length 1 m
Number of Electrical Cores 4
Outer Diameter of Inner Conductor 0.8 mm
Outer Diameter of Core Insulation 1.46 mm
Outer Diameter of Cable Sheath 5.2 mm
Number of Bending Cycles 2,500,000 (52 mm bending radius, 3 m/s, 10 m/s²)
Permissible Bending Radius, Single Bend, Min. 26 mm
Permissible Bending Radius, Multiple Bends, Min. 52 mm
Bending Radius for Continuous Bending 52 mm
Color of Cable Sheath Gray
Color of Core Insulation White / brown / blue / black
Weight per Length 44 kg/km
Outgoing Feeder Type 180 degree cable outlet
Material of Cable Sheath PVC
Material of Core Insulation PP
Silicone-Free Yes
Ambient Temperature during Assembly -30 °C to 80 °C
Ambient Temperature during Storage/Transport -40 °C to 80 °C
Net Weight 0.06 kg
Country of Origin SK

Selection Notes

Choose this straight-connector version when the supply point and the ET 200AL node have enough clearance behind the M8 port for a 180-degree cable exit; it keeps the run flush along the mounting rail rather than projecting outward. At 1 m it bridges one full cabinet width or a short run between adjacent panels — for tighter clearance around the connector, the angled variant in this line is the better fit. The 4-pole M8 connector and IP65/67 rating match the ET 200AL station's own ingress protection.

Technical Details

Short Description
Siemens 6ES7194-2LH10-1AA0 - M8 power cable, straight, 4-pole, 1 m, IP65/67, for SIMATIC ET 200AL
Protection Type
IP65/67
Catalog No
6ES7194-2LH10-1AA0
Delivery Date (Days)
10-15 days
Model Number
6ES7194-2LH10-1AA0
Tariff Code
85444290
