The Siemens 6ES7193-6BP20-0BB1 is a SIMATIC ET 200SP BaseUnit, type B1, that supplies one I/O module slot with push-in terminals rated up to 10 A on the P1/P2 potential group and 5 A per process terminal. It carries 24 V DC or 230 V AC depending on the module installed and isolates the backplane bus from the supply voltage, letting the user start a new potential group at this slot.
Type B1 is delivered without auxiliary terminals and bridged to the left, so it continues the AUX-bus potential group of the preceding BaseUnit instead of starting a new one; pick an unbridged or isolating BaseUnit type instead when the station design needs to break the AUX-bus group at this slot. With 12 push-in process terminals and a 10 A P1/P2 rating, it accepts standard (non fail-safe) ET 200SP I/O modules with normal current draw; higher-current modules should be checked against this BaseUnit's 5 A per-terminal limit before assignment.
Carrying a standard ET 200SP digital or analog I/O module in a station where the AUX-bus potential group should continue unbroken from the neighboring slot, with push-in field wiring for the fastest terminal assembly.
| Product type designation | BU type B1 |
|---|---|
| HW functional status | FS10 and higher |
| Rated value (DC) | See manual |
|---|---|
| For P1 and P2 bus | 24 V |
| For AUX bus | 24 V; Equal potential group to P1/P2 bus or PE |
| for process terminals | 24 V |
| Rated value (AC) | See manual |
| external protection for power supply lines | Yes |
| Mains filter: Integrated | No |
| up to 60 °C, max. | 10 A |
|---|---|
| For P1 and P2 bus, max. | 10 A |
| For AUX bus, max. | 10 A |
| For process terminals, max. | 5 A |
| Part number | 6ES7193-6BP20-0BB1 |
|---|---|
| Type designation | BU type B1 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047623403272 |
| ETIM class | EC001598 |
| eCl@ss | 27242603 |
| Automatic encoding | Yes |
|---|---|
| Slots: Number of slots | 1 |
| between backplane bus and supply voltage | Yes |
|---|---|
| between process terminals and supply voltage | Yes; Not applicable for process terminals 9 to 12 |
| between power bus and supply voltage | Yes |
| Isolation tested with | 3 100 V DC |
|---|
| Ecological footprint: environmental product declaration Global warming potential | Yes |
|---|---|
| Ecological footprint: global warming potential, (total) [CO2 eq] | 0.873 kg |
| Ecological footprint: global warming potential, (during production) [CO2 eq] | 0.866 kg |
| Ecological footprint: global warming potential, (during operation) [CO2 eq] | 0 kg |
| Ecological footprint: global warming potential, (after end of life cycle) [CO2 eq] | -0.0011 kg |
| Ambient temperature during operation: horizontal installation, min. | -30 °C |
|---|---|
| Ambient temperature during operation: vertical installation, min. | -30 °C |
| Altitude during operation relating to sea level: Installation altitude above sea level, max. | 2 000 m; On request: Installation altitudes greater than 2 000 m |
| Absolute humidity: dew point, min. | -60 °C; suitable for dry room applications |
| Terminals: Terminal type | Push-in terminal |
|---|---|
| Terminals: system-integrated shield connection | No |
| Terminals: Conductor cross-section, min. | 0.14 mm2; AWG 26 |
| Terminals: Conductor cross-section, max. | 2.5 mm2; AWG 14 |
| Terminals: Number of process terminals to I/O module | 12; Pro slot |
| Terminals: Number of terminals to AUX bus | 0 |
| Terminals: Number of add-on terminals | 0 |
| Terminals: Number of terminals with connection to P1 and P2 bus | 0; Pro slot |
| Width | 20 mm |
|---|---|
| Height | 117 mm |
| Depth | 35 mm |
| Weight, approx. | 48 g |
|---|
| Net weight | 0.057 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.557 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 01 Nov 2026
No documents are on file for this part yet.
Ask us for the datasheetThe rated current of BU type B1 is 10 A.
The rated operational voltage of BU type B1 is 230 V AC.
The tariff (HS) code on file for BU type B1 is 85366990.
The EAN (GTIN) of BU type B1 is 4047623403272.
BU type B1 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
