The Siemens 6ES7155-6AU00-0DN0 is a SIMATIC ET 200SP High Speed PROFINET interface module (IM155-6PN HS) that operates up to 30 ET 200SP I/O modules per station with isochronous mode down to 125 microseconds and multi-hot-swap support. It runs from 24 V DC, integrates a 2-port PROFINET switch, supports IRT, MRP/MRPD media redundancy, and PROFIsafe, and ships with a server module included.
The HS (High Speed) variant supports isochronous mode down to a 125 microsecond bus cycle with 0.25 microsecond jitter, so it fits motion-adjacent decentralized I/O where a standard-speed interface module's longer cycle would not meet the timing budget. Multi-hot-swap lets individual I/O modules be replaced while the station stays in RUN, and shared device support for up to 4 IO controllers allows the 30 module slots to be split across separate PLCs. The BusAdapter is ordered separately and sets the physical port media (2x RJ45, 2x FC, 2x SCRJ, or mixed combinations), so match it to the plant's existing copper or fiber PROFINET cabling.
High-speed, isochronous decentralized I/O for motion-related machine control, multi-controller shared-device architectures, and ET 200SP stations that need online module replacement without stopping production.
| Product type designation | IM 155-6 PN HS |
|---|---|
| HW functional status | From FS02 |
| Firmware version | V4.0 |
| FW update possible | Yes |
| Product function: I&M data | Yes; I&M0 to I&M3 |
| Product function: Module swapping during operation (hot swapping) | Yes; Multi-hot swapping |
| Product function: Isochronous mode | Yes |
| Product function: IRT | Yes |
| Engineering with: STEP 7 TIA Portal configurable/integrated from version | V14 |
| Engineering with: STEP 7 configurable/integrated from version | V5.5 SP4 |
| Engineering with: PROFINET from GSD version/GSD revision | GSDML V2.45 |
| via dataset | Yes |
|---|
| Rated value (DC) | 24 V |
|---|---|
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| Short-circuit protection | Yes |
| Mains buffering: Mains/voltage failure stored energy time | 5 ms |
| Part number | 6ES7155-6AU00-0DN0 |
|---|---|
| Type designation | IM 155-6 PN HS |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4047623407805 |
| ETIM class | EC001604 |
| eCl@ss | 27242608 |
| Current consumption, max. | 500 mA |
|---|---|
| Inrush current, max. | 4.5 A |
| I2t | 0.09 A2·s |
| Power loss, typ. | 1.7 W |
|---|
| Address space per module: Address space per module, max. | 32 byte; For input and output data respectively |
|---|---|
| Address space per station: Address space per station, max. | 968 byte |
| Rack: Quantity of operable ET 200SP modules, max. | 30 |
|---|---|
| Rack: Quantity of operable ET 200AL modules, max. | 0 |
| Submodules: Number of submodules per station, max. | 125 |
| Transmission procedure | 100BASE-TX |
|---|---|
| Number of PROFINET interfaces | 1; 2 ports (switch) |
| Interface types: RJ 45 (Ethernet) | Yes; with BusAdapter |
|---|---|
| Interface types: Number of ports | 2; with BusAdapter |
| Interface types: integrated switch | Yes |
| Interface types: BusAdapter (PROFINET) | Yes; BA 2x RJ45, BA 2x FC, BA 2x SCRJ, BA SCRJ/RJ45, BA SCRJ/FC, BA 2x LC, BA LC/RJ45, BA LC/FC |
| Protocols: PROFINET IO Device | Yes |
| Protocols: Open IE communication | Yes |
| Protocols: Media redundancy | Yes; PROFINET MRP client / HRP client |
| PROFINET IO Device Services: IRT | Yes; 125 µs to 4 ms in 125 µs frame |
| PROFINET IO Device Services: Dynamic Frame Packing (DFP) | No |
| PROFINET IO Device Services: PROFIenergy | Yes |
| PROFINET IO Device Services: Prioritized startup | Yes |
| PROFINET IO Device Services: Shared device | Yes |
| PROFINET IO Device Services: Number of IO Controllers with shared device, max. | 4 |
| RJ 45 (Ethernet): Transmission procedure | PROFINET with 100 Mbit/s full duplex (100BASE-TX) |
|---|---|
| RJ 45 (Ethernet): 100 Mbps | Yes |
| RJ 45 (Ethernet): Autonegotiation | Yes |
| RJ 45 (Ethernet): Autocrossing | Yes |
| Supports protocol for PROFINET IO | Yes |
|---|---|
| PROFIsafe | Yes |
| PROFIBUS | No |
| EtherNet/IP | No |
| Modbus TCP | No |
| Redundancy mode: PROFINET system redundancy (S2) | No |
| Redundancy mode: PROFINET system redundancy (R1) | No |
| Redundancy mode: H-Sync forwarding Media redundancy | Yes |
| Redundancy mode: MRP | Yes |
| Redundancy mode: MRPD | Yes |
| Open IE communication: TCP/IP | Yes |
| Open IE communication: SNMP | Yes |
| Open IE communication: LLDP | Yes |
| Equidistance | Yes |
|---|---|
| shortest clock pulse | 125 µs |
| max. cycle | 4 ms |
| Bus cycle time (TDP), min. | 125 µs |
| Jitter, max. | 0.25 µs |
| Status indicator | Yes |
|---|---|
| Alarms | Yes |
| Diagnostics function | Yes |
| Diagnostics indication LED: RUN LED | Yes; green LED |
| Diagnostics indication LED: ERROR LED | Yes; red LED |
| Diagnostics indication LED: MAINT LED | Yes; Yellow LED |
| Diagnostics indication LED: Monitoring of the supply voltage (PWR-LED) | Yes; green PWR LED |
| Diagnostics indication LED: Connection display LINK TX/RX | Yes; 2x green link LEDs on BusAdapter |
| between backplane bus and electronics | No |
|---|---|
| between PROFINET and all other circuits | Yes; 1500 V AC (type test) |
| between supply and all other circuits | No |
| between different circuits | Safety extra low voltage SELV |
|---|
| Isolation tested with | 707 V DC (type test) |
|---|
| Network loading class | 3 |
|---|---|
| Ecological footprint: environmental product declaration Global warming potential | Yes |
| Ecological footprint: global warming potential, (total) [CO2 eq] | 105 kg |
| Ecological footprint: global warming potential, (during production) [CO2 eq] | 13.7 kg |
| Ecological footprint: global warming potential, (during operation) [CO2 eq] | 91.9 kg |
| Ecological footprint: global warming potential, (after end of life cycle) [CO2 eq] | -0.617 kg |
| PROFINET Security Class | 1 |
|---|
| Ambient temperature during operation: horizontal installation, min. | -25 °C; No condensation |
|---|---|
| Ambient temperature during operation: vertical installation, min. | -25 °C; No condensation |
| Altitude during operation relating to sea level: Installation altitude above sea level, max. | 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual |
| Absolute humidity: dew point, min. | -60 °C; suitable for dry room applications |
| ET-Connection: via BU/BA Send | No |
|---|
| Width | 50 mm |
|---|---|
| Height | 117 mm |
| Depth | 74 mm |
| Weight, approx. | 147 g; without BusAdapter |
|---|
| Net weight | 0.195 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.695 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 01 Nov 2026
No documents are on file for this part yet.
Ask us for the datasheetThe rated operational voltage of IM 155-6 PN HS is 24 V AC.
The tariff (HS) code on file for IM 155-6 PN HS is 85176200.
The EAN (GTIN) of IM 155-6 PN HS is 4047623407805.
IM 155-6 PN HS ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
