Part number
6ES7148-6JE00-0BB0
$645.84 On request Dispatch — · From TürkiyeGet a Quote
SIMATIC ET 200eco

Siemens 6ES7148-6JE00-0BB0 SIMATIC ET 200eco PN CM 4x IO-Link DIQ 12x M12-L Remote I/O Module

Siemens ET 200eco PN module, 4x IO-Link + 12x DIQ, PROFINET/EtherNet IP/Modbus TCP, IP67/IP69K.

Rated current
2 A
Rated operational voltage
24 V DC
Communication
PROFINET IO, EtherNet/IP, Modbus TCP, IO-Link 1.0/1.1
EAN
4047623411802
Description

About the 6ES7148-6JE00-0BB0

The Siemens 6ES7148-6JE00-0BB0 is a SIMATIC ET 200eco PN combination module with 4 IO-Link ports and 12 parameterizable digital I/O channels rated 0.5 A or 2 A, housed in an IP67/IP69K M12-L enclosure for mounting on the machine. It runs PROFINET IO with EtherNet/IP and Modbus TCP together, supports S2 system redundancy and MRP, and gives shared-device access to up to 2 controllers.

Selection Notes

The 12 parameterizable DIQ channels, in 4-channel groups at 0.5 A or 2 A per channel, give more conventional digital I/O than the sibling combination module that trades DIQ count for extra IO-Link ports; pick this variant when most field devices are still hard-wired sensors and actuators rather than IO-Link. Total output current is capped at 7.5 A per module, 5.5 A on the 2L+ group, so tally connected loads before assigning more than a few 2 A outputs to one unit. Dual-protocol support, PROFINET IO plus EtherNet/IP or Modbus TCP, with S2 system redundancy lets it serve as a shared I/O drop for two independent controllers, useful where a line runs both a Siemens and a third-party PLC.

Specification

Full specification

209 values · Last verified 01 Nov 2026

General information 19

HW functional status From FS03
Firmware version V5.1.x
FW update possible Yes
Vendor identification (VendorID) 002 AH
Device identifier (DeviceID) 0306 H
Manufacturer ID according to ODVA (VendorID) 04E3H
Device ID according to ODVA (Product code) 0 FADH
Product function: I&M data Yes; I&M0 to I&M3
Product function: Isochronous mode No
Product function: IRT Yes
Product function: Prioritized startup Yes
Engineering with: STEP 7 TIA Portal configurable/integrated from version STEP 7 V17 or higher with HSP 0378
Engineering with: PROFINET from GSD version/GSD revision GSDML V2.4.x
Engineering with: Multi Fieldbus Configuration Tool (MFCT) V1.4.1 or higher
Operating mode: IO-Link Yes
Operating mode: DI Yes
Operating mode: DQ Yes
Operating mode: MSI Yes
Operating mode: MSO Yes

Supply voltage 9

power supply according to NEC Class 2 required No
Load voltage 1L+: Rated value (DC) 24 V
Load voltage 1L+: permissible range, lower limit (DC) 20.4 V
Load voltage 1L+: permissible range, upper limit (DC) 28.8 V
Load voltage 1L+: Reverse polarity protection Yes; against destruction
Load voltage 2L+: Rated value (DC) 24 V
Load voltage 2L+: permissible range, lower limit (DC) 20.4 V
Load voltage 2L+: permissible range, upper limit (DC) 28.8 V
Load voltage 2L+: Reverse polarity protection Yes; against destruction

Input current 3

Current consumption (rated value) 70 mA; without load
from load voltage 1L+ (unswitched voltage) 12 A; Maximum value
from load voltage 2L+, max. 12 A; Maximum value
Show all 209 specifications ↓ Show less ↑178 more values in Identification, Encoder supply, Power loss, Address area, Hardware configuration, Digital inputs, Digital outputs, Encoder, IO-Link, Interfaces, 1. Interface, Interface types, Protocols, Interrupts/diagnostics/status information, Potential separation, Isolation, Degree and class of protection, Standards, approvals, certificates, Security, Ambient conditions, Connection method, Dimensions, Version Classification, For use in hazard-Maritime application ous locations, Logistics.

Identification 9

Part number 6ES7148-6JE00-0BB0
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4047623411802
ETIM class EC001604
eCl@ss 27242608

Encoder supply 3

Number of outputs 4
24 V encoder supply: Short-circuit protection Yes; per channel, electronic
24 V encoder supply: Output current, max. 2 A; Per channel

Power loss 1

Power loss, typ. 9.7 W

Address area 2

Address space per module: Inputs 146 byte; + 8 bytes for QI information
Address space per module: Outputs 130 byte

Hardware configuration 1

Submodules: Number of configurable submodules, max. 6

Digital inputs 12

Number of digital inputs 12; Parameterizable as DIQ
in groups of 4
Digital inputs, parameterizable Yes
Sourcing/sinking input P-reading
Input characteristic curve in accordance with IEC 61131, type 3 Yes
Number of simultaneously controllable inputs all mounting positions: up to 60 °C, max. 12
Input voltage: Rated value (DC) 24 V
Input voltage: for signal "0" -3 to +5V
Input voltage: for signal "1" +11 to +30V
Input current: for signal "1", typ. 2.5 mA
Input delay (for rated value of input voltage) for standard inputs: parameterizable Yes; 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms
Cable length: unshielded, max. 30 m

Digital outputs 27

Number of digital outputs 12; Parameterizable as DIQ
in groups of 2 load groups for 4 or 8 outputs each
Current-sourcing Yes
output type acc. to IEC 61131, type 0.5 Yes
Short-circuit protection Yes; per channel, electronic
Response threshold, typ. 0.5 A: 1 A / 2 A: 3 A
Limitation of inductive shutdown voltage to 0.5 A: Type 1L+ (-70 V) / 2 A: Type (-18 V)
Controlling a digital input Yes
Switching capacity of the outputs: with resistive load, max. 0.5 A / 2 A
Switching capacity of the outputs: with inductive load, max. 0.5 A / 2 A
Switching capacity of the outputs: on lamp load, max. 0.5 A: 5 W / 2 A 10 W
Load resistance range: lower limit 0.5 A: 48 ohms / 2 A: 12 ohms
Load resistance range: upper limit 4 kΩ
Output voltage: for signal "1", min. 1L+ (-0.8 V) / 2L+ (-0.8 V)
Output current: for signal "1" rated value 0.5 A / 2 A
Output current: for signal "1" permissible range, max. 0.5 A / 2 A
Output current: for signal "0" residual current, max. 0.1 mA
Output delay with resistive load: "0" to "1", max. 0.5 A: 100 µs / 2 A: 150 µs; at rated load
Output delay with resistive load: "1" to "0", max. 0.5 A: 150 µs / 2 A: 2.5 ms; at rated load
Parallel switching of two outputs: for uprating No
Parallel switching of two outputs: for redundant control of a load Yes
Switching frequency: with resistive load, max. 0.5 A: 100 Hz / 2 A: 40 Hz
Switching frequency: with inductive load, max. 0.5 Hz
Switching frequency: on lamp load, max. 1 Hz
Total current of the outputs: Current per group, max. 1L+: 2 A / 2L+: 5.5 A
Total current of the outputs: Current per module, max. 7.5 A
Cable length: unshielded, max. 30 m

Encoder 2

Connectable encoders: 2-wire sensor Yes
Connectable encoders: permissible quiescent current (2-wire sensor), max. 1.5 mA

Interfaces 2

Transmission procedure 100BASE-TX
Number of PROFINET interfaces 1

1. Interface 10

Interface type PROFINET with 100 Mbit/s full duplex (100BASE-TX)
Interface types: M12 port Yes; 2x M12, 4-pin, D-coded
Interface types: Number of ports 2
Interface types: integrated switch Yes
Protocols: PROFINET IO device Yes
Protocols: Open IE communication Yes
PROFINET IO Device Services: IRT Yes; 250 µs to 4 ms in 125 µs frame
PROFINET IO Device Services: Prioritized startup Yes
PROFINET IO Device Services: Shared device Yes
PROFINET IO Device Services: Number of IO Controllers with shared device, max. 2

Interface types 3

M12 port: Autonegotiation Yes
M12 port: Autocrossing Yes
M12 port: Transmission rate, max. 100 Mbit/s

Protocols 36

Supports protocol for PROFINET IO Yes
PROFIsafe No
EtherNet/IP Yes
Modbus TCP Yes
Redundancy mode: PROFINET system redundancy (S2) Yes
Redundancy mode: on S7-1500R/H Yes
Redundancy mode: on S7-400H Yes
Redundancy mode: PROFINET system redundancy (R1) No
Redundancy mode: H-Sync forwarding Media redundancy Yes
Redundancy mode: MRP Yes
Redundancy mode: MRPD No
EtherNet/IP Services: CIP Implicit Messaging Yes
EtherNet/IP Services: CIP Explicit Messaging Yes
EtherNet/IP Services: CIP Safety No
EtherNet/IP Services: Shared device Yes; 2x EtherNet/IP Scanner
EtherNet/IP Services: Number of scanners with shared device, max. Updating times 2
EtherNet/IP Services: Requested Packet Interval (RPI) Redundancy mode 2 ms
EtherNet/IP Services: DLR (Device Level Ring) Address area No
EtherNet/IP Services: Address space per module, max. 300 byte
EtherNet/IP Services: LargeForwardOpen (Class3) No
Modbus TCP Services: read coils (code=1) Yes
Modbus TCP Services: read discrete inputs (code=2) Yes
Modbus TCP Services: Read Holding Registers (Code=3) Yes
Modbus TCP Services: write single coil (code=5) Yes
Modbus TCP Services: write multiple coils (code=15) Yes
Modbus TCP Services: Write Multiple Registers (Code=16) Yes
Modbus TCP Services: Parameter change by master No
Modbus TCP Services: Modbus TCP Security Protocol Address space per station No
Modbus TCP Services: Address space per station, max. 300 byte
Modbus TCP Services: Access-consistent address space Updating time 2 byte
Modbus TCP Services: I/O request interval Connections 2 ms
Modbus TCP Services: number of connections per device 12
Open IE communication: TCP/IP Yes; (only EtherNet/IP or Modbus TCP)
Open IE communication: SNMP Yes
Open IE communication: LLDP Yes
Open IE communication: ARP Yes

Interrupts/diagnostics/status information 20

Substitute values connectable Yes
Alarms: Diagnostic alarm Yes; Parameterizable
Alarms: Maintenance interrupt Yes; Parameterizable
Alarms: Hardware interrupt Yes; Parameterizable
Diagnoses: Diagnostic information readable Yes
Diagnoses: Monitoring the supply voltage Yes
Diagnoses: parameterizable Yes
Diagnoses: Wire break Yes; DI, input current < 0.3 mA, per channel
Diagnoses: Short-circuit encoder supply Yes; Per channel
Diagnostics indication LED: RUN LED Yes; green LED
Diagnostics indication LED: ERROR LED Yes; red LED
Diagnostics indication LED: MAINT LED Yes; Yellow LED
Diagnostics indication LED: Monitoring of the supply voltage (PWR-LED) Yes; green LED
Diagnostics indication LED: NS LED Yes; green/red LED
Diagnostics indication LED: MS LED Yes; green/red LED
Diagnostics indication LED: IO LED Yes; red-green-yellow LED
Diagnostics indication LED: Channel status display Yes; green LED
Diagnostics indication LED: for channel diagnostics Yes; red LED
Diagnostics indication LED: For load voltage monitoring Yes; green LED
Diagnostics indication LED: Connection display LINK TX/RX Yes; green LED, only link

Potential separation 5

between the load voltages Yes
between Ethernet and electronics Yes
Potential separation channels: between the channels Yes
Potential separation channels: between the channels and the power supply of the 8 channels are non-isolated and 8 channels are isolated from supply voltage
electronics 1L+

Isolation 2

tested with: 24 V DC circuits 707 V DC (type test)
tested with: Test voltage for interface, rms value [Vrms] 1 500 V; According to IEEE 802.3

Degree and class of protection 1

IP degree of protection IP65/67/69K

Standards, approvals, certificates 4

Suitable for safety-related tripping of standard modules Yes; from FS01
Highest safety class achievable for safety-related tripping of standard modules: Performance level according to ISO 13849-1 PL d
Use in hazardous areas: Explosion protection category for gas ATEX, UKEX, IECEx, CCCEx for Zone 2
Use in hazardous areas: Explosion protection category for dust ATEX, UKEX, IECEx, CCCEx for Zone 22

Security 2

signed firmware update Yes
securely removing data Yes

Ambient conditions 3

Ambient temperature during operation: min. -40 °C
Ambient temperature during operation: max. 60 °C
Altitude during operation relating to sea level: Ambient air temperature-barometric pressure-altitude Up to max. 5 000 m, at installation height > 2 000 m additional restrictions

Connection method 3

Design of electrical connection 4/5-pin M12 circular connectors
Design of electrical connection for the inputs and outputs M12, 5-pin, A-coded
Design of electrical connection for supply voltage M12, 4-pin, L-coded

Dimensions 1

Width 45 mm

Version Classification 2

eClass 16 27-24-26-08
ETIM 10 EC001604

For use in hazard-Maritime application ous locations 1

CCC-Ex NK / Nippon Kaiji Ky-Food, Pharmaceut- okai

Logistics 6

Net weight 0.823 kg
Country of origin DE
Shipping weight 1.323 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 01 Nov 2026

Documents

Documents for 6ES7148-6JE00-0BB0

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the 6ES7148-6JE00-0BB0

What is the rated current of 6ES7148-6JE00-0BB0?

The rated current of 6ES7148-6JE00-0BB0 is 2 A.

Which supply voltage is 6ES7148-6JE00-0BB0 rated for?

The rated operational voltage of 6ES7148-6JE00-0BB0 is 24 V DC.

What is the HS code of 6ES7148-6JE00-0BB0 for customs?

The tariff (HS) code on file for 6ES7148-6JE00-0BB0 is 85389091.

What is the EAN of 6ES7148-6JE00-0BB0?

The EAN (GTIN) of 6ES7148-6JE00-0BB0 is 4047623411802.

Where does 6ES7148-6JE00-0BB0 ship from, and how fast?

6ES7148-6JE00-0BB0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.

Guides

Guides for PLC & controllers

All guides for PLC & controllers
Reviews

Customer reviews

Series

Siemens SIMATIC ET 200eco

Brand
Siemens
Series
SIMATIC ET 200eco
$645.84 On request
Get a Quote
Quote

Get a Quote

Genuine parts

Genuine, factory-sealed parts

Siemens · 6ES7148-6JE00-0BB0

Every part on Stoklink is new, unused and made by the manufacturer named on the page.

Condition
New and unused, in the manufacturer's factory-sealed packaging.
Sourced from
Siemens and its authorised distributors.
Warranty
The manufacturer's warranty applies.
If a part is not genuine
We refund the full amount.

Added to cart Could not add to cart

View cart
