Part number
6ES7148-4FS00-0AB0
$604.90 On request Dispatch — · From TürkiyeGet a Quote
SIMATIC ET 200pro

Siemens 6ES7148-4FS00-0AB0 SIMATIC ET 200pro F-Switch PROFIsafe 6A Fail-safe I/O Module

Siemens F-Switch fail-safe module for SIMATIC ET 200pro, 3 PP switching outputs, 2 safety inputs, 6A, SIL3.

Rated current
6 A
Rated operational voltage
24 V DC
Communication
PROFIsafe
EAN
4025515075219
Description

About the 6ES7148-4FS00-0AB0

The Siemens 6ES7148-4FS00-0AB0 is an F-Switch electronic module for the SIMATIC ET 200pro distributed I/O system, with 3 fail-safe PP switching outputs that safely disconnect the 2L+, F0 and F1 backplane busbars plus 2 fail-safe digital inputs. Rated up to 6 A across mounting positions and PL e / SIL 3 over PROFIsafe, it isolates power to downstream I/O groups instead of switching a field load directly.

Selection Notes

Unlike the F-DI and F-DI/F-DO modules, the F-Switch does not read or drive field-level signals; its 3 PP outputs switch the 2L+, F0 and F1 backplane busbars themselves, so a single safety command removes power from every standard module downstream of it on the station. Use it as the safe power-off point for a machine zone instead of wiring individual output modules to cut power channel by channel. Its 45 mm width matches the standard, non-safety ET 200pro modules, so it does not need the extra backplane space the wider F-DI/F-DO modules require.

Applications

F-Switch modules sit at the head of a zone on the ET 200pro backplane, ahead of the standard I/O modules that need to lose power when a guard opens or an e-stop trips, giving that zone its own safety power cutoff without a separate contactor in the cabinet.

Specification

Full specification

35 values · Last verified 01 Nov 2026

Supply voltage 2

Rated value (DC) 24 V
power supply according to NEC Class 2 required No

Input current 3

from supply voltage 1L+, max. 50 mA
from load voltage 2L+ (without load), max. 25 mA; Typical
from backplane bus 3.3 V DC, max. 40 mA

Power loss 1

Power loss, typ. 3 W
Show all 35 specifications ↓ Show less ↑29 more values in Identification, Digital inputs, Digital outputs, Standards, approvals, certificates, Dimensions, EClass 7.1 27-24-26-04, Logistics.

Identification 9

Part number 6ES7148-4FS00-0AB0
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4025515075219
ETIM class EC001599
eCl@ss 27242604

Digital inputs 2

Number of digital inputs 2
Input current: for signal "1", typ. 3.5 mA

Digital outputs 3

Number of digital outputs 3
Short-circuit protection Yes
Total current of the outputs (per group) all mounting positions: up to 55 °C, max. 6 A

Standards, approvals, certificates 2

Highest safety class achievable in safety mode: Performance level according to ISO 13849-1 e
Highest safety class achievable in safety mode: SIL acc. to IEC 61508 3

Dimensions 3

Width 45 mm
Height 130 mm
Depth 65 mm

EClass 7.1 27-24-26-04 4

eClass 6 27-24-26-04
ETIM 10 EC001599
IDEA 4 3566
UNSPSC 15 32-15-17-05

Logistics 6

Net weight 0.196 kg
Country of origin DE
Shipping weight 0.696 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 01 Nov 2026

Documents

Documents for 6ES7148-4FS00-0AB0

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the 6ES7148-4FS00-0AB0

What is the rated current of 6ES7148-4FS00-0AB0?

The rated current of 6ES7148-4FS00-0AB0 is 6 A.

Which supply voltage is 6ES7148-4FS00-0AB0 rated for?

The rated operational voltage of 6ES7148-4FS00-0AB0 is 24 V DC.

What is the HS code of 6ES7148-4FS00-0AB0 for customs?

The tariff (HS) code on file for 6ES7148-4FS00-0AB0 is 85389091.

What is the EAN of 6ES7148-4FS00-0AB0?

The EAN (GTIN) of 6ES7148-4FS00-0AB0 is 4025515075219.

Where does 6ES7148-4FS00-0AB0 ship from, and how fast?

6ES7148-4FS00-0AB0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
