Part number
6ES7148-4FC00-0AB0
$931.50 On request Dispatch — · From TürkiyeGet a Quote
SIMATIC ET 200pro

Siemens 6ES7148-4FC00-0AB0 SIMATIC ET 200pro F-DI/F-DO 8/4 24V DC/2A Fail-safe I/O Module

Siemens fail-safe F-DI/F-DO module for SIMATIC ET 200pro, 8 safety inputs, 4 safety outputs, 24V DC/2A, SIL3.

Rated current
2 A
Rated operational voltage
24 V DC
Communication
PROFIsafe
EAN
4025515073055
Description

About the 6ES7148-4FC00-0AB0

The Siemens 6ES7148-4FC00-0AB0 is a combined fail-safe F-DI/F-DO electronic module for the SIMATIC ET 200pro distributed I/O system, with 8 safety digital inputs and 4 safety digital outputs rated 24 V DC at 2 A per channel over PROFIsafe. It is rated Performance Level e per ISO 13849-1 and SIL 3 per IEC 61508, combining input sensing and output switching for a safety loop in one module.

Selection Notes

Combining 8 F-DI and 4 F-DO channels in one 90 mm module lets a safety circuit read guard switches and drive its own output relays or contactor coils from the same PROFIsafe telegram, instead of pairing separate F-DI and F-DO modules. At 2 A per output channel it can switch small contactors or safety relay coils directly; loads above that still need an interposing relay. Like the F-DI-only sibling module in this series, it reaches PL e / SIL 3, so a mixed input/output safety function does not have to drop to a lower integrity level.

Applications

This combination fits machine zones where a guard door or light curtain both signals a stop condition and needs its own local output, such as latching a door lock or a zone contactor, without routing the output back through a separate module or the main safety PLC.

Specification

Full specification

37 values · Last verified 01 Nov 2026

Supply voltage 2

Rated value (DC) 24 V
power supply according to NEC Class 2 required No

Input current 3

from supply voltage 1L+, max. 100 mA; Typical
from load voltage 2L+ (without load), max. 50 mA; Typical
from backplane bus 3.3 V DC, max. 20 mA

Power loss 1

Power loss, typ. 5.8 W
Show all 37 specifications ↓ Show less ↑31 more values in Identification, Digital inputs, Digital outputs, Standards, approvals, certificates, Dimensions, EClass 7.1 27-24-26-04, Functional Saftey Maritime application, Logistics.

Identification 9

Part number 6ES7148-4FC00-0AB0
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4025515073055
ETIM class EC001599
eCl@ss 27242604

Digital inputs 2

Number of digital inputs 8
Input current: for signal "1", typ. 3.7 mA

Digital outputs 4

Number of digital outputs 4
Short-circuit protection Yes
Controlling a digital input Yes; digital output, according to IEC 61131-2, type 2
Output current: for signal "1" rated value 2 A

Standards, approvals, certificates 2

Highest safety class achievable in safety mode: Performance level according to ISO 13849-1 e
Highest safety class achievable in safety mode: SIL acc. to IEC 61508 3

Dimensions 3

Width 90 mm
Height 130 mm
Depth 65 mm

EClass 7.1 27-24-26-04 4

eClass 6 27-24-26-04
ETIM 10 EC001599
IDEA 4 3566
UNSPSC 15 32-15-17-05

Functional Saftey Maritime application 1

TUEV NK / Nippon Kaiji Ky- okai

Logistics 6

Net weight 0.316 kg
Country of origin DE
Shipping weight 0.816 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 01 Nov 2026

Documents

Documents for 6ES7148-4FC00-0AB0

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the 6ES7148-4FC00-0AB0

What is the rated current of 6ES7148-4FC00-0AB0?

The rated current of 6ES7148-4FC00-0AB0 is 2 A.

Which supply voltage is 6ES7148-4FC00-0AB0 rated for?

The rated operational voltage of 6ES7148-4FC00-0AB0 is 24 V DC.

What is the HS code of 6ES7148-4FC00-0AB0 for customs?

The tariff (HS) code on file for 6ES7148-4FC00-0AB0 is 85389091.

What is the EAN of 6ES7148-4FC00-0AB0?

The EAN (GTIN) of 6ES7148-4FC00-0AB0 is 4025515073055.

Where does 6ES7148-4FC00-0AB0 ship from, and how fast?

6ES7148-4FC00-0AB0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
