The Siemens 6ES7142-4BF00-0AA0 is a SIMATIC ET 200pro digital output module providing 8 channels rated 0.5 A at 24 V DC, each short-circuit protected and current-sourcing per IEC 61131 type 0.5. Suitable for safety-related tripping of standard modules up to Performance Level d (Category 3, ISO 13849-1) and SIL 2 (IEC 62061), the outputs switch resistive loads at up to 100 Hz.
The 0.5 A per-channel rating and current-sourcing output stage suit small DC loads such as indicator lamps and pilot relay coils rather than motor contactors; two outputs can be paralleled for redundant control of a single load. Because the module is suitable for safety-related tripping of standard modules to PL d / SIL 2, a fail-safe CPU can switch a standard (non-F) actuator through this channel without a dedicated F-DQ module, provided the rest of the safety chain meets the same category. The module still needs its own bus module and I/O connection module, ordered separately.
Actuator and indicator control in distributed SIMATIC ET 200pro stations - pilot lamps, small relays, and solenoids on 24 V DC machine and process lines, including outputs that must trip from a safety PLC's standard channel.
| Load voltage 2L+: Rated value (DC) | 24 V |
|---|---|
| Load voltage 2L+: Short-circuit protection | Yes; per channel, electronic |
| Load voltage 2L+: Reverse polarity protection | Yes; against destruction; load increasing |
| from load voltage 2L+ (without load), max. | 30 mA |
|---|---|
| from backplane bus 3.3 V DC, max. | 30 mA |
| Power loss, typ. | 2 W |
|---|
| Part number | 6ES7142-4BF00-0AA0 |
|---|---|
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4025515073833 |
| ETIM class | EC001599 |
| eCl@ss | 27242604 |
| Address space per module: Address space per module, max. | 1 byte |
|---|
| Number of digital outputs | 8 |
|---|---|
| Current-sourcing | Yes |
| output type acc. to IEC 61131, type 0.5 | Yes |
| Short-circuit protection | Yes |
| Response threshold, typ. | 0.7 A |
| Limitation of inductive shutdown voltage to | 2L+ (-47 V) |
| Controlling a digital input | Yes; Isolation between 1L+ and 2L+ is no longer provided, as 1M and 2M are jumpered |
| Switching capacity of the outputs: on lamp load, max. | 5 W |
| Load resistance range: lower limit | 48 Ω |
| Load resistance range: upper limit | 4 kΩ |
| Output voltage: for signal "1", min. | 2L+ (-0,8 V) |
| Output current: for signal "1" rated value | 0.5 A |
| Output current: for signal "0" residual current, max. | 0.5 mA |
| Parallel switching of two outputs: for uprating | No |
| Parallel switching of two outputs: for redundant control of a load | Yes |
| Switching frequency: with resistive load, max. | 100 Hz |
| Switching frequency: with inductive load, max. | 0.5 Hz |
| Switching frequency: on lamp load, max. | 1 Hz |
| Total current of the outputs (per group) all mounting positions: up to 55 °C, max. | 4 A |
| Cable length: shielded, max. | 30 m |
| Cable length: unshielded, max. | 30 m |
| Diagnostics function | Yes |
|---|---|
| Alarms: Diagnostic alarm | Yes |
| Diagnoses: Diagnostic information readable | Yes |
| Diagnoses: Short-circuit | Yes; Short-circuit of outputs to ground; module by module |
| Diagnostics indication LED: Group error SF (red) | Yes |
| Diagnostics indication LED: Status indicator digital output (green) | Yes |
| between backplane bus and all other circuit components | Yes |
|---|---|
| Potential separation digital outputs: between the channels | No |
| Potential separation digital outputs: between the channels and backplane bus | Yes |
| Isolation tested with | 707 V DC (type test) |
|---|
| Suitable for safety-related tripping of standard modules | Yes |
|---|---|
| Highest safety class achievable for safety-related tripping of standard modules: Performance level according to ISO 13849-1 | PL d |
| Width | 45 mm |
|---|---|
| Height | 130 mm |
| Depth | 35 mm |
| Weight, approx. | 140 g |
|---|
| Net weight | 0.175 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.675 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | Critical stock |
