The Siemens 6ES7134-7TD50-0AB0 is an ET200iSP electronic module with 4 analog inputs for HART 4-wire transmitters, rated Ex ib [ia Ga] IIC T4 Gb for direct installation in hazardous Zone 1 areas. It supports HART protocol version 6.0, integrates a fieldbus transceiver, and delivers 12-bit resolution with a 30 ms basic conversion time per channel.
The Ex ib [ia Ga] IIC T4 Gb rating places this module in Zone 1 gas-hazardous areas and Zone 21 dust areas — the 'ib' protection level, unlike 'ia', is rated for a single-fault condition rather than a fault-free enclosure, which matches typical process-industry field cabinets rather than Zone 0 locations. The 4-wire HART input wiring, rather than 2-wire loop-powered, is the deciding factor over other ET200iSP analog input variants: it suits transmitters with a separate power source instead of loop-powered instruments. Cable runs up to 500 m shielded keep the module usable for transmitters mounted well away from the I/O station.
Analog measurement input for HART 4-wire transmitters — pressure, level, flow, temperature — in Ex Zone 1 gas or Zone 21 dust process areas such as chemical, oil and gas, or pharmaceutical plants.
| Product type designation | 4AI I 4WIRE HART |
|---|---|
| HW functional status | 15 |
| Firmware version | V3.0.4 |
| Product function: Isochronous mode | No |
| Reparameterization possible in RUN | Yes |
|---|
| Rack mounting | No |
|---|---|
| Front mounting | Yes |
| Rail mounting | Yes |
| Wall mounting/direct mounting | No |
| Part number | 6ES7134-7TD50-0AB0 |
|---|---|
| Type designation | 4AI I 4WIRE HART |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4019169131674 |
| ETIM class | EC001596 |
| eCl@ss | 27242601 |
| Type of supply voltage | DC |
|---|---|
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Current consumption, typ. | 27 mA |
|---|---|
| from load voltage (power bus), max. | 30 mA |
| Power loss, typ. | 0.4 W |
|---|
| Fieldbus connection via separate transceiver | Yes |
|---|
| Number of analog inputs | 4 |
|---|---|
| permissible input current for current input (destruction limit), max. | 50 mA |
| Cycle time (all channels) max. | 120 ms; 30 ms basic conversion time x4 channels with 60 Hz, 50 Hz interference frequency suppression |
| Technical unit for temperature measurement adjustable | Yes |
| Input ranges: Voltage | No |
| Input ranges: Current | Yes |
| Input ranges: Thermocouple | No |
| Input ranges: Resistance thermometer | No |
| Input ranges: Resistance | No |
| Input ranges (rated values), currents: 4 mA to 20 mA | Yes |
| Input ranges (rated values), currents: Input resistance (4 mA to 20 mA) | 295 Ω |
| Cable length: shielded, max. | 500 m |
| Measurement principle | integrating (Sigma-Delta) |
|---|---|
| Integration and conversion time/resolution per channel: Resolution with overrange (bit including sign), max. | 12 bit; + sign |
| Integration and conversion time/resolution per channel: Integration time, parameterizable | Yes |
| Integration and conversion time/resolution per channel: Basic conversion time, including integration time (ms) | 30 ms |
| Integration and conversion time/resolution per channel: Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz |
| Smoothing of measured values: parameterizable | Yes; in 4 stages |
| Smoothing of measured values: Step: None | Yes; 1x cycle time |
| Smoothing of measured values: Step: low | Yes; 4x cycle time |
| Smoothing of measured values: Step: Medium | Yes; 32x cycle time |
| Smoothing of measured values: Step: High | Yes; 64x cycle time |
| Connection of signal encoders: for current measurement as 4-wire transducer | Yes |
|---|
| Linearity error (relative to input range), (+/-) | 0.015 % |
|---|---|
| Temperature error (relative to input range), (+/-) | 0.005 %/K |
| Crosstalk between the inputs, min. | -50 dB |
| Repeat accuracy in steady state at 25 °C (relative to input range), (+/-) | 0.01 % |
| Operational error limit in overall temperature range: Current, relative to input range, (+/-) | 0.15 % |
| Basic error limit (operational limit at 25 °C): Current, relative to input range, (+/-) | 0.1 % |
| Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency: Series mode interference (peak value of interference < rated value of input range), min. | 70 dB |
| Number of PROFINET interfaces | 0 |
|---|
| PROFINET IO | No |
|---|---|
| PROFIsafe | No |
| PROFIBUS | No |
| Further protocols: other bus systems | No |
| Alarms: Diagnostic alarm | Yes; Parameterizable |
|---|---|
| Alarms: Limit value alarm | Yes; Parameterizable |
| Diagnoses: Diagnostic information readable | Yes |
| Diagnoses: Wire break | Yes; I load < 3.6 mA |
| Diagnostics indication LED: Group error SF (red) | Yes |
| Module for Ex(i) protection | Yes; for more Co/Lo combinations, see certificate IECEx KEM 05.0007 |
|---|---|
| maximum values for connecting terminals for gas group IIC: Uo (no-load voltage), max. | 0.9 V |
| maximum values for connecting terminals for gas group IIC: Io (short-circuit current), max. | 0.8 mA |
| maximum values for connecting terminals for gas group IIC: Po (power output), max. | 0.2 mW |
| maximum values for connecting terminals for gas group IIC: Co (permissible external capacity), max. | 1 000 µF |
| maximum values for connecting terminals for gas group IIC: Lo (permissible external inductivity), max. | 1 000 mH |
| maximum values for connecting terminals for gas group IIC: Ui (intrinsically safe input voltage), max. | 30 V |
| maximum values for connecting terminals for gas group IIC: Ii (intrinsically safe input current), max. | 150 mA |
| maximum values for connecting terminals for gas group IIC: Pi (intrinsically safe input power), max. | 1.2 W |
| maximum values for connecting terminals for gas group IIC: Ci (internal capacity), max. | 0 nF |
| maximum values for connecting terminals for gas group IIC: Li (internal inductance), max. | 0 mH |
| between channels and powerbus | Yes |
|---|---|
| Potential separation analog inputs: between the channels | No |
| Potential separation analog inputs: between the channels and backplane bus | Yes |
| IP degree of protection | IP30 |
|---|
| CE mark | CE 0344 |
|---|---|
| UKCA mark | DEKRA 21UKEX0090 Importer UK: Siemens plc Manchester M20 2UR |
| cULus | LISTED E334384 |
| FM approval | CLASSIFIED 3025852 |
| Suitable for safety functions | No |
| INMETRO certificate | UL-BR 12.0074 |
| reference designation according to IEC 81346-2 (2009) | K |
| Highest safety class achievable in safety mode: acc. to EN 954 | n.a. |
| Highest safety class achievable in safety mode: Performance level according to ISO 13849-1 | none |
| Highest safety class achievable in safety mode: SIL acc. to IEC 61508 | No |
| Use in hazardous areas: ATEX marking | II 2 G (1) G Ex ib [ia Ga] IIC T4 Gb II 2 G (1) D Ex ib [ia IIIC Da] IIC T4 Gb I M2 Ex ib [ia] I Mb |
| Use in hazardous areas: ATEX certificate | KEMA 04 ATEX 1245 |
| Use in hazardous areas: IECEx | IECEx KEM 05.0007 |
| Use in hazardous areas: CCC Ex | 2020322316002942 |
| Use in hazardous areas: EAC Ex | PB Ex ib [ia] I Mb 1Ex ib [ia Ga] IIC T4 Gb [Ex ia Da] IIIC |
| Use in hazardous areas: FM marking | Class I, Zone 1 AEx ib [ia] IIC T4 Ex ib IIC T4 NI, Class I, DIV.2, GP. A,B,C,D T4 AIS, Class I, DIV.1, GP. A,B,C,D T4 DIP Class II, III, GP. E,F,G |
| Use in hazardous areas: Explosion protection category for gas | ATEX gas explosion protection, Zone 1 |
| Use in hazardous areas: Explosion protection category for dust | ATEX dust explosion protection, Zone 21 always install in corresponding enclosure |
| Use in hazardous areas: associated equipment (Ex ia) | Yes |
| Use in hazardous areas: associated equipment (Ex ib) | Yes |
| Marine approval: Germanischer Lloyd (GL) | Yes |
| Marine approval: American Bureau of Shipping (ABS) | Yes |
| Marine approval: Bureau Veritas (BV) | Yes |
| Marine approval: Det Norske Veritas (DNV) | Yes |
| Design of electrical connection | Screw/spring-type terminal |
|---|
| Width | 30 mm |
|---|---|
| Height | 129 mm |
| Depth | 136.5 mm |
| Weight, approx. | 230 g |
|---|
| eClass | 8 27-24-26-01 |
|---|---|
| ETIM | 10 EC001596 |
| IDEA | 4 3562 |
| UNSPSC | 15 32-15-17-05 |
| For use in hazard-Maritime application ous locations | NK / Nippon Kaiji Ky- okai |
|---|
| Net weight | 0.3 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.8 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | Low stock |
