Siemens 4RB2033-1EB50 4RB2 415V Power Supply

Name: Siemens 4RB2033-1EB50 4RB2 415V Power Supply
Brand: Siemens
SKU: 4RB2033-1EB50
Price: 24.41 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Brand: Siemens

Reference No: 4RB2033-1EB50

Catalog No: 4RB2033-1EB50

Series: 4RB2

Rated Voltage: 415V

Stock: 129

Delivery time: 1-2 business day(s)

Shipping Origin: Türkiye EXW

$24.41

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Siemens 4RB2033-1EB50 is a power supply from the SENTRON/SIRIUS 4RB2 series. Power capacitor PHICAP MKP 415 V 3.3 kVAr. Supplied by Stoklink for industrial and commercial low-voltage applications.

Technical Specifications

SKU	4RB2033-1EB50
Brand	Siemens
Series	4RB2
Product Type	Power Supply
Type of certification	CE
Type of enclosure material	Extruded round aliuminum can with stud
Type of mechanical safety	Overpressure disconnector (3-phase)
Standard	IEC 60831-1 / -2
Capacitor voltage (rms value) rated value	415 V
Operating frequency 1 rated value	50 Hz
Operating frequency 2 rated value	60 Hz
Capacity rated value	62 µF
Relative negative tolerance of the capacity rated value	5 %
Relative positive tolerance of the capacity rated value	1 %
Reactive power of the capacitor at 50 Hz rated value	3.3 kvar
Reactive power of the capacitor at 60 Hz rated value	4 kvar
Clearance minimum	10.4 mm
Creepage distance minimum	15.4 mm
Type of dielectric	Self-healing metallized polypropylene film
Filler	filled with Non PCB, Soft biodegradable resin
Safety features of the integrated discharge resistors	Discharge time ≤ 180 s to 75 V or less for safe discharging
Voltage test between the terminals	2.15 x VN at 50Hz / 2 s
Weight	0.903 kg
Country of Origin	IN

Certifications & Standards

IEC 60831-1

Applications & Use Cases

The Siemens 4RB2033-1EB50 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 4RB2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.

Technical Details

Rated Voltage (VAC)

415V

Catalog No

4RB2033-1EB50

Standards

IEC 60831-1

Delivery Date (Days)

1-2 days

Model Number

4RB2
