- Part number
- 3SE5122-0CT11
- Model no
- 3SE5
Description
About the 3SE5
About the 3SE5
The Siemens 3SE5122-0CT11 is a safety switch from the SENTRON/SIRIUS 3SE5 series. Position switch Metal enclosure 56 mm wide Device connection 3x (M20x 1.5) 1 NO/1 NC quick action contacts Fork lever operating mechanism with metal lever and plastic rollers 19 mm. Supplied by Stoklink for industrial and commercial low-voltage applications.
Applications & Use Cases
The Siemens 3SE5122-0CT11 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3SE5 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.
Specification
Full specification
General 8
| product brand name | SIRIUS |
|---|---|
| product designation | Mechanical position switches |
| product type designation | 3SE5 |
| manufacturer's article number: of the supplied basic switch | 3SE5122-0CA00 |
| manufacturer's article number: of the supplied actuator head for position switches | 3SE5000-0AT10 |
| manufacturer's article number: of the supplied operating lever | 3SE5000-0AT01 |
| manufacturer's article number: of the supplied switching contacts | 3SE5000-0CA00 |
| manufacturer's article number: of the supplied empty enclosure with cover | 3SE5122-0AA00 |
General technical data 22
| product function positive opening | Yes |
|---|---|
| insulation voltage rated value | 400 V |
| degree of pollution | class 3 |
| surge voltage resistance rated value | 6 kV |
| protection class IP | IP66/IP67 |
| shock resistance: according to IEC 60068-2-27 | 30 g / 11 ms |
| vibration resistance according to IEC 60068-2-6 | 0.35 mm/5 g |
| mechanical service life (operating cycles) typical | 1 000 000 |
| electrical endurance (operating cycles) at AC-15 at 230 V typical | 100 000 |
| thermal current | 10 A |
| material of the enclosure of the switch head | metal |
| reference code according to IEC 81346-2 | B |
| continuous current of the C characteristic MCB | 1 A; for a short-circuit current smaller than 400 A |
| continuous current of the quick DIAZED fuse link | 10 A; for a short-circuit current smaller than 400 A |
| continuous current of the DIAZED fuse link gG | 6 A |
| active principle | mechanical |
| repeat accuracy | 0.05 mm |
| Substance Prohibitance (day/month/year) | 07/01/2006 |
| SVHC substance name | Imidazolidine-2-thione (2-imidazoline-2-thiol) CAS-No. 96-45-7 |
| minimum actuating torque in directions of actuation | 0.25 N·m |
| length of the sensor | 127.5 mm |
| width of the sensor | 56 mm |
Ambient conditions 3
| ambient temperature: during operation | -25 ... +85 °C |
|---|---|
| ambient temperature: during storage | -40 ... +90 °C |
| explosion protection category for dust | none |
Show all 89 specifications ↓ Show less ↑56 more values in Identification, Main circuit, Enclosure, Drive Head, Installation/ mounting/ dimensions, Connections/ Terminals, Communication/ Protocol, Safety related data, ISO 13849, IEC 61508, Logistics.
Identification 10
| Part number | 3SE5122-0CT11 |
|---|---|
| Type designation | 3SE5 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4011209693579 |
| ETIM class | EC000030 |
| eCl@ss | 27270601 |
Main circuit 12
| design of the switching contact | mechanical |
|---|---|
| operating frequency rated value | 50 ... 60 Hz |
| number of NC contacts for auxiliary contacts | 1 |
| number of NO contacts for auxiliary contacts | 1 |
| operational current at AC-15: at 24 V rated value | 6 A |
| operational current at AC-15: at 125 V rated value | 6 A |
| operational current at AC-15: at 240 V rated value | 6 A |
| operational current at AC-15: at 400 V rated value | 4 A |
| operational current at DC-13: at 24 V rated value | 3 A |
| operational current at DC-13: at 125 V rated value | 0.55 A |
| operational current at DC-13: at 250 V rated value | 0.27 A |
| operational current at DC-13: at 400 V rated value | 0.12 A |
Enclosure 4
| design of the housing | block, wide |
|---|---|
| material of the enclosure | metal |
| coating of the enclosure | cathodic dip coating |
| design of the housing according to standard | No |
Drive Head 6
| design of the actuating element | Twist actuator, fork lever, metal lever, plastic rollers 19 mm, single-track |
|---|---|
| shape of the switch head | roller |
| design of the switching function | positive opening |
| circuit principle | snap-action contacts |
| number of switching contacts safety-related | 1 |
| cable entry type | 3x (M20 x 1.5) |
Installation/ mounting/ dimensions 2
| mounting position | any |
|---|---|
| fastening method | screw fixing |
Connections/ Terminals 5
| type of electrical connection | screw terminal |
|---|---|
| type of connectable conductor cross-sections: solid | 1x (0.5 ... 1.5 mm2), 2x (0.5 ... 0.75 mm2) |
| type of connectable conductor cross-sections: finely stranded with core end processing | 1x (0.5 ... 1.5 mm2), 2x (0.5 ... 0.75 mm2) |
| type of connectable conductor cross-sections: for AWG cables solid | 1x (20 ... 16), 2x (20 ... 18) |
| design of the interface for safety-related communication | without |
Communication/ Protocol 1
| design of the interface | without |
|---|
ISO 13849 1
| device type according to ISO 13849-1 | 3 |
|---|
IEC 61508 1
| safety device type according to IEC 61508-2 | A |
|---|
Logistics 7
| Net weight | 0.411 kg |
|---|---|
| Package dimensions | 166 × 56 × 78 mm |
| Country of origin | DE |
| Shipping weight | 0.911 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 31 Oct 2026
Documents
Documents for 3SE5122-0CT11
No documents are on file for this part yet.
Ask us for the datasheet
Quick answers
Questions about the 3SE5
What is the rated current of 3SE5?
The rated current of 3SE5 is 6 A.
What is the EAN of 3SE5?
The EAN (GTIN) of 3SE5 is 4011209693579.
Where does 3SE5 ship from, and how fast?
3SE5 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
