Part number
3SE2283-0GA44
Model no
3SE228
$302.53 On request Dispatch — · From TürkiyeGet a Quote
3SE2

Siemens 3SE2283-0GA44 Hinge Switch 2NC 1NO Position Switch

Rated current
4.2 A
EAN
4011209562561
Description

About the 3SE228

The Siemens 3SE2283-0GA44 is a safety switch from the SENTRON/SIRIUS 3SE2 series. Hinge switch molded-plastic enclosure with stainless steel hinge, 2 NC contacts/1 NO contact, for 40 mm profiles, supplied with additional hinge and fixing accessories, actuating angle 4°. Supplied by Stoklink for industrial and commercial low-voltage applications.

Applications & Use Cases

The Siemens 3SE2283-0GA44 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3SE2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.

Specification

Full specification

55 values · Last verified 31 Oct 2026

General 3

product brand name SIRIUS
product designation safety position switch
product type designation 3SE228

General technical data 13

product function positive opening Yes
insulation voltage rated value 250 V
surge voltage resistance rated value 4 kV
protection class IP IP65
shock resistance 30g / 18 ms
vibration resistance 10 ... 200 Hz: 20g
mechanical service life (operating cycles) typical 1 000 000
thermal current 2.5 A
reference code according to IEC 81346-2 B
active principle mechanical
Substance Prohibitance (day/month/year) 07/01/2006
length of the sensor 92 mm
width of the sensor 111.5 mm

Ambient conditions 8

ambient temperature: during operation -25 ... +65 °C
explosion protection category for dust none
design of the switching contact mechanical
number of NC contacts for auxiliary contacts 2
number of NO contacts for auxiliary contacts 1
operational current at AC-15: at 125 V rated value 4.2 A
operational current at AC-15: at 230 V rated value 2 A
operational current at DC-13: at 24 V rated value 1 A
Show all 55 specifications ↓ Show less ↑31 more values in Identification, Enclosure, Drive Head, Installation/ mounting/ dimensions, Connections/ Terminals, Communication/ Protocol, Logistics.

Identification 10

Part number 3SE2283-0GA44
Type designation 3SE228
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4011209562561
ETIM class EC000030
eCl@ss 27270601

Enclosure 4

design of the housing special design
material of the enclosure glass fiber reinforced thermoplast
coating of the enclosure none
design of the housing according to standard No

Drive Head 5

design of the actuating element rotary actuator
design of the switching function positive opening
circuit principle slow-action contacts
number of switching contacts safety-related 2
cable entry type 2x (M20 x 1.5)

Installation/ mounting/ dimensions 1

fastening method screw fixing

Connections/ Terminals 3

type of electrical connection screw terminal
type of connectable conductor cross-sections: finely stranded with core end processing 1x (0,5 ... 1 mm2)
design of the interface for safety-related communication without

Communication/ Protocol 1

design of the interface without

Logistics 7

Net weight 0.786 kg
Package dimensions 130 × 105 × 40 mm
Country of origin DE
Shipping weight 1.286 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 31 Oct 2026

Documents

Documents for 3SE2283-0GA44

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the 3SE228

What is the rated current of 3SE228?

The rated current of 3SE228 is 4.2 A.

What is the EAN of 3SE228?

The EAN (GTIN) of 3SE228 is 4011209562561.

Where does 3SE228 ship from, and how fast?

3SE228 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
