- Part number
- 3SB2227-0AC01
- Model no
- 3SB2
Description
About the 3SB2
About the 3SB2
The Siemens 3SB2227-0AC01 is a pilot device from the SENTRON/SIRIUS 3SB2 series. Illuminated pushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC Lampholder W2 x 4.6 d, with incandescent lamp 24 V. Supplied by Stoklink for industrial and commercial low-voltage applications.
Applications & Use Cases
The Siemens 3SB2227-0AC01 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3SB2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.
Specification
Full specification
General 4
| product brand name | SIRIUS |
|---|---|
| product designation | Illuminated pushbuttons |
| design of the product | Complete unit round |
| product type designation | 3SB2 |
Enclosure 1
| number of command points | 1 |
|---|
Actuator 8
| design of the actuating element | Illuminated pushbutton |
|---|---|
| principle of operation of the actuating element | momentary contact type |
| product extension optional light source | Yes |
| color of the actuating element | red |
| material of the actuating element | plastic |
| shape of the actuating element | Flat pushbutton |
| type of unlocking device | without |
| number of switching positions | 2 |
Show all 85 specifications ↓ Show less ↑72 more values in Identification, Front ring, Holder, Contact block/ lampholder, General technical data, Supply voltage, Auxiliary circuit, Connections/ Terminals, Ambient conditions, Installation/ mounting/ dimensions, Logistics.
Identification 10
| Part number | 3SB2227-0AC01 |
|---|---|
| Type designation | 3SB2 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4011209091542 |
| ETIM class | EC001028 |
| eCl@ss | 27371228 |
Front ring 4
| product component front ring | Yes |
|---|---|
| design of the front ring | Standard |
| material of the front ring | plastic |
| color of the front ring | black |
Holder 1
| material of the holder | Plastic |
|---|
Contact block/ lampholder 3
| socket design | W2 x 4.6d with lamp |
|---|---|
| number of lampholders | 1 |
| number of switching elements | 1 |
General technical data 11
| product function: positive opening | Yes |
|---|---|
| product function: EMERGENCY STOP function | No |
| product component light source | Yes |
| type of voltage of the operating voltage | AC/DC |
| protection class IP | IP65 |
| vibration resistance according to IEC 60068-2-6 | 20 ... 200 Hz: 5 g |
| operating frequency maximum | 1 000 1/h |
| mechanical service life (operating cycles) typical | 3 000 000 |
| reference code according to IEC 81346-2 | S |
| Substance Prohibitance (day/month/year) | 07/01/2006 |
| operating voltage rated value | 5 ... 60 V |
Supply voltage 6
| type of voltage of the supply voltage: of the light source | AC/DC |
|---|---|
| supply voltage of the light source at AC: at 50 Hz rated value | 24 V |
| supply voltage of the light source at AC: at 60 Hz rated value | 24 V |
| supply voltage 1 of the light source at DC rated value | 24 V |
| relative negative tolerance of the supply voltage | -15 % |
| relative positive tolerance of the supply voltage | 10 % |
Auxiliary circuit 19
| number of NC contacts for auxiliary contacts | 1 |
|---|---|
| number of NO contacts for auxiliary contacts | 0 |
| number of CO contacts for auxiliary contacts | 0 |
| consumed current for rated value of supply voltage maximum | 40 mA |
| operational current at AC-12: at 24 V rated value | 10 A |
| operational current at AC-12: at 60 V rated value | 10 A |
| operational current at AC-12: at 110 V rated value | 10 A |
| operational current at AC-12: at 230 V rated value | 10 A |
| operational current at AC-15: at 24 V rated value | 4 A |
| operational current at AC-15: at 110 V rated value | 4 A |
| operational current at AC-15: at 230 V rated value | 4 A |
| operational current at DC-12: at 24 V rated value | 6 A |
| operational current at DC-12: at 60 V rated value | 5 A |
| operational current at DC-12: at 110 V rated value | 2.5 A |
| operational current at DC-12: at 230 V rated value | 1 A |
| operational current at DC-13: at 24 V rated value | 3 A |
| operational current at DC-13: at 60 V rated value | 1.2 A |
| operational current at DC-13: at 110 V rated value | 0.7 A |
| operational current at DC-13: at 230 V rated value | 0.3 A |
Connections/ Terminals 2
| type of electrical connection | tab terminals |
|---|---|
| tightening torque of the screws in the bracket maximum | 0.4 N·m |
Ambient conditions 3
| ambient temperature: during operation | -25 ... +60 °C |
|---|---|
| ambient temperature: during storage | -40 ... +80 °C |
| environmental category during operation according to IEC 60721 | 3K6 |
Installation/ mounting/ dimensions 6
| fastening method | front plate mounting |
|---|---|
| shape of the installation opening | round |
| mounting diameter | 16 mm |
| mounting height | 8 mm |
| installation width | 19 mm |
| installation depth | 50 mm |
Logistics 7
| Net weight | 0.01 kg |
|---|---|
| Package dimensions | 75 × 46 × 53 mm |
| Country of origin | CZ |
| Shipping weight | 0.51 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 3SB2227-0AC01
No documents are on file for this part yet.
Ask us for the datasheet
Quick answers
Questions about the 3SB2
What is the rated current of 3SB2?
The rated current of 3SB2 is 10 A.
Which supply voltage is 3SB2 rated for?
The rated operational voltage of 3SB2 is 24 V AC.
What is the EAN of 3SB2?
The EAN (GTIN) of 3SB2 is 4011209091542.
Where does 3SB2 ship from, and how fast?
3SB2 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
