- Part number
- 3SB2203-0AB01
- Model no
- 3SB2
Low stock
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
3SB2Siemens 3SB2203-0AB01 3SB2 10A Pilot Device
Description
About the 3SB2
About the 3SB2
The Siemens 3SB2203-0AB01 is a pilot device from the SENTRON/SIRIUS 3SB2 series. Pushbutton, 16 mm, round, plastic, black, pushbutton, flat, 1 NC. Supplied by Stoklink for industrial and commercial low-voltage applications.
Applications & Use Cases
The Siemens 3SB2203-0AB01 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3SB2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.
Specification
Full specification
General 4
| product brand name | SIRIUS |
|---|---|
| product designation | Pushbuttons |
| design of the product | Complete unit round |
| product type designation | 3SB2 |
Enclosure 1
| number of command points | 1 |
|---|
Actuator 8
| design of the actuating element | Pushbutton |
|---|---|
| principle of operation of the actuating element | momentary contact type |
| product extension optional light source | No |
| color of the actuating element | black |
| material of the actuating element | plastic |
| shape of the actuating element | Flat pushbutton |
| type of unlocking device | without |
| number of switching positions | 2 |
Show all 76 specifications ↓ Show less ↑63 more values in Identification, Front ring, Holder, Contact block/ lampholder, General technical data, Auxiliary circuit, Connections/ Terminals, Ambient conditions, Installation/ mounting/ dimensions, Logistics.
Identification 10
| Part number | 3SB2203-0AB01 |
|---|---|
| Type designation | 3SB2 |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4011209321724 |
| ETIM class | EC001028 |
| eCl@ss | 27371228 |
Front ring 4
| product component front ring | Yes |
|---|---|
| design of the front ring | Standard |
| material of the front ring | plastic |
| color of the front ring | black |
Holder 1
| material of the holder | Plastic |
|---|
Contact block/ lampholder 2
| number of lampholders | 0 |
|---|---|
| number of switching elements | 1 |
General technical data 10
| product function: positive opening | Yes |
|---|---|
| product function: EMERGENCY STOP function | No |
| type of voltage of the operating voltage | AC/DC |
| protection class IP | IP65 |
| vibration resistance according to IEC 60068-2-6 | 20 ... 200 Hz: 5 g |
| operating frequency maximum | 1 000 1/h |
| mechanical service life (operating cycles) typical | 10 000 000 |
| reference code according to IEC 81346-2 | S |
| Substance Prohibitance (day/month/year) | 07/01/2006 |
| operating voltage rated value | 5 ... 250 V |
Auxiliary circuit 18
| number of NC contacts for auxiliary contacts | 1 |
|---|---|
| number of NO contacts for auxiliary contacts | 0 |
| number of CO contacts for auxiliary contacts | 0 |
| operational current at AC-12: at 24 V rated value | 10 A |
| operational current at AC-12: at 60 V rated value | 10 A |
| operational current at AC-12: at 110 V rated value | 10 A |
| operational current at AC-12: at 230 V rated value | 10 A |
| operational current at AC-15: at 24 V rated value | 4 A |
| operational current at AC-15: at 110 V rated value | 4 A |
| operational current at AC-15: at 230 V rated value | 4 A |
| operational current at DC-12: at 24 V rated value | 6 A |
| operational current at DC-12: at 60 V rated value | 5 A |
| operational current at DC-12: at 110 V rated value | 2.5 A |
| operational current at DC-12: at 230 V rated value | 1 A |
| operational current at DC-13: at 24 V rated value | 3 A |
| operational current at DC-13: at 60 V rated value | 1.2 A |
| operational current at DC-13: at 110 V rated value | 0.7 A |
| operational current at DC-13: at 230 V rated value | 0.3 A |
Connections/ Terminals 2
| type of electrical connection | tab terminals |
|---|---|
| tightening torque of the screws in the bracket maximum | 0.4 N·m |
Ambient conditions 3
| ambient temperature: during operation | -25 ... +70 °C |
|---|---|
| ambient temperature: during storage | -40 ... +80 °C |
| environmental category during operation according to IEC 60721 | 3K6 |
Installation/ mounting/ dimensions 6
| fastening method | front plate mounting |
|---|---|
| shape of the installation opening | round |
| mounting diameter | 16 mm |
| mounting height | 8 mm |
| installation width | 19 mm |
| installation depth | 50 mm |
Logistics 7
| Net weight | 0.015 kg |
|---|---|
| Package dimensions | 72 × 50 × 50 mm |
| Country of origin | CZ |
| Shipping weight | 0.515 kg |
| Ships from | Türkiye |
| Dispatch | 16 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 3SB2203-0AB01 1
-
Datasheet
ProductDownload PDF: Product data sheet 3SB2203-0AB01
Product data sheet 3SB2203-0AB01
Quick answers
Questions about the 3SB2
What is the rated current of 3SB2?
The rated current of 3SB2 is 10 A.
What is the EAN of 3SB2?
The EAN (GTIN) of 3SB2 is 4011209321724.
Where does 3SB2 ship from, and how fast?
3SB2 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
