Siemens 3RN2012-1BW30 Motor Protection Circuit Breaker

Siemens 3RN2012-1BW30 3RN2 24V Motor Protection Circuit Breaker

Name: Siemens 3RN2012-1BW30 3RN2 24V Motor Protection Circuit Breaker
Brand: Siemens
SKU: 3RN2012-1BW30
Price: 128.21 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Brand: Siemens

Reference No: 3RN2012-1BW30

Catalog No: 3RN2012-1BW30

Series: 3RN2

Rated Voltage: 24V

Stock: 9

Delivery time: 1-2 business day(s)

Shipping Origin: Türkiye EXW

$128.21

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Siemens 3RN2012-1BW30 is a motor protection circuit breaker from the SENTRON/SIRIUS 3RN2 series. Thermistor motor protection relay standard evaluation unit 22.5 mm enclosure screw terminal 2 changeover contacts Us = 24 V-240 V AC/DC manual/auto/remote RESET with ATEX approval 2 LEDs (ready/tripped) electrical isolation test/RESET button wire-break monitoring short-circuit monitoring non-volatile. Supplied by Stoklink for industrial and commercial low-voltage applications.

Technical Specifications

SKU	3RN2012-1BW30
Brand	Siemens
Series	3RN2
Product Type	Motor Protection Circuit Breaker
Product function	thermistor motor protection
Display version LED	Yes
At AC in hot operating state	1.7 W
At DC in hot operating state	1.7 W
Degree of pollution	3
Surge voltage resistance rated value	4 kV
Shock resistance according to IEC 60068-2-27	11 g / 15 ms
Vibration resistance according to IEC 60068-2-6	10 ... 55 Hz: 0.35 mm
Mechanical service life (operating cycles) typical	10 000 000
At 24 V typical	100 000
At 230 V typical	100 000
Net Weight	0.181 kg
Error memory	Yes
Dynamic open-circuit detection	Yes
External reset	Yes
Auto-RESET	Yes
Manual RESET	Yes
Type of voltage of the control supply voltage	AC/DC
Weight	0.181 kg
Country of Origin	DE

Applications & Use Cases

The Siemens 3RN2012-1BW30 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 3RN2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.

Technical Details

Rated Voltage (VAC)

24V

Catalog No

3RN2012-1BW30

Delivery Date (Days)

1-2 days

Model Number

3RN2
