Schneider Electric LV510317 CVS100B EasyPact CVS 4P 100A 25kA Fixed Moulded Case Circuit Breaker

The Schneider Electric LV510317 CVS100B is a 4-pole moulded case circuit breaker from the EasyPact CVS series, rated at 100A (at 40°C) and 415V AC with a breaking capacity of 25 kA at 380/415V AC. Designed for fixed backplate mounting, this MCCB provides reliable overcurrent and short-circuit protection for industrial distribution boards and control panels, combining robust performance with compact dimensions of 140 × 86 × 161 mm and a weight of just 2.2 kg.

Technical Specifications

Certifications & Standards

• IEC 60947-2: International standard for low-voltage switchgear and controlgear — circuit breakers
• EN 60947-2: European harmonised standard for low-voltage circuit breakers
• IEC 60664-1: Insulation coordination for equipment within low-voltage systems
• GOST: Russian/CIS national standards certification for electrical equipment
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• REACH: Compliant with EU REACH regulation (EC) No 1907/2006 on chemical substances
• China RoHS: Compliant with Chinese restriction of hazardous substances requirements
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive 2012/19/EU

Applications & Use Cases

• Main or branch circuit protection in industrial distribution panels
• Overcurrent and short-circuit protection for 4-wire (3-phase + neutral) distribution systems
• Control panel and switchboard installations requiring fixed backplate mounting
• Building services, commercial, and light industrial electrical infrastructure up to 415V AC
• Suitable for markets requiring GOST certification (Russia and CIS countries)
