Schneider Electric LP1K1210BD TeSys K 3P 12A 5.5kW 24V DC Coil AC-3 Power Contactor

The Schneider Electric LP1K1210BD is a TeSys K series 3-pole power contactor rated at 12A (AC-3, ≤440V, ≤50°C) with a 24V DC coil, designed for motor switching and control applications up to 5.5kW at 380–415V AC. Compact and versatile, LP1K1210BD supports plate or DIN rail mounting and is built to IEC 60947-4-1 standards for reliable performance in demanding industrial environments.

Technical Specifications

Certifications & Standards

• IEC 60947-4-1: Low-voltage switchgear — electromechanical contactors and motor-starters
• IEC 60947-5-1: Low-voltage switchgear — control circuit devices and switching elements
• IEC 60947: General low-voltage switchgear and controlgear standard
• IEC 60068-2-27: Environmental testing — shock
• IEC 60068-2-6: Environmental testing — vibration (sinusoidal)
• UL 508: Industrial control equipment (UL Listed)
• CSA C22.2 No 14: Canadian standard for industrial control equipment
• EN/ISO 13849-1: Safety of machinery — safety-related parts of control systems
• UL94 V1: Flammability rating for plastic materials
• NF F16-101: French railway fire behaviour standard — materials classification
• NF F16-102: French railway fire behaviour standard — products classification
• VDE 0660: German standard for low-voltage switchgear
• NFC C 63-110: French standard for low-voltage controlgear
• REACH: EU regulation on chemical substances compliance
• RoHS: Restriction of hazardous substances in electrical and electronic equipment

Applications & Use Cases

• Direct-on-line (DOL) motor starting for three-phase motors up to 5.5kW
• Machine automation and industrial control panels requiring compact AC-3 contactors
• Reversing or star-delta starter configurations when paired with compatible TeSys K accessories
• Railway and transportation equipment requiring NF F16-101/102 fire classification compliance
• Safety-rated circuits in machinery compliant with EN/ISO 13849-1
• OEM panel builders seeking UL 508 and CSA C22.2 No 14 dual-certified components

Frequently Asked Questions

• What is the coil voltage of the LP1K1210BD? The coil operates on 24V DC.
• What motor power can LP1K1210BD switch? Up to 5.5kW at 380–415V AC under AC-3 duty.
• Can LP1K1210BD be DIN rail mounted? Yes — it supports both plate and DIN rail mounting.
• What is the AC-3 rated current? 12A at voltages up to 440V and temperatures up to 50°C.
• Is this contactor UL certified? Yes — it is listed to UL 508 and certified to CSA C22.2 No 14.
