Schneider Electric LP1K0910BD LP1K 3-Pole 9A 24V DC Coil TeSys K Contactor

The Schneider Electric LP1K0910BD is a TeSys K series 3-pole contactor rated at 9A and 440V, equipped with a 24V DC control coil — a compact and reliable solution for motor starting, reversing, and general power switching applications in industrial control panels. Designed for AC-3 utilization category, the LP1K0910BD delivers proven switching performance in a space-saving format weighing just 0.225 kg.

Technical Specifications

Applications & Use Cases

• Motor Control: Suitable for direct-on-line starting and stopping of three-phase induction motors up to 4 kW at 400V (AC-3 duty).
• Industrial Automation: Ideal for use in motor control centres (MCCs), control panels, and automated machinery where reliable switching is required.
• Reversing Starters: Can be used in reversing contactor pairs for bi-directional motor control applications.
• General Power Switching: Applicable for resistive and mildly inductive load switching in AC-1 category installations.
• OEM & Panel Building: Compact footprint and lightweight design (0.225 kg) make the LP1K0910BD well-suited for space-constrained enclosures and OEM machine building.

Frequently Asked Questions

What is the coil voltage of the LP1K0910BD?

The LP1K0910BD is fitted with a 24V DC coil, making it compatible with PLC and low-voltage DC control circuits without the need for an additional transformer.

What utilization category does the LP1K0910BD comply with?

The TeSys K contactor is designed for AC-3 duty (squirrel-cage motor starting) as well as AC-1 resistive load switching.

Can auxiliary contact blocks be added to the LP1K0910BD?

Yes, the TeSys K platform supports add-on auxiliary contact blocks compatible with the LP1K frame size, allowing expansion of control circuit contacts.

What is the rated voltage of this contactor?

The LP1K0910BD is rated at 440V, suitable for standard three-phase industrial power systems including 380V, 400V, and 415V networks.
