Schneider Electric LC1D25M7 TeSys Deca 3-Pole 25A 15HP 480V AC Contactor

The Schneider Electric LC1D25M7 is a TeSys Deca series 3-pole AC contactor rated at 25A and 15HP at 480V AC, designed for reliable motor switching and industrial power control applications. With a short-circuit current rating (SCCR) of 100 kA, the LC1D25M7 delivers robust protection and performance in demanding electrical installations. Weighing just 0.37 kg, this compact contactor is engineered for panel space efficiency without compromising on switching capability.

Technical Specifications

Applications & Use Cases

• Motor Starting & Switching: Ideal for AC-3 duty motor starters in industrial machinery, pumps, compressors, and conveyor systems up to 15HP at 480V AC.
• Panel Board Integration: Compact form factor suits MCC (motor control center) panels and distribution boards where space is at a premium.
• Industrial Automation: Suitable for use in automated production lines, HVAC systems, and process control applications requiring reliable high-cycle switching.
• Power Distribution: The 100 kA SCCR rating makes the LC1D25M7 appropriate for high-fault-current environments, ensuring system-level protection compliance.

Frequently Asked Questions

• What is the rated motor horsepower for the LC1D25M7? The LC1D25M7 is rated for 15HP at 480V AC three-phase motor loads.
• What does the suffix M7 indicate? The M7 suffix typically denotes the coil voltage variant. Consult the Schneider Electric TeSys Deca coil voltage table for the specific voltage this suffix represents.
• Is the LC1D25M7 part of the TeSys Deca series? Yes, the LC1D25M7 belongs to the Schneider Electric TeSys Deca contactor series, known for enhanced durability and optimized energy consumption.
• What is the SCCR of this contactor? The LC1D25M7 has a Short-Circuit Current Rating (SCCR) of 100 kA, suitable for high-fault-current industrial environments.
