Schneider Electric LC1D115F7 TeSys Deca 3-Pole 115A 75HP 480V AC Contactor

The Schneider Electric LC1D115F7 is a TeSys Deca series 3-pole AC contactor rated at 115A and 75HP at 480V AC, engineered for robust motor control and industrial power switching applications. With a short-circuit current rating (SCCR) of 100kA, the LC1D115F7 delivers exceptional fault protection in demanding electrical installations. Weighing 2.5kg, this contactor offers a compact yet powerful solution for panel builders and OEMs requiring reliable motor starter contactors.

Technical Specifications

Applications & Use Cases

• Motor Control: Ideal for starting, stopping, and reversing 3-phase AC motors up to 75HP in industrial environments.
• HVAC Systems: Suitable for controlling large compressor and fan motors in commercial and industrial HVAC equipment.
• Pump & Conveyor Control: Reliable switching for pumping stations, conveyor drives, and material handling systems.
• Panel Building & OEM: Designed for integration into motor control centers (MCCs), switchboards, and custom control panels requiring high fault-withstand ratings.
• Industrial Automation: Compatible with PLC-driven control architectures where frequent switching cycles and long service life are required.

Frequently Asked Questions

What is the rated current of the LC1D115F7?

The LC1D115F7 is rated at 115A, suitable for motor loads up to 75HP at 480V AC.

What is the SCCR of this contactor?

The short-circuit current rating (SCCR) is 100kA, providing robust protection in high fault-current installations.

How many poles does the LC1D115F7 have?

It is a 3-pole contactor, designed for three-phase AC motor and power switching applications.

Which series does this contactor belong to?

The LC1D115F7 is part of Schneider Electric's TeSys Deca series, known for high reliability and compact design.
