- Part number
- ZB5AW0B15
- Model no
- ZB5
Description
About the ZB5
About the ZB5
The Schneider Electric ZB5AW0B15 is a Harmony XB5 complete body: a fixing collar, a 1 NO + 1 NC contact assembly and an integral white-LED light block in one part, supplied at 24 V AC/DC. It combines the switching function and the illumination of a selector or push-button station in a single body.
Certifications & Standards
- IEC 60947-1
- IEC 60947-5-1
- IEC 60947-5-4
- UL 508
- CSA C22.2 No 14
- JIS C8201-1
- JIS C8201-5-1
- UL Listed
Selection Notes
Because the light block and the contact block are built into one assembly, this SKU replaces a separate body plus light block when the station needs both an NO/NC output and a lit cap — fewer parts to stock and assemble than building the same function from a plain body and a bolt-on light block. Confirm the control circuit is 24 V AC/DC before ordering: the 24 V version is not interchangeable with the sibling supplied at the other voltage.
Specification
Full specification
Main 13
| Range of Product | Harmony XB5 |
|---|---|
| Product or Component Type | Complete body/contact assembly and light block |
| Device short name | ZB5 |
| Fixing collar material | Plastic |
| Sale per indivisible quantity | 1 |
| Head type | Standard |
| Contacts type and composition | 1 NO + 1 NC |
| Contact operation | Slow-break |
| Connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1, Screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1 |
| Light source | Universal LED |
| Bulb base | Integral LED |
| Light block supply | Direct |
| Light source colour | White |
Complementary 28
| CAD overall width | 1.2 in (30 mm) |
|---|---|
| CAD overall height | 1.7 in (42 mm) |
| CAD overall depth | 1.3 in (32 mm) |
| Terminals description ISO n°1 | (13-14)NO, (11-12)NC |
| Net Weight | 0.093 lb(US) (0.042 kg) |
| Contacts usage | Standard |
| Positive opening | With IEC 60947-5-1 appendix K |
| Operating travel | 0.06 in (1.5 mm) NC changing electrical state), 0.1 in (2.6 mm) NO changing electrical state), 0.2 in (4.3 mm) total travel) |
| Operating force | 2 N NC changing electrical state, 2.3 N NO changing electrical state |
| Operating torque | 0.44 lbf.in (0.05 N.m) NO changing electrical state |
| Mechanical durability | 5000000 cycles |
| Tightening torque | 7.08…10.6 lbf.in (0.8…1.2 N.m) IEC 60947-1 |
| Shape of screw head | Cross Philips no 1, Cross pozidriv No 1, Slotted flat Ø 4 mm, Slotted flat Ø 5.5 mm |
| Contacts material | Silver alloy (Ag/Ni) |
| Short-circuit protection | 10 A cartridge fuse gG IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A IEC 60947-5-1 |
| [Ui] rated insulation voltage | 600 V 3)IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 6 kV IEC 60947-1 |
| [Ie] rated operational current | 3 A 240 V, AC-15, A600 IEC 60947-5-1, 6 A 120 V, AC-15, A600 IEC 60947-5-1, 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1, 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1, 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1, 1.2 A 600 V, AC-15, A600 IEC 60947-5-1 |
| Electrical durability | 1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C |
| Electrical reliability | Λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4, Λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4 |
| Signalling type | Steady |
| [Us] rated supply voltage | 24 V AC/DC 50/60 Hz |
| Supply voltage limits | 19.2…30 V DC, 21.6…26.4 V AC |
| Current Consumption | 18 mA |
| Service life | 100000 h at rated voltage and 25 °C |
| Surge withstand | 1 kV IEC 61000-4-5 |
| Device presentation | Basic sub-assemblies |
Environment 12
| Protective treatment | TH |
|---|---|
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) |
| Electrical shock protection class | Class II conforming to IEC 60536 |
| Standards | JIS C8201-5-1, IEC 60947-1, IEC 60947-5-4, UL 508, IEC 60947-5-1, CSA C22.2 No 14, JIS C8201-1 |
| Product Certifications | CSA, DNV, BV, LROS (Lloyds register of shipping), UL Listed |
| Vibration resistance | 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Resistance to fast transients | 2 kV IEC 61000-4-4 |
| Resistance to electromagnetic fields | 9.1 V/m (10 V/m) IEC 61000-4-3 |
| Resistance to electrostatic discharge | 6 kV on contact (on metal parts) IEC 61000-2-6, 8 kV in free air (in insulating parts) IEC 61000-2-6 |
| Electromagnetic emission | Class B IEC 55011 |
Show all 67 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.
Identification 8
| Part number | ZB5AW0B15 |
|---|---|
| Type designation | ZB5 |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3389110908398 |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 5
| Country of origin | FR |
|---|---|
| Shipping weight | 0.042 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for ZB5AW0B15
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- UL
- CSA
- JIS C8201-5-1
- IEC 60947-1
- IEC 60947-5-4
- UL 508
- IEC 60947-5-1
- CSA C22.2 No 14
- JIS C8201-1
Quick answers
Questions about the ZB5
Which supply voltage is ZB5 rated for?
The rated operational voltage of ZB5 is 24–DC V DC.
What is the HS code of ZB5 for customs?
The tariff (HS) code on file for ZB5 is 853690.
What is the EAN of ZB5?
The EAN (GTIN) of ZB5 is 3389110908398.
Where does ZB5 ship from, and how fast?
ZB5 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
