Schneider Electric TM241C24R Modicon M241 24 I/O Relay 100-240V AC Logic Controller

The Schneider Electric TM241C24R is a Modicon M241 logic controller with 24 discrete I/O — 14 inputs (8 fast) and a mixed 6-relay/4-transistor (4 fast) output stage — supplied from 100-240 V AC. Relay outputs switch up to 2 A at 5-250 V AC or 5-125 V DC, and the controller supports up to 14 remote I/O expansion modules for machines needing both discrete switching and AC-mains simplicity.

Technical Specifications

Certifications & Standards

• CE
• RCM
• cULus
• UKCA
• DNV-GL
• ABS
• LR
• ANSI/ISA 12-12-01
• CSA C22.2 No 142
• CSA C22.2 No 213
• IEC 61131-2:2007
• UL 508

Selection Notes

The TM241C24R's relay outputs (6 of the 10, switching 5-250 V AC or 5-125 V DC at up to 2 A) let it drive AC contactors and solenoids directly from an AC-mains supply, unlike a transistor-only M241 that needs a 24 V DC source. Its remaining 4 transistor fast outputs (100 kHz PTO) cover a single positioning axis when the rest of the machine runs on relay-switched AC loads.
