Schneider Electric NTSXTB18000H NTS Screw Terminal Block 18-Point Without Cover Remote I/O Module

% $-25.47
Schneider Electric NTSXTB18000H Modicon Edge I/O NTS screw terminal block 18-point - 3.81 mm pitch
Schneider Electric NTSXTB18000H Modicon Edge I/O NTS screw terminal block 18-point - 3.81 mm pitch

Schneider Electric NTSXTB18000H NTS Screw Terminal Block 18-Point Without Cover Remote I/O Module

Brand: Schneider Electric
Reference No: NTSXTB18000H
Catalog No: NTSXTB18000H
Series: Modicon Edge I/O NTS
Tariff Code (HS): 853710
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$25.47

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric NTSXTB18000H is a 18-point screw terminal block from the Modicon Edge I/O NTS range, built for the low-height (100 mm) I/O module housing. It ships without a cover, uses a 3.81 mm pitch, and handles DC-wired I/O channels. The H suffix marks the hardened variant, rated IP20 from -40 to 70 degrees C for extended-temperature panels.

Technical Specifications

Reference NTSXTB18000H
Brand Schneider Electric
GTIN 3606486878484
Range of Product Modicon Edge I/O NTS
Product or Component Type Terminal block
Connector Type Screw connector
Pin Number 18
Pitch 3.81 mm
Cover Without cover
Height 3.5 in (90 mm)
Width 0.6 in (14 mm)
Net Weight 0.068 lb(US) (0.031 kg)
Product Compatibility NTS low height I/O module (discrete I/O, analog input, counting, field device master, passive, motion expert modules)
IP Degree of Protection IP20
Ambient Air Temperature for Operation -40 to 70 C

Certifications & Standards

  • CE
  • UKCA
  • cULus
  • RCM
  • EN/IEC 61131-2

Selection Notes

Choose the low-height variant to match the NTS I/O module body (100 mm); a low-height terminal block will not seat correctly on a high-height module and vice versa. The uncovered version leaves the connection points exposed for faster field wiring where touch-safety is handled elsewhere in the enclosure. Screw connectors on this block are removable from the module front face, so a wiring fault or module swap does not require re-terminating the field cabling.

Technical Details

Short Description
Modicon Edge I/O NTS screw terminal block, 18 points, 3.81 mm pitch, low module, IP20.
Mounting Type
Front-face plug-in on NTS low-height I/O module
Protection Type
IP20
Catalog No
NTSXTB18000H
Delivery Date (Days)
30 days
Model Number
NTS
Tariff Code
853710
