Part number
LV516450
Model no
CVS160N
$191.02 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric LV516450 EasyPact CVS160N 3P 100 A 50 kA MA Fixed Moulded Case Circuit Breaker

Schneider Electric CVS160N MA magnetic-only MCCB, 100 A, 50 kA Icu, motor-circuit short-circuit protection.

Rated current
100 A
Description

About the CVS160N

The Schneider Electric LV516450 is a 3-pole EasyPact CVS160N moulded case circuit breaker rated 100 A with a 50 kA breaking capacity (Icu) at 380/415 V AC. It uses a magnetic-only MA trip unit for short-circuit protection, the standard configuration for motor-circuit applications that pair it with a separate thermal overload relay. The breaker is fixed-mounted and carries IP40 front-face ingress protection.

Certifications & Standards

  • IEC
  • GOST
  • IEC 60947-2
  • EN 60947-2

Selection Notes

The MA trip unit on the CVS160N fires on short-circuit current only - it carries no adjustable thermal overload curve - so this breaker is the motor-circuit configuration: pair it with a separate thermal overload relay or motor circuit protector to cover running overload, and let this breaker clear fault current with its 6...14x In (adjustable) instantaneous pick-up. Choose it over the TM-D or ETS versions of the same CVS160 frame when overload protection already sits elsewhere in the motor starter.

Specification

Full specification

68 values · Last verified 30 Oct 2026

Main 17

Range EasyPact
Range of product EasyPact CVS100...250
Product name EasyPact CVS
Device short name CVS160N
Product or component type Circuit breaker
Device application Motor
Poles description 3P
Protected poles description 3D
Earth leakage protection (Vigi add on) Without
[In] rated current 100 A at 65 °C
Network type AC
Utilisation category Category A
[Icu] Breaking capacity 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 40 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 80 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Trip unit name MA
Trip unit technology Magnetic
Trip unit rating 100 A at 65 °C
Protection type Short-circuit protection (magnetic)

Complementary 21

[Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2
Network frequency 50/60 Hz
Breaking capacity code N
[Ics] rated service breaking capacity 30 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 80 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Mechanical durability 25000 cycles
Electrical durability 12000 cycles 415 V In conforming to IEC 60947-2
Control type Toggle
Instantaneous pick-up adjustment type Ii Adjustable
Instantaneous pick-up adjustment range 6...14 x In
Contact position indicator Yes
Mounting support Backplate
Mounting mode Fixed
Upside connection Front
Downside connection Front
Connections - terminals Screw connection
Connection pitch 35 mm
Compatibility code CVS160
Width 105 mm
Depth 86 mm
Height 161 mm
Net weight 1.5 kg

Environment 6

Standards IEC 60947-2, EN 60947-2
Product certifications IEC, GOST
Electrical shock protection class Class II
IP degree of protection IP40
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -50…85 °C
Show all 68 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number LV516450
Type designation CVS160N
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 9 cm
Package 1 Width 10.5 cm
Package 1 Length 16 cm
Package 1 Weight 2.25 kg
Unit Type of Package 2 S03
Number of Units in Package 2 7
Package 2 Height 30 cm
Package 2 Width 30 cm
Package 2 Length 40 cm
Package 2 Weight 15.75 kg
Shipping weight 1.5 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for LV516450

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • IEC 60947-2
  • EN 60947-2
Quick answers

Questions about the CVS160N

What is the rated current of CVS160N?

The rated current of CVS160N is 100 A.

What is the HS code of CVS160N for customs?

The tariff (HS) code on file for CVS160N is 853620.

Where does CVS160N ship from, and how fast?

CVS160N ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
