Schneider Electric LV510346 EasyPact CVS100F 4P 80 A 36 kA TM-D Fixed Moulded Case Circuit Breaker

The Schneider Electric LV510346 is a 4-pole EasyPact CVS100F moulded case circuit breaker rated 80 A, with a breaking capacity of 36 kA at 380/415 V AC. It uses a TM-D thermal-magnetic trip unit, combining adjustable thermal overload protection with a fixed magnetic short-circuit trip, and mounts as a fixed, backplate-mounted device for distribution applications up to 80 A.

Technical Specifications

Certifications & Standards

• IEC
• GOST
• IEC 60947-2
• EN 60947-2

Selection Notes

The TM-D trip unit on the LV510346 pairs an adjustable thermal overload stage (56–80 A) with a fixed magnetic instantaneous trip at 640 A, so the overload threshold can be tuned to the connected load while the short-circuit threshold stays fixed. The 4-pole version adds a protected neutral pole. In the CVS100F frame, 36 kA at 380/415 V AC covers distribution circuits exposed to higher prospective fault currents than the CVS100B (25 kA) code supports.
