Schneider Electric LV510300 EasyPact CVS100B 3P 16 A 25 kA TM-D Fixed Moulded Case Circuit Breaker

The Schneider Electric LV510300 is a 3-pole EasyPact CVS100B moulded case circuit breaker rated 16 A, with a breaking capacity of 25 kA at 380/415 V AC. It uses a TM-D thermal-magnetic trip unit, combining adjustable thermal overload protection with a fixed magnetic short-circuit trip, and mounts as a fixed, backplate-mounted device for distribution applications up to 16 A.

Technical Specifications

Certifications & Standards

• IEC
• GOST
• IEC 60947-2
• EN 60947-2

Selection Notes

The TM-D trip unit on the LV510300 pairs an adjustable thermal overload stage (11.2–16 A) with a fixed magnetic instantaneous trip at 190 A, so the overload threshold can be tuned to the connected load while the short-circuit threshold stays fixed. In the CVS100B frame, 25 kA at 380/415 V AC covers general distribution circuits with moderate fault levels; move to the CVS100F (36 kA) code if the prospective fault current at the installation point is higher.
