Part number
LP1K1201FD
Model no
LP1K
$28.66 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric LP1K1201FD TeSys K Contactor 3P 1NC Aux 12 A AC-3 110 V DC Coil Contactor

TeSys K contactor, 3P, 12 A AC-3, 1NC auxiliary contact, 110 V DC coil.

Rated current
12 A
Motor power
5.5 kW
Poles
3P
Description

About the LP1K

The Schneider Electric LP1K1201FD is a TeSys K miniature contactor, 3P (3 NO) with 1 NC built-in, rated 12 A AC-3 at up to 440 V for 3-phase motor control up to 5.5 kW at 400 V and resistive load switching up to 20 A at 690 V AC-1. It runs on a 110 V DC coil and is DIN-rail or screw mounted in a 45 mm housing.

Certifications & Standards

  • CB Scheme
  • CCC
  • UL
  • CSA
  • EAC
  • CE
  • UKCA
  • IEC 60947-4-1
  • IEC 60947-5-1
  • GB/T 14048.4

Selection Notes

The 12 A AC-3 rating places this contactor at the 5.5 kW point of the TeSys K range at 400 V; step up to the next current rating in the same frame if the motor's full-load current exceeds 12 A rather than running the contactor at its thermal limit continuously. The 1 NC auxiliary contact gives a direct run or fault-feedback signal to the control circuit without an add-on contact block, and the 110 V DC coil should match the control transformer already used elsewhere in the panel to avoid a dedicated supply.

Specification

Full specification

69 values · Last verified 29 Oct 2026

Main 4

Range TeSys
Product or component type Contactor
Device short name LP1K
Contactor application Resistive load Motor control

Complementary 40

Utilisation category AC-3 AC-3e AC-1 AC-4
Poles description 3P
power pole contact composition 3 NO
[Ue] rated operational voltage Power circuit: <= 690 V AC <= 400 Hz Signalling circuit: <= 690 V AC <= 400 Hz
[Ie] rated operational current 12 A (at <60 °C) at <= 440 V AC AC-3 for power circuit 12 A (at <60 °C) at <= 440 V AC AC-3e for power circuit 20 A (at <60 °C) at <= 690 V AC AC-1 for power circuit
Control circuit type DC standard
[Uc] control circuit voltage 110 V DC
Motor power kW 3 kW at 220...230 V AC 50/60 Hz AC-3 5.5 kW at 380...415 V AC 50/60 Hz AC-3 5.5 kW at 440 V AC 50/60 Hz AC-3 4 kW at 690 V AC 50/60 Hz AC-3 3 kW at 220...230 V AC 50/60 Hz AC-3e 5.5 kW at 380...415 V AC 50/60 Hz AC-3e 5.5 kW at 440 V AC 50/60 Hz AC-3e 4 kW at 690 V AC 50/60 Hz AC-3e 3 kW at 220...230 V AC 50/60 Hz AC-4 5.5 kW at 380...415 V AC 50/60 Hz AC-4 5.5 kW at 440 V AC 50/60 Hz AC-4
Auxiliary contact composition 1 NC
[Uimp] rated impulse withstand voltage 8 kV
Overvoltage category III
[Ith] conventional free air thermal current 20 A (at 60 °C) for power circuit 10 A (at 50 °C) for signalling circuit
Irms rated making capacity 144 A AC for power circuit conforming to IEC 60947 110 A AC for signalling circuit conforming to IEC 60947
Rated breaking capacity 110 A at 440 V conforming to IEC 60947 80 A at 500 V conforming to IEC 60947 70 A at 660...690 V conforming to IEC 60947
[Icw] rated short-time withstand current 115 A 50 °C - 1 s for power circuit 105 A 50 °C - 5 s for power circuit 100 A 50 °C - 10 s for power circuit 75 A 50 °C - 30 s for power circuit 55 A 50 °C - 1 min for power circuit 50 A 50 °C - 3 min for power circuit 25 A 50 °C - >= 15 min for power circuit 80 A - 1 s for signalling circuit 90 A - 500 ms for signalling circuit 110 A - 100 ms for signalling circuit
Associated fuse rating 25 A gG at <= 440 V for power circuit 25 A aM for power circuit 10 A gG for signalling circuit conforming to IEC 60947 10 A gG for signalling circuit conforming to VDE 0660
Average impedance 3 mOhm - Ith 20 A 50 Hz for power circuit
[Ui] rated insulation voltage Power circuit: 600 V conforming to UL 508 Power circuit: 690 V conforming to IEC 60947-4-1 Signalling circuit: 690 V conforming to IEC 60947-4-1 Signalling circuit: 690 V conforming to IEC 60947-5-1 Signalling circuit: 600 V conforming to UL 508 Power circuit: 600 V conforming to CSA C22.2 No 14 Signalling circuit: 600 V conforming to CSA C22.2 No 14
safety cover With
Insulation resistance > 10 MOhm for signalling circuit
Inrush power in W 3 W (at 20 °C)
Hold-in power consumption in W 3 W at 20 °C
Heat dissipation 1.3 W
Control circuit voltage limits Operational: 0.8...1.15 Uc (at = 0.10 Uc (at <50 °C)
Connections - terminals Screw clamp terminals 1 cable(s) 1.5...4 mm2solid Screw clamp terminals 1 cable(s) 0.75...4 mm2flexible without cable end Screw clamp terminals 1 cable(s) 0.34...2.5 mm2flexible with cable end Screw clamp terminals 2 cable(s) 1.5...4 mm2solid Screw clamp terminals 2 cable(s) 0.75...4 mm2flexible without cable end Screw clamp terminals 2 cable(s) 0.34...1.5 mm2flexible with cable end Power circuit: screw clamp terminals 2 cable(s) 1.5 mm2flexible with cable end
Maximum operating rate 3600 cyc/h
Coil technology Without built-in suppressor module
Auxiliary contacts type Type instantaneous 1 NC
Minimum switching current 5 mA for signalling circuit
Minimum switching voltage 17 V for signalling circuit
Mounting support Plate Rail
Tightening torque 0.8...1.3 N.m - on screw clamp terminals Philips No 2 0.8...1.3 N.m - on screw clamp terminals flat Ø 6 mm 0.8...1.3 N.m - on screw clamp terminals pozidriv No 2
Operating time 30...40 ms coil energisation and NO closing 10 ms coil de-energisation and NO opening
Safety reliability level B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1
Mechanical durability 10 Mcycles
Electrical durability 1.3 Mcycles 12 A AC-3 at Ue <= 440 V 1.3 Mcycles 12 A AC-3e at Ue <= 440 V 0.3 Mcycles 20 A AC-1 at Ue <= 690 V 0.02 Mcycles 72 A AC-4 at Ue <= 440 V
Height 58 mm
Width 45 mm
Depth 57 mm
Net weight 0.225 kg

Environment 7

Standards EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 UL 60947-5-1 CSA C22.2 No 60947-4-1 CSA C22.2 No 60947-5-1 GB/T 14048.4
Product certifications CB Scheme CCC UL CSA EAC CE UKCA
IP degree of protection IP2X
Ambient air temperature for operation -25...50 °C
Ambient air temperature for storage -50...80 °C
Operating altitude 2000 m without derating
Flame retardance V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
Show all 69 specifications ↓ Show less ↑18 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number LP1K1201FD
Type designation LP1K
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 10

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 6.6 cm
Package 1 Width 4.8 cm
Package 1 Length 6.2 cm
Package 1 Weight 220.0 g
Shipping weight 0.225 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 29 Oct 2026

Documents

Documents for LP1K1201FD

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • CSA
  • CE
  • UKCA
  • CCC
  • EAC
  • CB Scheme
Quick answers

Questions about the LP1K

What is the rated current of LP1K?

The rated current of LP1K is 12 A.

What motor power is LP1K rated for?

The rated motor power of LP1K is 5.5 kW.

What is the HS code of LP1K for customs?

The tariff (HS) code on file for LP1K is 85365080.

Where does LP1K ship from, and how fast?

LP1K ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
