Schneider Electric LP1K0910ED TeSys K contactor - 9 A 48 V DC coil 1NO

Schneider Electric LP1K0910ED TeSys K Contactor 3P 3NO AC-3 9 A 48 V DC Coil 1NO Screw Clamp Contactor

Name: Schneider Electric LP1K0910ED TeSys K Contactor 3P 3NO AC-3 9 A 48 V DC Coil 1NO Screw Clamp Contactor
Brand: Schneider Electric
SKU: LP1K0910ED
Price: 25.87 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Schneider Electric

Reference No: LP1K0910ED

Catalog No: LP1K0910ED

Tariff Code (HS): 853650

Rated Current: 9 A

Power: 4 kW

Poles: 3P

Stock: 0

Delivery time: 30 business day(s)

Shipping Origin: Türkiye EXW

$25.87

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Schneider Electric LP1K0910ED is a TeSys K three-pole contactor rated 9 A AC-3 at up to 440 V, switching motors up to 4 kW at 400 V on a 48 V DC coil with one built-in 1NO auxiliary contact. Screw clamp terminals and a 45 mm width keep it compact for DIN-rail panel layouts.

Technical Specifications

Reference	LP1K0910ED
GTIN	3389110496352
Brand	Schneider Electric
Range	TeSys K
Device short name	LP1K
Contactor application	Motor control
Utilisation category	AC-3 / AC-3e / AC-4
Poles	3P
Power pole contact composition	3 NO
[Ue] rated operational voltage	<= 690 V AC
[Ie] rated operational current (AC-3, <= 440 V)	9 A
[Uc] control circuit voltage	48 V DC
Auxiliary contact composition	1NO
Motor power (380...415 V AC, AC-3)	4 kW
[Ith] conventional free air thermal current	20 A
[Icw] rated short-time withstand current (1 s)	90 A
Rated breaking capacity (440 V)	110 A
Associated fuse rating (<= 440 V)	25 A gG
Mounting support	DIN rail or plate
Dimensions (H x W x D)	58 x 45 x 57 mm
Net weight	0.225 kg
IP degree of protection	IP2X
Ambient air temperature for operation	-25...50 °C
Operating altitude	2000 m without derating
Country of origin	ID

Certifications & Standards

CB Scheme
CCC
UL
CSA
EAC
CE
UKCA
EN/IEC 60947-4-1
EN/IEC 60947-5-1
UL 60947-4-1
UL 60947-5-1
CSA C22.2 No. 60947-4-1
CSA C22.2 No. 60947-5-1
GB/T 14048.4

Selection Notes

The 48 V DC coil distinguishes this from the otherwise identical 9 A LP1K0901FD, which uses a 110 V DC coil and a 1NC contact — pick this unit when the control system supplies 48 V DC.

Technical Details

Short Description

TeSys K contactor, 3P 3NO, 9 A AC-3, 48 V DC coil, 1NO, 4 kW at 400 V

Rated Current (Ampere)

9 A

Mounting Type

DIN rail or plate

Protection Type

IP2X

Catalog No

LP1K0910ED

Number of Poles

Power (kW)

4 kW

Delivery Date (Days)

30 days

Model Number

TeSys K (LP1K)

Tariff Code

853650
