Schneider Electric LP1K0610ED TeSys K Contactor 3P 1NO Aux 6 A AC-3 48 V DC Coil Contactor

% $-23.36
Schneider Electric LP1K0610ED TeSys K contactor 6A 48VDC coil 1NO
Schneider Electric LP1K0610ED TeSys K contactor 6A 48VDC coil 1NO

Schneider Electric LP1K0610ED TeSys K Contactor 3P 1NO Aux 6 A AC-3 48 V DC Coil Contactor

Brand: Schneider Electric
Reference No: LP1K0610ED
Tariff Code (HS): 85365080
Rated Current: 6 A
Power: 2.2 kW
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$23.36

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric LP1K0610ED is a TeSys K miniature contactor, 3P (3 NO) with 1 NO built-in, rated 6 A AC-3 at up to 440 V for 3-phase motor control up to 2.2 kW at 400 V. It runs on a 48 V DC coil and is DIN-rail or screw mounted in a 45 mm housing.

Technical Specifications

Reference LP1K0610ED
Brand Schneider Electric
Range TeSys K
Device Short Name LP1K
Product Type Contactor
Poles 3P (3 NO)
Utilisation Category AC-3, AC-3e, AC-4
[Ie] Rated Operational Current (AC-3, ≤440 V) 6 A
Motor Power (AC-3, 380…415 V) 2.2 kW
Auxiliary Contact 1 NO
Control Circuit Voltage [Uc] 48 V DC
[Uimp] Rated Impulse Withstand Voltage 8 kV
Overvoltage Category III
[Ith] Conventional Free Air Thermal Current 20 A
Rated Breaking Capacity (440 V, IEC 60947) 110 A
[Icw] Rated Short-Time Withstand Current (1 s) 90 A (1 s)
Connections - Terminals Screw clamp, 0.75–4 mm²
Maximum Operating Rate 3600 cyc/h
IP Degree of Protection IP2X
Ambient Air Temperature for Operation -25…50 °C
Width x Height x Depth 45 x 58 x 57 mm
Net Weight 0.225 kg

Certifications & Standards

  • CB Scheme
  • CCC
  • UL
  • CSA
  • EAC
  • CE
  • UKCA
  • IEC 60947-4-1
  • IEC 60947-5-1
  • GB/T 14048.4

Selection Notes

The 6 A AC-3 rating places this contactor at the 2.2 kW point of the TeSys K range at 400 V; step up to the next current rating in the same frame if the motor's full-load current exceeds 6 A rather than running the contactor at its thermal limit continuously. The 1 NO auxiliary contact gives a direct run or fault-feedback signal to the control circuit without an add-on contact block, and the 48 V DC coil should match the control transformer already used elsewhere in the panel to avoid a dedicated supply.

Technical Details

Short Description
TeSys K contactor, 3P, 6 A AC-3, 1NO auxiliary contact, 48 V DC coil.
Rated Current (Ampere)
6 A
Mounting Type
DIN rail or plate
Protection Type
IP2X
Number of Poles
4P
Power (kW)
2.2 kW
Delivery Date (Days)
30 days
Model Number
LP1K
Tariff Code
85365080
