Schneider Electric LC1G5004KUEN TeSys Giga Contactor 4P 4NO AC-1 700 A 100-250 V AC/DC V AC/DC Coil Contactor

The Schneider Electric LC1G5004KUEN is a 4-pole TeSys Giga contactor rated 700 A AC-1 at up to 440 V, for heavy resistive and power-switching duty such as heater banks, capacitor banks or bypass circuits. It runs on a 100-250 V AC/DC wide-band electronic coil matched to standard 110/230 V control transformers and ships with a 1 NO + 1 NC auxiliary block factory-fitted on the 225 x 185 mm Giga frame.

Technical Specifications

Certifications & Standards

• CE
• UKCA
• CCC
• cULus
• EN/IEC 60947-4-1

Selection Notes

Rated 700 A AC-1, the LC1G5004KUEN is sized for power-switching and resistive duty — heater banks, capacitor banks, bus-tie and bypass circuits — rather than motor starting; the 4600 A breaking capacity and 4.0 kA 10 s short-time withstand are what matter for coordinating with an upstream breaker on this frame. It carries a 100-250 V AC/DC coil. Local contact-wear diagnosis (CWD) is read directly at the device; where the panel is inaccessible or centrally monitored, the LSEA electronic-coil variant of the same current frame adds remote diagnostics without changing the mechanical footprint.
