Schneider Electric LC1G400EHEN TeSys Giga Contactor 3P 3NO AC-3 400 A 200 kW 48-130 V AC/DC Coil Contactor

The Schneider Electric LC1G400EHEN is a 3-pole TeSys Giga contactor rated 400 A AC-3, switching motors up to 200 kW at 400 V. It runs on a 48-130 V AC/DC wide-band electronic coil for low-voltage control loops, ships with a 1 NO + 1 NC auxiliary block, and withstands 3.6 kA for 10 s on a short circuit on the 225 x 140 mm Giga frame.

Technical Specifications

Certifications & Standards

• CE
• UKCA
• CCC
• cULus
• EN/IEC 60947-4-1

Selection Notes

Rated 400 A AC-3 (200 kW at 400 V), the LC1G400EHEN is sized for motor starting and running duty; the 3.6 kA short-time withstand for 10 s is the figure to check against the upstream breaker's let-through when coordinating selectivity on a motor feeder. Its 48-130 V AC/DC coil keeps the design simple for panels already running a low-voltage control loop, with contact-wear status read locally at the device. Where the motor load is close to the 200 kW boundary, the next current step up in the same Giga 3-pole family keeps the AC-3 rating comfortably inside its nameplate rather than at the ceiling.
