Schneider Electric LC1G2254LSEA TeSys Giga Contactor 4P 4NO AC-1 330 A 200-500 V AC/DC Coil Contactor

Schneider Electric TeSys Giga 4P contactor, 330 A AC-1 at ≤440 V, 200-500 V AC/DC coil, plate mount, Contact Wear Diagnosis.

Rated current
330 A
Rated operational voltage
200–500–DC V DC
Poles
3P
EAN
3606481922755
Description

About the LC1G

The Schneider Electric LC1G2254LSEA is a 4-pole TeSys Giga high-power contactor rated 330 A AC-1 at up to 440 V, built for heavy power-switching duty rather than motor AC-3 starting. It runs on a 200-500 V AC/DC wide-band electronic coil with built-in peak limiting, ships with a 1 NO + 1 NC auxiliary contact block and local Contact Wear Diagnosis, and mounts on a plate 143 mm wide.

Certifications & Standards

  • CB Scheme
  • CCC
  • cULus
  • EAC
  • CE
  • UKCA
  • EU-RO-MR by DNV-GL
  • EN/IEC 60947-4-1
  • EN/IEC 60947-5-1
  • UL 60947-4-1
  • CSA C22.2 No 60947-4-1
  • JIS C8201-4-1
  • JIS C8201-5-1
  • UL 60335-1
  • UL 60335-2-40

Selection Notes

The 4P/4NO contact arrangement with AC-1-only duty targets heavy resistive or power-distribution switching rather than three-phase motor starting; for motor AC-3 duty at a comparable frame size, pick the corresponding 3-pole Giga variant instead. Local Contact Wear Diagnosis flags power-contact wear before failure, and the switching module can be replaced in place without removing busbars. The 200-500 V AC/DC coil spans the whole band without a separate coil code per voltage, which simplifies sourcing across regions.

Specification

Full specification

64 values · Last verified 29 Oct 2026

Main 11

Range TeSys
Range of Product TeSys Giga
Product or Component Type Contactor
Device short name LC1G
Contactor application Power switching
Utilisation category AC-3 AC-3e AC-1 AC-5a AC-5b AC-6a AC-6b DC-1 DC-3 DC-5
Poles description 4P
[Ue] rated operational voltage <= 1000 V AC 50/60 Hz <= 460 V DC
[Ie] rated operational current 225 A (at <140 °F (60 °C)) at <= 440 V AC-3 330 A (at <104 °F (40 °C)) at <= 1000 V AC-1
[Uc] control circuit voltage 200...500 V AC 50/60 Hz 200...500 V DC
Control circuit voltage limits Operational: 0.8 Uc Min...1.1 Uc Max (at <140 °F (60 °C)) Drop-out: 0.1 Uc Max...0.45 Uc Min (at <140 °F (60 °C))

Complementary 32

[Uimp] rated impulse withstand voltage 8 kV
Overvoltage category III
[Ith] conventional free air thermal current 330 A (at 104 °F (40 °C))
Rated breaking capacity 2050 A at 440 V
[Icw] rated short-time withstand current 1.8 kA - 10 s 1.0 kA - 30 s 0.85 kA - 1 min 0.56 kA - 3 min 0.44 kA - 10 min
Associated fuse rating 250 A aM at <= 440 V for motor 200 A aM at <= 690 V for motor 400 A gG at <= 690 V 400 A UL Type J at <= 600 V
Average impedance 0.00015 Ohm
[Ui] rated insulation voltage 1000 V
Power dissipation per pole 20 W AC-1 - Ith 330 A 8 W AC-3 - Ith 225 A
Compatibility code LC1G
Pole contact composition 4 NO
Auxiliary contact composition 1 NO + 1 NC
Irms rated making capacity 2720 A at 440 V
Coil technology Built-in bidirectional peak limiting
Safety reliability level B10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1
Mechanical durability 8 Mcycles
inrush power in VA (50/60 Hz, AC) 295 VA
inrush power in W (DC) 215 W
hold-in power consumption in VA (50/60 Hz, AC) 13.0 VA
hold-in power consumption in W (DC) 8.0 W
Operating time 40...70 ms closing 15...50 ms opening
Maximum operating rate 600 cyc/h AC-3 600 cyc/h AC-3e 300 cyc/h AC-1
Connections - terminals Power circuit: bar 2 - busbar cross section: 25 x 6 mm Power circuit: lugs-ring terminals 1 0.3 in2 (185 mm2) Power circuit: bolted connection Control circuit: push-in 1 0.0003...0.004 in2 (0.2...2.5 mm2) - cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.0004...0.004 in2 (0.25...2.5 mm2) - cable stiffness: flexible with cable end Control circuit: push-in 2 0.0008...0.002 in2 (0.5...1.0 mm2) with cable end Control circuit: push-in 0.001...0.004 in2 (0.75...2.5 mm2) - cable stiffness: solid stranded without cable end Control circuit: push-in 0.001...0.004 in2 (0.75...2.5 mm2) - cable stiffness: flexible with cable end
Connection pitch 1.4 in (35 mm)
Mounting Support Plate
Standards EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 UL 60335-1 UL 60335-2-40:Annex JJ
Product Certifications CB Scheme CCC cULus EAC CE UKCA EU-RO-MR by DNV-GL
Tightening torque 159.3 lbf.in (18 N.m)
Height 10.04 in (255 mm)
Width 5.6 in (143 mm)
Depth 7.6 in (193 mm)
Net Weight 11.2 lb(US) (5.1 kg)

Environment 7

IP degree of protection IP2X front face with shrouds IEC 60529 IP2X front face with shrouds VDE 0106
Ambient Air Temperature for Operation -13...140 °F (-25...60 °C)
Ambient Air Temperature for Storage -76...176 °F (-60...80 °C)
Mechanical robustness Vibrations 5...300 Hz 2 gn contactor open Vibrations 5...300 Hz 4 gn contactor closed Shocks 10 gn 11 ms contactor open Shocks 15 gn 11 ms contactor closed
color Dark grey
Protective treatment TH
Permissible ambient air temperature around the device -40...158 °F (-40...70 °C) at Uc
