- Part number
- GV2G05
- Model no
- GV2G
Description
About the GV2G
About the GV2G
The Schneider Electric GV2G05 is a 3-pole, 63 A, 690 V terminal block from the Linergy FT range, mounted on the same DIN rail as the TeSys GV2, Deca, K or U devices it supplies through a busbar outlet. It can take a GV1L3 current limiter for parallel motor starter assemblies and connects to the supply cable through screw clamp terminals.
Selection Notes
Mount the GV2G05 alongside the devices on the same DIN rail rather than on top of them, unlike the GV1G09 top-feed terminal block; add a GV1L3 current limiter when several parallel motor starters share this same busbar feed.
Specification
Full specification
Main 7
| Range | Linergy |
|---|---|
| Product name | FT |
| Device short name | GV2G |
| Product or Component Type | Terminal block |
| Accessory / separate part category | Connection accessory |
| Poles description | 3P |
| Range compatibility | TeSys GV2, TeSys Deca, TeSys K, TeSys U |
Complementary 7
| [Ie] rated operational current | 63 A |
|---|---|
| Mounting Location | 35 mm DIN rail |
| IP degree of protection | IP20 conforming to IEC 60529 |
| [Ui] rated insulation voltage | 690 V IEC 60947-1 |
| Connections - terminals | Screw clamp terminals 1 cable(s) (4 AWG) - solid, Screw clamp terminals 1 cable(s) 0.002…0.02 in² (1.5…16 mm²) - flexible with cable end, Screw clamp terminals 1 cable(s) 0.002…0.02 in² (1.5…16 mm²) - flexible without cable end, Screw clamp terminals 1 cable(s) 0.002…0.04 in² (1.5…25 mm²) - solid, Screw clamp terminals 2 cable(s) 0.002…0.006 in² (1.5…4 mm²) - flexible with cable end, Screw clamp terminals 2 cable(s) 0.002…0.009 in² (1.5…6 mm²) - solid, Screw clamp terminals 2 cable(s) 0.004…0.006 in² (2.5…4 mm²) - flexible without cable end, Screw clamp terminals 1 cable(s) (4 AWG) - flexible |
| Tightening torque | 15.05 lbf.in (1.7 N.m) screw clamp terminals, 19.5 lbf.in (2.2 N.m) connector |
| Net Weight | 0.254 lb(US) (0.115 kg) |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Show all 28 specifications ↓ Show less ↑13 more values in Identification, Logistics.
Identification 8
| Part number | GV2G05 |
|---|---|
| Type designation | GV2G |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3389110512946 |
Logistics 5
| Country of origin | RO |
|---|---|
| Shipping weight | 0.115 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for GV2G05
No documents are on file for this part yet.
Ask us for the datasheet
Quick answers
Questions about the GV2G
What is the HS code of GV2G for customs?
The tariff (HS) code on file for GV2G is 853890.
What is the EAN of GV2G?
The EAN (GTIN) of GV2G is 3389110512946.
Where does GV2G ship from, and how fast?
GV2G ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
