Schneider Electric GV1L3 TeSys GV2 Current Limiter Module 32 A 690 V for GV2 Breakers Automation Component

% $-71.64
Schneider Electric GV1L3 TeSys GV2 current limiter module - 32A 690V accessory
Schneider Electric GV1L3 TeSys GV2 current limiter module - 32A 690V accessory

Schneider Electric GV1L3 TeSys GV2 Current Limiter Module 32 A 690 V for GV2 Breakers Automation Component

Brand: Schneider Electric
Reference No: GV1L3
Series: TeSys GV2 | TeSys Deca
Tariff Code (HS): 853620
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$71.64

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric GV1L3 is a TeSys short-circuit current limiter module rated 32 A at 690 V AC, mounted on top of a GV2L, GV2LE, GV2P, GV2ME or GV2RT motor circuit breaker to raise its breaking capacity from 50 kA up to 100-130 kA at 400 V. It activates at 1500 A and weighs 0.13 kg.

Technical Specifications

SKU GV1L3
Brand Schneider Electric
Range TeSys GV2 / TeSys Deca
Component Type Current limiting module
Compatible Devices GV2RT, GV2ME, GV2P, GV2L
Function Increases breaking capacity of the circuit breaker
Mounting Location On top of the circuit breaker
Rated Operational Current (Ie) 32 A
Conventional Thermal Current (Ith) 63 A
Activation Threshold 1500 A
Breaking Capacity Boost Up to 100-130 kA, depending on protective device
Rated Operational Voltage (Ue) 690 V AC, 50/60 Hz
Rated Insulation Voltage (Ui) 690 V AC, 50/60 Hz
Net Weight 0.13 kg

Selection Notes

Add the GV1L3 on top of a GV2 breaker whose standard 50 kA breaking capacity is not enough for the prospective fault current at the installation point; the module raises it to 100-130 kA without changing the breaker's own current setting. It is sized for the 32 A / 690 V class of GV2 breakers only - larger frames in the GV3 and GV4 ranges use a different current-limiter reference.

Technical Details

Short Description
TeSys GV2 current limiter module, 32 A, 690 V AC, boosts breaking capacity to 100-130 kA.
Mounting Type
Mounts on top of GV2 circuit breaker
Delivery Date (Days)
30 days
Model Number
GV1L3
Tariff Code
853620
