Part number
EZCV250H4160
Model no
Easypact EZCV250H
$571.78 On request Dispatch — · From TürkiyeGet a Quote
EasyPact

Schneider Electric EZCV250H4160 EasyPact EZCV250H 4P 160 A 36 kA TM-D Moulded Case Circuit Breaker

Schneider Electric EZCV250H4160, EasyPact EZCV250H, 4P 160 A, 36 kA at 380/415 V AC, TM-D trip, integrated Vigi earth-leakage protection

Rated current
160 A
Rated operational voltage
440 V AC
Description

About the Easypact EZCV250H

The Schneider Electric EZCV250H4160 is a 160 A EasyPact EZCV250H moulded case circuit breaker with integrated earth-leakage (Vigi) protection for low-voltage distribution. Its TM-D thermal-magnetic trip unit combines overload, short-circuit and earth-fault tripping, and the 4-pole frame breaks 36 kA at 380/415 V AC under IEC 60947-2.

Certifications & Standards

  • JIS C8201-2-2
  • EN/IEC 60947-2
  • GB/T 14048.2
  • EN/IEC 60947-1

Selection Notes

EZCV250H4160 folds earth-fault detection into the breaker itself rather than requiring a separate add-on Vigi module, so it suits a 4-pole distribution circuit that needs earth-leakage protection in the same DIN footprint as a standard EZCV250H breaker. The 160 A TM-D trip is fixed-thermal, so pick a different amperage in the EZCV250H4xxx line rather than relying on field adjustment if the protected circuit's load current changes. Because the 36 kA breaking figure applies at 380/415 V, verify prospective fault current at the installation point before using the 25 kA rating that applies at 440 V.

Specification

Full specification

65 values · Last verified 30 Oct 2026

Main 23

Range of product EasyPact
Product or component type Circuit breaker
Device short name Easypact EZCV250H
Circuit breaker name Easypact EZCV250H
Device application Distribution
Poles description 4P
Protected poles description 3t
Network type AC
Network frequency 50/60 Hz
[In] rated current 160 A at 40 °C
[Ui] rated insulation voltage 440 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2
[Ue] rated operational voltage 440 V AC 50/60 Hz conforming to IEC 60947-2
Breaking capacity code H
Breaking capacity 100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2, 25 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 36 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity 12.5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2, 18 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
Suitability for isolation Yes conforming to IEC 60947-2
Utilisation category Category A
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit rating 160 A at 40 °C
Protection type Overload protection, Earth-leakage protection, Short-circuit protection
Pollution degree 3 conforming to IEC 60947

Complementary 13

Control type Toggle
Mounting mode Fixed
Mounting support Backplate
Upside connection Front
Downside connection Front
Mechanical durability 10000 cycles
Connection pitch 35 mm
Local signalling Positive contact indication
Neutral protection setting Without protection
Earth-leakage protection With
Height 165 mm
Width 140 mm
Depth 68 mm

Environment 5

Standards JIS C8201-2-2, EN/IEC 60947-2, GB/T 14048.2, EN/IEC 60947-1
IP degree of protection IP20 conforming to IEC 60529
IK degree of protection IK07 conforming to EN 50102
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -35…85 °C
Show all 65 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number EZCV250H4160
Type designation Easypact EZCV250H
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 11.000 cm
Package 1 Width 14.500 cm
Package 1 Length 18.500 cm
Package 1 Weight 2.520 kg
Unit Type of Package 2 S03
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 15.607 kg
Shipping weight 2.52 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for EZCV250H4160

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • JIS C8201-2-2
  • EN/IEC 60947-2
  • GB/T 14048.2
  • EN/IEC 60947-1
Quick answers

Questions about the Easypact EZCV250H

What is the rated current of Easypact EZCV250H?

The rated current of Easypact EZCV250H is 160 A.

Which supply voltage is Easypact EZCV250H rated for?

The rated operational voltage of Easypact EZCV250H is 440 V AC.

What is the HS code of Easypact EZCV250H for customs?

The tariff (HS) code on file for Easypact EZCV250H is 853620.

Where does Easypact EZCV250H ship from, and how fast?

Easypact EZCV250H ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
