Schneider Electric E160N420FM, EasyPact CVS1600N, 4P 1600 A, 50 kA at 380/415 V AC, ETS 2.0 electronic trip
The Schneider Electric E160N420FM is a 1600 A EasyPact CVS1600N moulded case circuit breaker for low-voltage electrical distribution, built on a medium-to-high breaking N frame. Its ETS 2.0 electronic trip unit gives adjustable long-time overload and instantaneous short-circuit protection (LI), and the 4-pole, 4D frame breaks 50 kA at 380/415 V AC under IEC 60947-2.
Pick the N frame as the mid-tier option: 50 kA at 380/415 V covers most distribution boards without paying for the H frame's extra breaking capacity. The 4-pole frame adds switched neutral protection, selectable at 0.5 x Ir for a half-protected N/2 conductor or 1 x Ir for a fully protected neutral -- relevant on TT or TN-S systems carrying unbalanced single-phase loads. Within the 1600 A CVS1600 frame size, E160N420FM (N class) sits alongside breaking-class siblings at the same amperage -- move up a class if downstream fault studies show higher prospective short-circuit current than 50 kA at 380/415 V, since the ETS 2.0 long-time setting only trims down to 0.4 x In (640 A) and cannot raise the frame's current rating.
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS |
| Product or component type | Circuit breaker |
| Device short name | CVS1600N |
| Device application | Low voltage electrical distribution |
| Poles description | 4P |
| Protected poles description | 4D |
| Neutral position | Left |
| Neutral protection setting | No protection (3D), 0.5 x Ir (3D + N/2), 1 x Ir (4D) |
| [Ue] rated operational voltage | 440 V AC 50/60 Hz |
|---|---|
| [In] rated current | 1600 A at 50 °C |
| Network type | AC |
| Network frequency | 50/60 Hz |
| [Ui] rated insulation voltage | 800 V AC conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-3 |
| Power dissipation | 15 W |
| Protection type | L : for overload protection (long time), I : for instantaneous short-circuit protection |
| Breaking capacity code | N 50 kA 415 V AC |
| Local signalling | 4 LEDs (red) for fault indication, 1 LED (yellow) for overload |
| Auxiliary contact composition | 1 NO/NC |
| Earth-leakage protection | Without |
| Control type | Rotary handle, Toggle |
| Breaking capacity | 70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 45 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Utilisation category | Category A |
| [Ics] rated service breaking capacity | 70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 45 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 5000 cycles |
| Electrical durability | 3000 cycles at 415 V In, 2000 cycles at 440 V In |
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
| Connection pitch | 70 mm |
| Mounting mode | Fixed |
| Mounting support | Backplate |
| Upside connection | Front |
| Downside connection | Front |
| Trip unit name | ETS 2.0 |
| Trip unit technology | Electronic |
| Trip unit protection functions | LI |
| Trip unit rating | 1600 A at 50 °C |
| Long time pick-up adjustment type Ir | Adjustable |
| Long time pick-up adjustment range | 0.4...1 x In |
| Long time delay adjustment type | Adjustable 9 settings |
| [tr] long-time delay adjustment range | 12.5…600 s at 1.5 x Ir, 0.5…24 s at 6 x Ir, 0.7…16.6 s at 7.2 x Ir |
| Thermal memory | 20 mn |
| Instantaneous pick-up adjustment type Ii | Adjustable |
| Instantaneous pick-up adjustment range | 1.5...10 x Ir |
| Zone selective interlocking ZSI | Without |
| Net weight | 18 kg |
| IP degree of protection | IP40 conforming to IEC 60529 |
|---|---|
| IK degree of protection | IK07 conforming to IEC 62262 |
| Relative humidity | 0…95 % |
| Operating altitude | 0...2000 m without derating, 2000...5000 m with derating |
| Height | 327 mm |
| Width | 280 mm |
| Depth | 147 mm |
| Standards | EN/IEC 60947-2 |
| Product certifications | CCC, CB, CE |
| Pollution degree | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Part number | E160N420FM |
|---|---|
| Type designation | CVS1600N |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| Warranty (in months) | 18 |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 29.5 cm |
| Package 1 Width | 39.6 cm |
| Package 1 Length | 59.6 cm |
| Package 1 Weight | 20 kg |
| Shipping weight | 18.0 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
