Schneider Electric E080F320FM EasyPact CVS800F 3P 800 A 36 kA ETS 2.0 Fixed Moulded Case Circuit Breaker

The Schneider Electric E080F320FM is a 800 A EasyPact CVS800F moulded case circuit breaker for low-voltage electrical distribution, built on a standard-breaking F frame. Its ETS 2.0 electronic trip unit gives adjustable long-time overload and instantaneous short-circuit protection (LI), and the 3-pole, 3D frame breaks 36 kA at 380/415 V AC under IEC 60947-2.

Technical Specifications

Certifications & Standards

• CCC
• CB
• CE
• EN/IEC 60947-2

Selection Notes

Pick the F frame where available fault current stays under 36 kA at 380/415 V; it is the lightest-duty, lowest-cost frame in this CVS range. The 3-pole frame protects the three phase conductors only; use it on a balanced three-phase feeder where the neutral is bonded upstream or not distributed. Within the 800 A CVS800 frame size, E080F320FM (F class) sits alongside breaking-class siblings at the same amperage -- move up a class if downstream fault studies show higher prospective short-circuit current than 36 kA at 380/415 V, since the ETS 2.0 long-time setting only trims down to 0.4 x In (320 A) and cannot raise the frame's current rating.
