Schneider Electric DF2FN63 Cylindrical Fuse Link gG 22×58 mm 63 A 500 V Fuse Link

% $-6.79
Schneider Electric DF2FN63 cylindrical gG fuse link 63 A 500 V
Schneider Electric DF2FN63 cylindrical gG fuse link 63 A 500 V

Schneider Electric DF2FN63 Cylindrical Fuse Link gG 22×58 mm 63 A 500 V Fuse Link

Brand: Schneider Electric
Reference No: DF2FN63
Series: TeSys fuse-disconnector
Tariff Code (HS): 853610
Rated Current: 63 A
Rated Voltage: 500 V
Stock: 22
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$6.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric DF2FN63 is a 22 x 58 mm cylindrical gG fuse link for TeSys GS switch-disconnector fuse bases, rated 63 A at 500 V AC. It protects circuits against thermal overloads and short-circuit currents with a general-purpose gG time-current curve, and ships without a blown-fuse striker indicator, ten fuse links to a set.

Technical Specifications

Reference DF2FN63
Brand Schneider Electric
Range TeSys fuse-disconnector
Device short name DF2
GTIN 3389110503005
Fuse type NFC cylindrical
Fuse size 22 x 58 mm
Fuse curve / class gG
[In] Rated current 63 A
[Un] Rated operational voltage 500 V AC
Blown-fuse indicator None (without striker)
Net weight 0.045 kg

Selection Notes

The 22 x 58 mm body size ties this fuse link to a specific TeSys GS fuse-disconnector frame, so pick the amp rating to match the protected circuit's full-load current rather than the disconnector's maximum frame rating — the gG curve covers both general overload and short-circuit duty, unlike an aM fuse sized only for motor starting.

Technical Details

Short Description
22 x 58 mm cylindrical gG fuse link, 63 A, 500 V AC, set of 10
Rated Current (Ampere)
63 A
Rated Voltage (VAC)
500 V
Delivery Date (Days)
30 days
Model Number
DF2
Tariff Code
853610
