Part number
DF2FN100
Model no
DF2
$6.96 In stock · 43 Dispatch Planned dispatch date. We aim to ship within 30 business days. Depending on warehouse workload it can take 1–2 business days longer. · From Türkiye
TeSys fuse-disconnector

Schneider Electric DF2FN100 Cylindrical Fuse Link gG 22×58 mm 100 A 500 V Fuse Link

22 x 58 mm cylindrical gG fuse link, 100 A, 500 V AC, set of 10

Rated current
100 A
Rated operational voltage
500 V AC
EAN
3389110540147
Description

About the DF2

The Schneider Electric DF2FN100 is a 22 x 58 mm cylindrical gG fuse link for TeSys GS switch-disconnector fuse bases, rated 100 A at 500 V AC. It protects circuits against thermal overloads and short-circuit currents with a general-purpose gG time-current curve, and ships without a blown-fuse striker indicator, ten fuse links to a set.

Selection Notes

The 22 x 58 mm body size ties this fuse link to a specific TeSys GS fuse-disconnector frame, so pick the amp rating to match the protected circuit's full-load current rather than the disconnector's maximum frame rating — the gG curve covers both general overload and short-circuit duty, unlike an aM fuse sized only for motor starting.

Specification

Full specification

41 values · Last verified 30 Oct 2026

Main 8

Range of Product TeSys fuse-disconnector
Product or Component Type Cartridge fuse
Device short name DF2
[Ue] rated operational voltage 500 V AC
Line Rated Current 100 A 500 V
Fuse size 22 x 58 mm
Fuse type NFC
Quantity per Set Set of 10

Complementary 2

fuse curve GG
Net Weight 0.099 lb(US) (0.045 kg)

Contractual warranty 1

Warranty (in months) 18
Show all 41 specifications ↓ Show less ↑30 more values in Identification, Logistics.

Identification 8

Part number DF2FN100
Type designation DF2
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3389110540147

Logistics 22

Unit Type of Package 1 PCE
Nbr. of units in pkg. 1
Package 1 Height 0.984 in (2.500 cm)
Package 1 Width 4.449 in (11.300 cm)
Package 1 Length 4.724 in (12.000 cm)
Package weight(Lbs) 1.834 oz (52.000 g)
Unit Type of Package 2 BB1
Number of Units in Package 2 10
Package 2 Height 0.984 in (2.500 cm)
Package 2 Width 4.449 in (11.300 cm)
Package 2 Length 4.724 in (12.000 cm)
Package 2 Weight 18.413 oz (522.000 g)
Unit Type of Package 3 S02
Number of Units in Package 3 160
Package 3 Height 5.906 in (15.000 cm)
Package 3 Width 11.811 in (30.000 cm)
Package 3 Length 15.748 in (40.000 cm)
Package 3 Weight 20.258 lb(US) (9.189 kg)
Shipping weight 0.045 kg
Ships from Türkiye
Dispatch 29 Dec
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for DF2FN100

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the DF2

What is the rated current of DF2?

The rated current of DF2 is 100 A.

Which supply voltage is DF2 rated for?

The rated operational voltage of DF2 is 500 V AC.

What is the HS code of DF2 for customs?

The tariff (HS) code on file for DF2 is 853610.

What is the EAN of DF2?

The EAN (GTIN) of DF2 is 3389110540147.

Where does DF2 ship from, and how fast?

DF2 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 30 business days.
