- Part number
- N084008
- Catalog no
- MI5FA25V2.5
Mersen N084008 MI5FA25V2.5 Miniature Fuses Size 5x20 250V 2.5A High Speed FA Clip Mounting
Miniature Fuses Size 5x20 250V 2.5A High Speed FA Clip Mounting
Description
About the MI5FA25V2.5
About the MI5FA25V2.5
The Mersen MI5FA25V2.5 (N084008) is a miniature Fuses Size 5x20 250V 2.5A High Speed FA Clip Mounting from the Semiconductor Miniature Fuses Size 5x20 FA/FB 125V-250V range. Genuine Mersen product, supplied worldwide by Stoklink with export shipping from Turkey.
Certifications & Compliance
- UL
- CE
- RoHS
- UKCA
- REACH
Specification
Full specification
| Part number | N084008 |
|---|---|
| Catalog no | MI5FA25V2.5 |
| Brand | Mersen |
| Condition | New, factory sealed |
| Source | Mersen and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 3605340059502 |
| Rated current | 2.5 A |
|---|---|
| Rated operational voltage | 250 V AC |
| Shipping weight | 0.001 kg |
|---|---|
| Standards | UL, CE, RoHS, UKCA, REACH |
| Mounting | Clip-on / Busbar |
| HS code | 85361050 |
|---|---|
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
| ROHS Compliant | Yes |
|---|---|
| AC or DC | AC |
| Speed/Characteristic | High Speed |
| Fuse Size | 5x20 |
| Clearing I2t At Rated Voltage | 3.2 A²s |
| Melting I2t | 1.44 A²s |
| Min Interrupting Rating (MBC) | 10 kA |
| Design Details | FA |
| Connection/Terminal Type | Ferrule |
| Product group | Miniature Fuses |
| Body/Insulating Material | Ceramic |
| Product Diameter | 5 mm |
| Product Length | 20 mm |
| Product Height | 5 mm |
| Sell Pack Quantity | 50 EA |
| Sell Pack Weight | 0.1 kg |
| Sell Pack Width | 37 mm |
| Sell Pack Length | 59 mm |
| Sell Pack Height | 29 mm |
| Product Weight | 0.0012 kg |
From the manufacturer description; the values above take precedence.
Documents
Documents for N084008
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- UL
- CE
- RoHS
- UKCA
- REACH
Quick answers
Questions about the MI5FA25V2.5
What is the rated current of MI5FA25V2.5?
The rated current of MI5FA25V2.5 is 2.5 A.
Which supply voltage is MI5FA25V2.5 rated for?
The rated operational voltage of MI5FA25V2.5 is 250 V AC.
What is the HS code of MI5FA25V2.5 for customs?
The tariff (HS) code on file for MI5FA25V2.5 is 85361050.
What is the EAN of MI5FA25V2.5?
The EAN (GTIN) of MI5FA25V2.5 is 3605340059502.
Where does MI5FA25V2.5 ship from, and how fast?
MI5FA25V2.5 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
Reviews
Customer reviews
Series
Mersen Semiconductor Miniature Fuses Size 5x20 FA/FB 125V-250V
- Brand
- Mersen
- Series
- Semiconductor Miniature Fuses Size 5x20 FA/FB 125V-250V
