Mersen 83010104 STMT1-50K320V-1P Surge Protection Device Type 1, 50kA Iimp (10/350), 1Ph, 277V, L-N, 1 Pole, Monobloc, 2 Modules

% $-254.02
Mersen 83010104 Surge Protective Device
Mersen 83010104 Surge Protective Device

Mersen 83010104 STMT1-50K320V-1P Surge Protection Device Type 1, 50kA Iimp (10/350), 1Ph, 277V, L-N, 1 Pole, Monobloc, 2 Modules

Brand: Mersen
Reference No: 83010104
Catalog No: STMT1-50K320V-1P
Series: Surge-Trap® Monobloc STMT1 Series - 50kA
Tariff Code (HS): 85363030
Stock: 0
Shipping Origin: Turkey EXW
$254.02

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Mersen STMT1-50K320V-1P (83010104) is a surge Protection Device Type 1, 50kA Iimp (10/350), 1Ph, 277V, L-N, 1 Pole, Monobloc, 2 Modules from the Surge-Trap® Monobloc STMT1 Series - 50kA range. Genuine Mersen product, supplied worldwide by Stoklink with export shipping from Turkey.

Technical Specifications

Catalogue No STMT1-50K320V-1P
ROHS Compliant Yes
IEC SPD Type Class I
Format Monobloc
Nominal Operating Volt Rating (Un) 277
AC or DC AC
Protection Modes L - N / L-PE / N-PE
System Configuration TNS, TNC, TT (nur L-N)
Lightning Impulse Current (10/350) (LIMP) 50 kA
Following Current (Ifi) 50 kA
Short Circuit Withstand (ISCCR) 50 kA
Number of Poles 1-Pole
Torque Rating 3 N m
Max. Back-Up Fuse 500 A [gG]
MOV Response Time ≤50
Installation Mounting DIN Rail
Product group Power Line SPDs
Product Width 36 mm
Product Length 70 mm
Product Height 90 mm
Sell Pack Quantity 1 EA
Sell Pack Weight 0.282 kg
Sell Pack Width 42 mm
Sell Pack Length 117 mm
Sell Pack Height 90 mm
Product Weight 0.252 kg
EAN/UPC 8435297852339

Certifications & Compliance

  • CE
  • RoHS
  • REACH

Technical Details

Short Description
Surge Protection Device Type 1, 50kA Iimp (10/350), 1Ph, 277V, L-N, 1 Pole, Monobloc, 2 Modules
Mounting Type
DIN Rail
Catalog No
STMT1-50K320V-1P
Standards
CE, RoHS, REACH
Model Number
STMT1-50K320V-1P
Tariff Code
85363030
