Modular PlasticABB 1SFA611621R1074 MLBL-07L LED Block 230V AC Front Mount Modular Plastic Series
Description
About the MLBL-07L
About the MLBL-07L
The ABB MLBL-07L LED Block (SKU: 1SFA611621R1074) is a front-mounting pilot light LED block from the ABB Modular Plastic Series, rated at 230 V AC. Designed for integration into control panels and industrial automation systems, the MLBL-07L provides a reliable visual indication solution with a compact 10 mm × 44 mm × 42 mm footprint and a lightweight 0.01 kg body, making it ideal for space-constrained switchgear and operator interface assemblies.
Certifications & Standards
- CE: Conforms to European Union safety, health, and environmental protection requirements.
- UKCA: UK Conformity Assessed marking for the Great Britain market.
- CCC: China Compulsory Certification for products sold in the Chinese market.
- CSA: Canadian Standards Association certification for North American markets.
- EAC: Eurasian Conformity mark for the Eurasian Economic Union member states.
- RoHS: Compliant with EU Restriction of Hazardous Substances Directive 2011/65/EU.
- REACH: Compliant with EU REACH regulation on chemical substances (EC 1907/2006).
- WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive for responsible disposal.
Specification
Full specification
Dimensions 4
| Product Net Width | 10 mm |
|---|---|
| Product Net Height | 44 mm |
| Product Net Depth / Length | 42 mm |
| Product Net Weight | 0.01 kg |
Technical 15
| Ambient Air Temperature | Operation -25 ... +70 °C, Storage -40 ... +85 °C |
|---|---|
| Color | Blue |
| Illumination | Illuminated |
| Lamp Type | 230 V AC, integrated LED |
| Mounting Type | Front mounting |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Operational Voltage | 230 V AC |
| Power Loss | Maximum 0.4 W |
| Connecting Capacity | Flexible with Ferrule 1 x 0.75...2.5 mm², Flexible with Ferrule 2 x 0.75...2.5 mm², Flexible with Insulated Ferrule 1 x 0.75...2.5 mm², Flexible with Insulated Ferrule 2 x 0.75...2.5 mm², Flexible 1 x 0.75 ... 2.5 mm², Flexible 2 x 0.75 ... 2.5 mm², Solid 1 x 0.75...2.5 mm², Solid 2 x 0.75...2.5 mm² |
| Connection Type | Screw Clamp |
| Terminal Type | Screw Terminals |
| Tightening Torque | 0.9 N·m |
| Wire Stripping Length | 8 mm |
| Suitable For | MCBH-00, MCBH5-00, MP1, MP2, MP3, MP4, MPMT3, MPMP3, M2SS1, M2SS2, M2SS3, M2SS4, M2SS5, M2SS6, M3SS1, M3SS2, M3SS3, M3SS4, M3SS5, M3SS6, M3SS7, M3SS8, MPM1 |
| Suitable for Product Class | Pilot Devices |
Technical UL/CSA 1
| Connecting Capacity UL/CSA | 1x 18...14 AWG, 2x 18...14 AWG |
|---|
Show all 52 specifications ↓ Show less ↑32 more values in Identification, Environmental, Material Compliance, External Classifications and Standards, Logistics.
Identification 10
| Part number | 1SFA611621R1074 |
|---|---|
| Type designation | MLBL-07L |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 7320500544891 |
| eCl@ss | 27371209 |
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85369001 |
Environmental 1
| Degree of Protection | Terminals IP20 |
|---|
Material Compliance 6
| REACH Declaration | 2CMT2022-006479 |
|---|---|
| RoHS Declaration | 2CMT2022-006498 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006523 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
External Classifications and Standards 5
| ETIM 6 | EC000204 - Lamp holder block for control circuit devices |
|---|---|
| ETIM 7 | EC000204 - Lamp holder block for control circuit devices |
| eClass | V11.0 : 27371209 |
| UNSPSC | 39122221 |
| E-Number (Sweden) | 3705627 |
Logistics 10
| Package Level 1 Units | bag 10 piece |
|---|---|
| Package Level 1 Width | 135 mm |
| Package Level 1 Depth / Length | 155 mm |
| Package Level 1 Height | 25 mm |
| Package Level 1 Gross Weight | 0.11 kg |
| Package Level 1 EAN | 7320500373156 |
| Shipping weight | 0.11 kg |
| Ships from | Türkiye |
| Dispatch | 16 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SFA611621R1074
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- CSA
- RoHS
- UKCA
- CCC
- EAC
Quick answers
Questions about the MLBL-07L
Which supply voltage is MLBL-07L rated for?
The rated operational voltage of MLBL-07L is 230 V AC.
What is the HS code of MLBL-07L for customs?
The tariff (HS) code on file for MLBL-07L is 85369001.
What is the EAN of MLBL-07L?
The EAN (GTIN) of MLBL-07L is 7320500544891.
Where does MLBL-07L ship from, and how fast?
MLBL-07L ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
