ABB 1SDA101432R1 XT7H M 1250 Ekip Dip LS/I In1250A 3p F F 1250A 3-Pole 70kA Fixed Moulded Case Circuit Breaker
Description
About the XT7H
About the XT7H
The ABB 1SDA101432R1 XT7H M 1250 Ekip Dip LS/I In1250A 3p F F is a 1250 A, 3-pole fixed-mount power circuit-breaker from the Tmax XT7 series, engineered for the protection of transformers, generators, and large electrical installations. Rated for a breaking capacity of 70 kA at 400 V AC and equipped with the Ekip Dip LS/I electronic trip unit, the XT7H M 1250 Ekip Dip LS/I In1250A 3p F F delivers precise long-time and instantaneous overcurrent protection in a compact 210 × 268 × 178 mm fixed-frame format.
Certifications & Standards
- CE: Conforms to applicable European Union directives for electrical equipment
- RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
- Amendment 2015/863: Compliant with the RoHS II amendment expanding restricted substance scope
- REACH: Meets EU REACH regulation requirements for chemical substances
- IEC 60947-2: Designed and tested to the international standard for low-voltage circuit-breakers
- WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible disposal
- EU Directive 2011/65/EU: Full RoHS directive compliance confirmed
Applications & Use Cases
- Transformer primary and secondary protection in industrial and commercial power distribution
- Generator protection in standby and prime power installations
- Main incomer and feeder protection in MCC panels and switchboards
- Large motor feeder protection requiring high breaking capacity
- Installation protection in data centres, manufacturing facilities, and utilities
Specification
Full specification
Material Compliance 2
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|---|
| Simplified SCIP | 615b5733-8c68-4f8b-b6db-ad5e9e77274c Bulgaria, 64916361-482d-4c10-8f36-44c97254831a Belgium, 6ee8e61f-a0da-4fda-9094-6e1db1341afd Hungary, eaff4771-3586-456a-8e23-c286bbe6520c Spain, 982091bc-5820-4651-a248-9aa8d5fcca8f Croatia, c0a3b7d9-e41f-4411-991e-a28f2a509a75 Czechia, 47029f9b-a21c-47b8-8d08-004bb35adf3f Estonia, 5d625d9c-2419-4ec0-9aba-4978be9b4788 Greece, 15ad83de-42e9-4226-a816-5df4d0dd8546 Portugal, 47533c63-b8aa-4045-ade4-8ee20199a015 Hungary, c57545f2-37af-4912-86b8-0976eb797daf Netherlands, 15814883-5a94-4868-ac51-0d23c047d6c6 Poland, f98ca6cb-0f09-4c16-ab4e-6d1c93aff110 Sweden, 96caac13-5c56-4a76-8b68-e5e569d127de Poland, 20b081d0-50bd-40a5-a4be-1f76936a25c3 Sweden, 4c79b268-b14f-4a8b-98fb-ab15cf94fc69 France, d4430368-10f7-4acc-9f49-48c4c6bdbc50 Germany, abb03077-1b4f-40f6-84b7-d0dd962da7ec Germany, f094ab20-d91c-4582-b41e-c40545c2458d France, 72868fb0-fce9-4157-a712-0e41b7ccb058 Germany, 59d222fb-ac7d-4c42-9a9e-085414ff0a4e Germany, 26b1f611-420f-4403-b66a-18cfcdf3758d Belgium, 980a8c8b-bfdd-4122-a055-afb4a9fa6192 Denmark, 4218a654-b028-4228-a3f2-b40934e3952b Germany, 83be51a7-061d-45bd-9b06-a5a575287242 Finland, c414f125-1f9a-4827-ad7f-d6c592c3face Norway, 7f0db7d7-6e8b-4ffc-85dc-ca8637615843 Poland, 5b1bb6ab-aaa4-4432-b6ea-c8748233e5fe Romania |
Environmental 1
| Ambient Air Temperature | Operation -40 ... 125 °C |
|---|
Dimensions 4
| Product Net Width | 210 mm |
|---|---|
| Product Net Height | 268 mm |
| Product Net Depth / Length | 178 mm |
| Product Net Weight | 11 kg |
Show all 56 specifications ↓ Show less ↑49 more values in Identification, Additional Information, Technical, External Classifications and Standards, Logistics.
Identification 11
| Part number | 1SDA101432R1 |
|---|---|
| Type designation | XT7H |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 8056221012508 |
| ETIM class | EC000228 |
| eCl@ss | 27370409 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
Additional Information 5
| Circuit Breaker Type to be Associated | Power Distribution |
|---|---|
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
Technical 20
| Current Type | AC |
|---|---|
| Electrical Durability | 3000 cycle, 60 cycles per hour |
| Mechanical Durability | 20000 cycle, 60 cycles per hour |
| Number of Poles | 3P |
| Order Multiple | 1 piece |
| Power Loss | at Rated Operating Conditions per Pole 57 W |
| Rated Current (In) | 1250 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA, (230 V AC) 100 kA, (240 V AC) 100 kA, (380 V AC) 70 kA, (415 V AC) 70 kA, (440 V AC) 65 kA, (500 V AC) 50 kA, (525 V AC) 50 kA, (690 V AC) 42 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | 20 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA, (230 V AC) 100 kA, (240 V AC) 100 kA, (380 V AC) 70 kA, (415 V AC) 70 kA, (440 V AC) 65 kA, (500 V AC) 50 kA, (525 V AC) 50 kA, (690 V AC) 42 kA |
| Rated Uninterrupted Current (Iu) | 1250 A |
| Release | Ekip Dip LS/I |
| Release Type | EL |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT7M |
| Terminal Connection Type | Front |
External Classifications and Standards 3
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
|---|---|
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
Logistics 10
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 280 mm |
| Package Level 1 Height | 350 mm |
| Package Level 1 Depth / Length | 360 mm |
| Package Level 1 Gross Weight | 12.5 kg |
| Package Level 1 EAN | 8056221012508 |
| Shipping weight | 12.5 kg |
| Ships from | Türkiye |
| Dispatch | 9 Nov |
| Stock | Critical stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SDA101432R1
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- RoHS
- IEC60947-2
Quick answers
Questions about the XT7H
What is the rated current of XT7H?
The rated current of XT7H is 1250 A.
What is the HS code of XT7H for customs?
The tariff (HS) code on file for XT7H is 85362090.
What is the EAN of XT7H?
The EAN (GTIN) of XT7H is 8056221012508.
Where does XT7H ship from, and how fast?
XT7H ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
