ABB 1SDA101367R1 XT7S M 1000 Ekip Dip LS/I In1000A 3p F F Moulded Case Circuit Breaker

The ABB 1SDA101367R1 — catalog number XT7S M 1000 Ekip Dip LS/I In1000A 3p F F — is a 1000 A, 3-pole fixed-mounted moulded case power circuit-breaker from the Tmax XT7S series, engineered for transformer, generator, and installation protection. With an 85 kA breaking capacity at 220 V AC and Ekip Dip LS/I electronic trip unit, it delivers precise long-time and instantaneous protection in a compact 210 × 268 × 178 mm fixed-frame design.

Technical Specifications

Certifications & Standards

• CE: Complies with applicable European Union directives for electrical equipment
• IEC 60947-2: Meets the international standard for low-voltage switchgear and controlgear — circuit-breakers
• RoHS: Restriction of Hazardous Substances compliant — free from restricted materials per EU Directive 2011/65/EU
• REACH: Compliant with EU REACH regulation (EC) No 1907/2006 on chemical substances
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive 2012/19/EU

Applications & Use Cases

• Transformer and generator feeder protection in medium and large industrial installations
• Main incomer and tie-breaker positions in low-voltage switchboards and motor control centres
• Installation protection for commercial buildings, data centres, and utility substations
• Applications requiring high breaking capacity (85 kA) combined with electronic LS/I protection curves
• Fixed-mounting configurations where the circuit-breaker remains in a permanent panel position
