ABB 1SDA100827R1 XT7S 1000 Ekip Dip LS/I In=1000A 3p F F Moulded Case Circuit Breaker

The ABB 1SDA100827R1 XT7S 1000 Ekip Dip LS/I In=1000A 3p F F is a high-performance fixed-mount power circuit-breaker from the Tmax XT7S series, engineered for transformer, generator, and installation protection in demanding industrial environments. Rated at 1000 A with a breaking capacity of 85 kA at 220 V AC, this 3-pole fixed unit combines the Ekip Dip LS/I electronic trip unit with robust construction — delivering precision overcurrent and short-circuit protection for critical power distribution applications.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances requirements
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment
• Amendment 2015/863: EU amendment updating Annex II of Directive 2011/65/EU
• IEC 60947-2: Meets the international standard for low-voltage switchgear and controlgear — circuit-breakers
• CE: CE marked for compliance with applicable EU directives
• WEEE: Registered under EU Waste Electrical and Electronic Equipment directive for proper end-of-life recycling

Applications & Use Cases

• Transformer feeder and secondary-side protection in MV/LV substations
• Generator protection in standby and prime power installations
• Main and distribution circuit protection in industrial control panels
• Building infrastructure and data centre power distribution boards
• Marine and offshore power systems requiring high breaking capacity
